Summary of Contents for Reinecker Videomatic VEO
- Page 1 User manual Videomatic VEO...
- Page 3 Reinecker Vision GmbH Sandwiesenstraße 19 ·64665 Alsbach-Hähnlein Email: info@reineckervision.de · www.reineckervision.de Wir erklären in alleiniger Verantwortung für alle unsere Systeme, dass diese mit den folgenden Normen oder normativen Dokumenten übereinstimmen. We declare under our so/e responsibility that the systems, which have been brought into the market by us, meet the requirements of the following directives.
- Page 4 Place date of issue...
-
Page 5: Table Of Contents
Disposal of the unit according to EU directive 2002/96/EEC ....9 Power supply ..................10 Safety instructions .................. 11 Instructions for the reading system Videomatic VEO ......12 Delivery content ..................12 The VEO cameras .................. 12 Vario camera: ..................12 Focus camera MD: ................. - Page 6 Description of the 3-buttons remote control unit ........17 Left button: ..................... 17 Central („Zoom“) button: ................. 18 Right button: ................... 18 Turning the unit ON manually ..............19 Bottom-up view: ..................19 Description of the 1-button remote control unit ........20 Central button „Zoom +/-“...
-
Page 7: General Information
Product description Videomatic VEO is an opto-electronic reading system, which magnifies text and pictures. It may be used permanently for private and professional appliance. The text or pictures are being captured by the integrated camera and then displayed on the monitor. -
Page 8: Medical Device
Note: The mentioned life span does not reflect the complete life span of the Videomatic VEO. It is rather an indication on when the product might be obsolete and substitution might be recommended due to new product developments. -
Page 9: Precautions By Alteration Of The Performance Of The System
Stop using the reading device if technical features or performances should change. Switch the device off and disconnect the power supply from the mains wall socket. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Reinstatement and installation This device may be technically maintained and reconditioned by Reinecker Vision GmbH only or by an authorized technician. -
Page 10: Power Supply
Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. Caution: The use of any other equipment might lead to an increased electromagnetic emission and to a product damage. -
Page 11: Safety Instructions
2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. 4. Do not expose the system to direct sunlight or to very hot or cold environment, as this would harm the picture quality. -
Page 12: Ii. Instructions For The Reading System Videomatic Veo
Adapter cable (country-specific) • User manual • Information sheet for repair cases The VEO cameras Videomatic VEO is available in combination with the following three camera types: Vario camera: • magnification from 1x to 100x (independent of monitor size) •... -
Page 14: Insert / Replace Batteries In Remote Control
Insert / replace batteries in remote control The remote control operates on 2 x AA-batteries (1,5V). • Detach the cover on the flipside of the remote control. Put in the batteries and make sure that polarity is correctly matched. • Replace the cover onto the remote control using marginal pressure. -
Page 15: Iii. Installation Of The System
Connect the power supply to a mains wall socket and plug the adapter end of the cord into the DC12V power supply socket located on the base of the Videomatic VEO. Note: The delivered power cable is to be used exclusively in connection with the Videomatic VEO. -
Page 16: Alignment Of Monitor
Alignment of monitor Due to the monitor’s technology contrast and brightness change depending on the angle of view. The highly flexible four-dimensional monitor arm enables the user to adjust the monitors height and angle according to their seated position (see below) Rotatable by 90 degrees... -
Page 17: Alignment Of Xy-Table
Alignment of xy-table The xy-table has two independent friction brakes for the x- and y-axis. The friction can be continuously adjusted from minimum to maximum. The yellow friction brake is used for the x-axis and the black brake for the y-axis. x- and y- axis can be moved into all directions x-axis is locked, y- axis is flexible... -
Page 18: Positioning Of The Remote Control Unit
Accordingly, the user has the opportunity to find the best way of operating the Videomatic VEO based on his personal ergonomic demands. Positioning of... -
