- Page 1 D D M M X X D D I I M M M M E E R R P P A A C C K K DMX-35 User Guide Please read these instructions carefully before use World-wide Headquarters: 3000 North 29th Ct., Hollywood, Florida, USA, FL 33020 Tel: +1-954-929-1115 Fax: +1-954-929-5560 www.ChauvetLighting.com...
-
Page 2: Dmx Operation
The DMX-35 is a dual function unit. In DMX mode, it is a standard dimmer pack used with par cans to turn them on and off as well as dimming them and a ropelight connector that allows control over all 4 ropelight channels independently. It is also a stand alone 4 channel chase unit.The maximum load per channel is 7 amps. -
Page 3: Slave Mode
CHASE MODE OPERATION When dip switch SW 10 is set in the on position, the DMX-35 functions as a stand alone chaser. In this mode the user has several options that can be selected to customize the chase (see chart below). -
Page 4: Specifications
Specifications: Input Power: 110V, 60Hz Maximum Load: Total: 20 Amps Per Channel: 7 Amps Fuse: 7 Amps, 125V (Please complete for your records) User Informtion Date Purchased: Serial No: ________________ Dealer Stamp Model: DMX-35 Dimmer Pack...
