RIDGID R2740 Operator's Manual

3 in. x 18 in. belt sander variable speed double in
Hide thumbs Also See for R2740:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Your belt sander has been engineered and manufactured to our high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID
SAVE THIS MANUAL FOR FUTURE REFERENCE
Cette ponceuse à bande a été conçue et fabriquée conformément
à nos strictes normes de fiabilité, simplicité d'emploi et sécurité
d'utilisation. Correctement entretenue, elle vous donnera des
années de fonctionnement robuste et sans problème.
AVERTISSEMENT :
Pour réduire les risques de blessures, l'utilisateur doit
lire et veiller à bien comprendre le manuel d'utilisation
avant d'utiliser ce produit.
Merci d'avoir acheté un produit RIDGID
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Find Quality Products Online at:
product.
®
.
®
GlobalTestSupply
www.
OPERATOR'S MANUAL
3 in. x 18 in. BELT SANDER
VARIABLE SPEED DOUBLE INSULATED
Su lijadora de banda ha sido diseñada y fabricada de conformidad
con nuestras estrictas normas para brindar fiabilidad, facilidad de
uso y seguridad para el operador. Con el debido cuidado, le brindará
muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario debe leer
y comprender el manual del operador antes de usar
este producto.
Le agradecemos la compra de un producto RIDGID
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
.com
R2740
.
®
sales@GlobalTestSupply.com

Advertisement

Table of Contents
loading

Related Manuals for RIDGID R2740

Summary of Contents for RIDGID R2740

  • Page 1 à bien comprendre le manuel d’utilisation y comprender el manual del operador antes de usar avant d’utiliser ce produit. este producto. Le agradecemos la compra de un producto RIDGID Merci d’avoir acheté un produit RIDGID ® ®...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO  Introduction ..................................2 Introduction / Introducción  General Power Tool Safety Warnings ..........................3-4 Règles de sécurité relatives aux outils électriques / Advertencias de seguridad para herramientas eléctrical  Belt Sander Saw Safety Rules ............................4 Avertissements de sécurité...

  • Page 3: General Power Tool Safety Warnings

    GENERAL POWER TOOL SAFETY WARNINGS  Prevent unintentional starting. Ensure the switch is in WARNING the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Read all safety warnings and all instructions. Carrying power tools with your finger on the switch or Failure to follow the warnings and instructions may energising power tools that have the switch on invites result in electric shock, fire and/or serious injury.

  • Page 4: Règles De Sécurité Relatives Aux Outils Électriques / Advertencias De Seguridad Para Herramientas Eléctrical  Belt Sander Saw Safety Rules

    GENERAL POWER TOOL SAFETY WARNINGS SERVICE  Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into  Have your power tool serviced by a qualified repair account the working conditions and the work to be person using only identical replacement parts.

  • Page 5: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING: in death or serious injury.

  • Page 6: Electrical

    ELECTRICAL DOUBLE INSULATION EXTENSION CORDS Double insulation is a concept in safety in electric power When using a power tool at a considerable distance from tools, which eliminates the need for the usual three-wire a power source, be sure to use an extension cord that has grounded power cord.

  • Page 7: Features

    FEATURES PRODUCT SPECIFICATIONS Belt Size ............3 in. x 18 in. Input .......120 V, 60 Hz, AC only, 6.5 Amps Sanding Surface ..........17.5 sq. in. Net Weight .............. 5.8 lbs. No Load Speed ........400 - 950 ft./min. LOCk-ON BUTTON kNOW YOUR BELT SANDER The lock-on feature allows you to lock the switch trigger in See Figure 1, page 14.

  • Page 8: Operation

    OPERATION APPLICATIONS WARNING: You may use this product for the purposes listed below: Do not allow familiarity with products to make you  Sanding wood, metals, and plastics careless. Remember that a careless fraction of a  Smoothing rough boards, chamfering, rounding edges second is sufficient to inflict serious injury.
  • Page 9 OPERATION VARIABLE SPEED CONTROL DIAL WARNING: See Figure 2, page 14. Keep hands and fingers clear of front roller and The sander has a variable speed control dial, A (slowest) spring mechanism at all times. Failure to do so to F (fastest), designed to allow operator control of belt could result in fingers getting pinched, causing speed.

  • Page 10: Operation

    OPERATION OPERATING THE SANDER WARNING: See Figure 8, page 15. The sander is designed to be operated as shown Clamp or otherwise secure the work to prevent it from in Figure 8, page 15 with both hands on the tool at moving under the sander.

  • Page 11: Adjustments

    ADJUSTMENTS MANUALLY ADJUSTING SANDING BELT  Slowly turn the tracking screw clockwise until the sanding belt is positioned at the edge of the platen. Do not allow TRACkING the sanding belt to extend past the edge of the platen. See Figure 11, page 15. This sander features an automatic tracking system designed WARNING: to keep the sanding belt centered.
  • Page 12 MAINTENANCE  Force old timing belt from one of the small pulleys with  Check for wear. Replace both brush assemblies when a screwdriver and remove it while turning the large either has less than 1/4 in. length of carbon remaining. pulley.

  • Page 13: Entretien / Mantenimiento  Warranty

    Fig. 1 Fig. 4 A - Switch trigger (gâchette, gatillo interruptor) Fig. 5 A - Lift belt tension release lever to remove sanding belt (relever le levier de tension pour retirer la bande, levante la palanca de A - Sanding belt (bande abrasive, banda de lija) liberación de tensión de la banda para retirar B - Variable speed control dial (commande de vitesse variable, selector de velocidad) la banda de lija)
  • Page 14 Fig. 10 Fig. 12 Fig. 7 A - Lock-on button (bouton de verrouillage, botón del seguro de encendido) B - Switch trigger (gâchette, gatillo A - Zipper (fermeture à glissière, cremallera) interruptor) A - Brush cap (couvercle de balai, tapa de la B - Dust (sac à...