Page 19: Description Of The 3-Buttons Remote Control Unit
Description of the 3-buttons remote control unit Frontal view: Colour mode Power ON/OFF, Contrast / brightness, selection zoom +/ -, autofocus* line marker / line cover Left button: Colour mode selection By turning the colour mode selection-button from the left to the right the following colour modes can be selected: Position 1. -
Page 20: Central („Zoom") Button
Central („Zoom“) button: • Power ON/OFF By briefly pressing the “Zoom +/-” button, the video magnifier turns ON. By pressing and holding the „Zoom +/-“-button for approx. 4 sec., the video magnifier can be turned OFF manually . • Zoom + / - By turning the button to the left and to the right the magnification will continuously change from minimum to maximum. -
Page 21: Turning The Unit On Manually
• Line marker / shadowing By pulling out the control button will activate the line marking and shadowing functions. Turn this button to choose the area on the screen to be marked by the line marker or to be covered by shadowing. To deactivate the line marker/shadowing function, push the button back in again. -
Page 22: Description Of The 1-Button Remote Control Unit
Description of the 1-button remote control unit Front view: Power ON/OFF, zoom +/-, colour selection Central button „Zoom +/-“ • Power ON/OFF By briefly pressing the “Zoom +/-” button, the video magnifier turns ON. By pressing and holding the „Zoom +/-“-button for approx. 4 sec., the video magnifier can be turned OFF manually. -
Page 23: Bottom-Up View
OFF OvervieW mode Automatic switch-OFF function Videomatic VEO is equipped with an automatic switch-OFF function. The VEO will automatically switch itself OFF if the remote control of the unit has been inactive for a pre-selected period of time. The automatic turn OFF function can be deactivated or set to one of three possible time frame settings. -
Page 24: Lighting On/Dim/Off
Lighting ON/dim/OFF By pushing the yellow button on the bottom side of the remote control the lighting can be • turned ON • dimmed • turned OFF When turning OFF the VEO the selected level of illumination will be saved. Overview mode When you are working within a higher magnification level and want to find out which part of the page you have reached this function helps you... -
Page 25: Menu Selection
Menu selection Keep the black button (underneath the remote control) pressed for approximately 3 seconds until the main menu appears on the screen. Main Menu Brightness Contrast Color Saturation - 30 Ruler / Mask Ruler / Mask Settings AF Mode* Continuous/Zoom Reset to Factory Settings Recall User Settings... -
Page 26: Explanation Of The Menu Content
Explanation of the menu content The image shows in detail how the menu is structured. Main Menu Menu level 1 Menu level 2 Advanced Settings Menu level 3 Special Settings Menu level 4 Customize Buttons adjustment range | explication Function Menu settings Main Menu adjustment range from -50 to +50... - Page 27 Main Menu Ruler / Mask Settings Ruler Color adjustment range from 0 to 31 adjustment range from 0 to 31 Green Blue adjustment range from 0 to 31 Main Menu AF Mode* Continuous | Semi-Automatic | Semi-Autom. +Zoom | Continuous / Zoom Return to factory settings Reset to Factory Settings Recall User Settings...
- Page 28 Main Menu Advanced Settings Color Combination Setup User colors adjustment range from 0 to 31 User color 1 - Red adjustment range from 0 to 31 User color 1 - Green adjustment range from 0 to 31 User color 1 - Blue adjustment range from 0 to 31 User color 2 - Red adjustment range from 0 to 31...
- Page 29 Overview: Special Settings Zoom Extension Max. Digital Zoom 3.5x Customize Buttons Store User Settings Recall User Settings Reset to Factory Settings Expert Settings Monitor size Auto Return Main Menu Advanced Settings Special Settings ON | OFF Zoom Extension OFF | adjustment range from 1,5x to 15x Max.
-
Page 30: Warranty Information
Warranty Information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH. -
Page 31: Notes
Notes... - Page 33 Type: Videomatic VEO Serial-Number: Manufacturer: Reinecker Vision GmbH Final examination: Power supply: 100 - 240 VAC 50/60 Hz over plug- in power supply: 12V DC/ 5,0A Type: FSP060-DIBAN2 Power consumption: max. 80 Watt...
- Page 34 In case service is Reinecker Vision GmbH necessary, please International Contact contact your autho- sales department, customer relations: rized distributor Sandwiesenstraße 19 DE-64665 Alsbach- Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: + 49 6257 9311-0 Fax: + 49 6257 9311-8230 E-Mail: export@reineckervision.de...
