EB-GS2972
Evaluation Board User Guide
EB-GS2972
Evaluation Board User Guide
50283 - 2
May 2012
www.gennum.com
1 of 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EB-GS2972 and is the answer not in the manual?

Questions and answers

Related Manuals for GENNUM EB-GS2972

Summary of Contents for GENNUM EB-GS2972

  • Page 1 EB-GS2972 Evaluation Board User Guide www.gennum.com EB-GS2972 1 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 2: Table Of Contents

    2.1 Top Level Schematic ........................9 2.2 Audio Input Schematic ........................ 10 2.3 GS2972 Schematic ......................... 11 2.4 Power Schematic ........................... 12 3. Board Layout..............................13 4. Bill of Materials............................19 EB-GS2972 2 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 3: Overview

    Overview Together with the EB-GS2972 Evaluation Board, this document serves as a guide for evaluating the GS2972, a Gennum 3Gb/s, HD, SD SDI Transmitter. This document contains four main sections: 1. Evaluation Board User Guide. 2. Evaluation Board Schematics. 3. Evaluation Board Layout.
  • Page 4 Serial Audio Group 2 Power Audio AES (x4) 20-bit Video 3G-SDI GS2972 PCLK (Transmitter) 3G-SDI GSPI LED’s GSPI Header DIP Switch Block Diagram of the EB-GS2972 EB-GS2972 4 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 5: Board User Guide

    Through the use of JP7, the user can select the I/O voltage to be either 1.8V or 3.3V. If the EB-GS2972 and the EB-GS2970 are connected together, one supply will power both boards. Therefore, the +5V DC power is only required on either the EB-GS2972 or the EB-GS2970.
  • Page 6 When DETECT_TRS is LOW, the device extracts all internal timing from the supplied H:V:F or CEA-861 timing signals, dependent on the status of the TIM861 pin. When DETECT_TRS is HIGH, the device extracts all internal timing from TRS signals embedded in the supplied video stream. EB-GS2972 6 of 22 Evaluation Board User Guide...

  • Page 7: Inputs

    1.3.2 Parallel Video Input The EB-GS2972 has a 48-pin parallel connector for the serialized video input (J25). The video input includes the 20-bit video data and pixel clock. The related timing signals (F,V,H) are on the 10-bit parallel connector (J27).

  • Page 8: Control And Status

    GS2972s GSPI pins. To communicate with the GS2972 and the two SRCs, a Gennum USB to GSPI dongle must be connected to the GSPI header. A GSPI dongle is provided for communication to the GSPI interface. If you have the EB-GS2972 and the EB-GS2970 connected together, only one GSPI dongle is required, and can be connected to either of the boards.

  • Page 10: Audio Input Schematic

    SRC4382_SPI3 PCLK_GS4911 C127 SRC4382_SPI4 0.1u 0.1u 0.1u Gr2_AES_Ser 0.1u AES_IN5_6 AES5_6 AES_IN7_8 AES7_8 AES5_6 GS2972_AES5_6 AES7_8 GS2972_AES7_8 105R 105R SN65LVDT2 SN65LVDT2 FXL2TD245 Figure 2-2: Audio Input Schematics EB-GS2972 10 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 12: Power Schematic

    SRC-A SRC-B 1V8_SRC4382 Between pins 16 and 17 Between pins 16 and 17 VCC_1.8V SRC-A SRC-B C134 C135 C137 C136 C138 0.1u 0.1u Figure 2-4: Power Schematic EB-GS2972 12 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 13: Board Layout

    3. Board Layout Figure 3-1: Layer 1 (Top Layer) EB-GS2972 13 of 22 Evaluation Board User Guide 50283 - 2 May 2012...
  • Page 14 Figure 3-2: Layer 2 (Ground) EB-GS2972 14 of 22 Evaluation Board User Guide 50283 - 2 May 2012...
  • Page 15 Figure 3-3: Layer 3 (Power) EB-GS2972 15 of 22 Evaluation Board User Guide 50283 - 2 May 2012...
  • Page 16 Figure 3-4: Layer 4 (Signal 1) EB-GS2972 16 of 22 Evaluation Board User Guide 50283 - 2 May 2012...
  • Page 17 Figure 3-5: Layer 5 (Signal 2) EB-GS2972 17 of 22 Evaluation Board User Guide 50283 - 2 May 2012...
  • Page 18 Figure 3-6: Layer 6 (Bottom Layer) EB-GS2972 18 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 19: Bill Of Materials

    TSW-105-07-L-D BLKCON .100/VH/TM1SQ/W.100/3 5V Input (CON_WEID5MM_2_PWR) J3, J4 UCBBJE20-1 (BNC_EDGEMNT _GHZ-POUR-2LYR-ER3.8) J13, J14, J15, J16 BCJ-FPLV01 SQT-124-01-F-D-RA (HEADER 2MM_48_2X24_INVERSE) J27, J29 SQT-105-01-F-D-RA (HEADER 2MM_10_2X5_INVERSE) 4 HEADER (header_4_1x4) EB-GS2972 19 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 20: Evaluation Board User Guide 50283 - 2 May

    TP17, TP21, TP22, TP23 MAX6823V (SOT23) LT3021ES8-1.2 (CT-SOIC_8) GS2972 (CT-BGA_100_11X11_1.00) U10, U11, U12, U13 SN65LVDT2 (SOT23-5) TPS74201_RGW (20QFN-5X5(MOD)) SN74LVC1T45DBVR (sot23-6) LT3021ES8-1.8 (CT-SOIC_8) FXL4TD245 (mlp16e) U18, U22 SN74LVC1G3157 (SOT23-6) GS4911B (64QFN-9X9-P65) EB-GS2972 20 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 21: Eb-Gs2972

    FXL2TD245 (mac010a) HSMF-C165 U26, U27 SRC4382 (48-TQFP) CS10-27.000M (SM/XTAL_6.0X3.5/2) Parts Not To Be Populated DNP (0603) R65, R106 DNP (0603) R109 DNP (0402) R113, R115 DNP (0603) EB-GS2972 21 of 22 Evaluation Board User Guide 50283 - 2 May 2012...

  • Page 22: Eb-Gs2972

    Fax: +82-2-414-2998 Gennum Corporation assumes no liability for any errors or omissions in this document, or for the use of the circuits or devices described herein. The sale of the circuit or device described herein does not imply any patent license, and Gennum makes no representation that the circuit or device is free from patent infringement.
