- Page 1 User manual VEO VOX Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.
- Page 3 RoHS II (Council directive 2011/65/EEC) Die CE– Kennzeichnung auf dem Gerät dokumentiert diese Übereinstimmung. The CE mark on the system points out this accordance. M. Reinecker Geschäftsführer Alsbach-Hähnlein, M. Reinecker General Manager 20.03.2018 ....................Ort und Datum der Ausstellung...
-
Page 4: Table Of Contents
Content I. General Information ....................6 Information on electromagnetic capability (EMC) ............6 Storage of the user manual ..................6 Product description ......................6 Medical device ......................7 Purpose ........................7 Evolution and lifetime of products ................7 Safety advice .......................7 Caution when using around medical devices ..............7 Precaution by alteration of the performance of the system ........8 Reinstatement/installation and maintenance...............8 Cleaning of the system ....................8... - Page 5 Frontal view ......................15 Central („zoom“) button ..................15 Left button ......................15 Right button ......................16 How to use the touch screen functions ..............16 1. Continuous Reading mode ................16 2. Still Capture mode ..................16 Call the Control Panel ....................17 Decision between Continuous Reading and Still Capture mode ......17 Choosing Reading Area - Cross Hair symbol ............18 Continuous Reading mode ..................18 Still Capture-Mode .....................21...
-
Page 6: General Information
I. General Information Important notes on the operation of VEO VOX! Please read them carefully prior to the operation of the reading system! Information on electromagnetic compatibility (EMC) This opto-electronic reading system with speech output is suited for use in all set- ups including the domicile that are connected directly to a public power supply for buildings with residential purposes. -
Page 7: Medical Device
In case the end user intends to use the VEO VOX in combination with another medi- cal devices that are life sustaining or a support system, it is recommended to get in contact with Reinecker Vision GmbH or with a licensed distributor. -
Page 8: Precaution By Alteration Of The Performance Of The System
The device contains of electronic components. To avoid damage to the environment, the country-specific rules have to be respected. Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. Caution: The use of any other power supply besides the original, might lead to... -
Page 9: Safety Instructions
2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. -
Page 10: Ii. Instructions For Reading System Veo Vox
Unpack the system carefully by lifting at the chassis arm while placing support under the XY table. Be sure to place unit on a stable surface with sufficient space. This may require more than 1 person. In case more space is needed, ask for Reinecker Visions height adjustable tables. -
Page 11: Insert / Replace Batteries In Remote Control
1. USB-port 2. 12V DC plug-in connector 3. Power outlet 4. Power adapter 5. Connection box Insert / replace batteries in remote control The remote control operates on 2 x AA-batteries (1,5V). ● Detach the cover on the flipside of the remote control. ●... -
Page 12: Alignment Of Monitor
Alignment of monitor Due to the monitor’s technology, contrast and brightness change depending on the angle of view. The highly flexible four-dimensional monitor arm enables the user to adjust the moni- tors height and angle according to the most ergonomic position (see below). Rotatable by 90 degrees... -
Page 13: Alignment Of The Xy-Table
Alignment of the xy-table The xy-table has two independent friction brakes for the x- and y-axis. The friction can be continuously adjusted from minimum to maximum. The yellow friction brake is used for the x-axis and the black brake for the y-axis. -
Page 14: Positioning Of The Remote Control
Positioning of the remote control The remote-control can be magnetically attached to the front of the monitor, the right side of the xy table, or can be handheld 1. Positioning of the remote control underneath the monitor 2. Positioning the remote control at the right side on the xy-table Turn ON and booting of VEO VOX... -
Page 15: Description Of The 3-Button Remote Control
Description of the 3-button remote control Frontal view 1. Color selection mode 2. Power ON/OFF, zoom +/-, autofocus 3. Contrast/Brightness, Line marker/shadowing Central („zoom“) button Power ON/OFF ● By briefly pressing the “zoom +/-” button, the system turns ON. By pressing and holding the “Zoom +/-“ button for approx. 4 sec., the system can be turned OFF manually. -
Page 16: Right Button
Right button ● Contrast/Brightness This button is equipped with a pull-out function. With the button in the pushed-in position, the combined adjustment of contrast and brightness is activated. Turn left: Low contrast, low brightness; turn right: high contrast, high brightness. Line marker/Shadowing ●... -
Page 17: Call The Control Panel
Call the Control Panel The Reinecker icon, which is located at the bottom left side of the screen, indicates that the touch control panel is hidden, but appears when touched. By tapping the Reinecker icon, the control panel appears as shown below: The camera icon for Continuous Reading / Still Capture reading, changes posi- tion and appears on the upper right corner of the screen. -
Page 18: Choosing Reading Area - Cross Hair Symbol
Choosing Reading Area - Cross Hair symbol In viewing mode: By tapping this icon you can choose one of the following options: Cross Hair, Full Screen, Column. With these settings you determine the area of the text that shall be scanned and read aloud: Cross Hair: Reading starts with the word/area that is in the center of the Cross Hair. - Page 19 To stop the reading, tap briefly on the STOP icon (the camera icon turns to red). Note: In case you have hidden the operating controls by pressing the Reinecker icon, you can stop reading also by briefly tapping the green camera icon. ●...
- Page 20 ● Image Gallery In viewing mode: Save image: Briefly press the icon to save the document that is visible on the screen in the image gallery. Open image gallery (Load image): Tap and hold the IMAGE MEMORY icon for approx. 2 seconds to see all images that have been saved.
-
Page 21: Still Capture-Mode
Still Capture-Mode Touch Panel ON / OFF ● Tap this icon to show / hide the touch screen operating panel. ● Call / Exit Still Capture mode The system is in Still Capture Viewing- (red camera) / Reading mode (green camera). All visible text on the screen will be cap- tured and read aloud in virtual mode. - Page 22 To stop the reading, tap briefly on the STOP icon (the camera icon turns to red). Note: In case you have hidden the operating controls by pressing the Reinecker icon, you can stop reading also by briefly tapping the green camera icon. ●...
-
Page 23: Vox Menu Adjustments
View image: Select an image and confirm selection by a double tap on this image. It will be displayed in full screen mode on the screen. Note: Selected images will be displayed in Still Capture Mode automatically. You can select Visualisations options (as described before) to display the text according to your needs. -
Page 24: Vox Options (Reading)
VOX options (Reading) Settings ► Recognition Single column recognition Enabled | Disabled Automatic continuous reading Enabled | Disabled Back Settings ► Visualisations Center on word Enabled | Disabled Draw paragraph boundaries Enabled | Disabled Retain typefaces Enabled | Disabled Typeface Monospace | Sans Serif | Serif Retain front styles Enabled | Disabled... - Page 25 Settings ► Languages Languages English | German | French | Norwegian... (choose between 30 languages) Back Settings ► Audio Volume adjustment range from 0 to 100 Speed adjustment range from -20 to +20 Bluetooth headphones Back Settings ► Interface Language English | German | French | Norwegian...
-
Page 26: Description Of 3-Button Remote Control (Bottom-Up View)
Settings ► System Installed Version Installed software Version Camera firmware version Installed Camera Firmware Version +49 6257 9311-0, Reinecker Tel.: /E-Mail: international@reineckervision.de Date todays´ date Software Version Installed software version Available Version IP addresses Updater state Idle Check for updates... -
Page 27: Overview Mode
Overview mode When you are working at a higher magnification level and want to find out which part of the page you have reached, this function helps you to get the overview. To activate overview when reading at a higher magnification level, push and hold the yellow button on the bottom side of the remote, for approx. -
Page 28: Explanation Of Veo Menu Content (System)
Explanation of VEO menu content (system) Main menu Brightness Adjustment range from -50 to +50 Contrast Adjustment range from -50 to +50 Color Saturation Adjustment range from -50 to +50 Main menu ► Ruler / Mask Settings Ruler / Mask Horizontal | align ruler horizontal Vertical | align ruler vertical Mask Mode... - Page 29 Main menu ► Advanced Settings ► Color Combination Setup ► Color Combinations 1-6 Color mode Deactivated | Full Color | Greyscale | False Color Foreground Black | Red | Green | Blue | Yellow | Magenta | Cyan | White | User 1 | User 2 Background Black | Red | Green | Blue | Yellow | Magenta | Cyan | White | User 1 | User 2...
- Page 30 Main menu ► Advanced Settings ► Sharpness Settings Real Color Sharpness Adjustment range from 0 to 24 False Color Sharpness Adjustment range from 0 to 24 Exit Main menu ► Advanced Settings ► OSD Messages OSD Messages ON | OFF Main menu ►...
-
Page 31: Troubleshooting
Troubleshooting Problem Solution There is no image on the Check the main power connection, the cable con- monitor. nection to the monitor or PC, and whether the rele- vant systems are switched ON and working. Image/Screen is (too) Check the brightness and contrast settings of the dark. -
Page 32: Technical Details
Technical details 24“ class high resolution automatic language- Weight approx. 17 kg touch screen recognition (by sentence) Dimensions (B x H x T) (approx. 61 cm) approx. 55 x 53 x 59 cm more than 30 languages diverse display options: with over 100 voices original, overlay, column, included... -
Page 33: Warranty Information
Warranty Information 1. Reinecker Vision GmbH grants a warranty of 24 months against defects in manu- facture counted from the first date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH. -
Page 34: Notes
Notes... - Page 35 VEO VOX ( VEOVOT24 ) Type: Serial number: Manufacturer: Reinecker Vision GmbH Final examination: Power supply: 100 VAC – 240 VAC 50-60 Hz Via plug-in power suppy: 12V DC / 8000mA Power consumption: max. 80 watt...
- Page 36 Reinecker Vision GmbH In case service is necessary, please International Contact contact your authorized distributor. sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311-0 Fax: +49 6257 9311-8230 Email: international@reineckervision.de www.reineckervision.com...
