Zte MF620 Quick Manual

Etisalat easynet HSDPA USB Modem
Quick Guide
NO.55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057 Service Hotline: +86-755-26779999 http://www.zte.com.cn E-mail: mobile@zte.com.cn
Introduction
The etisalat easynet HSDPA USB modem is a multi-mode, 3G USB modem, working in HSDPA/WCDMA/EDGE/GPRS/
GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and
a mobile phone (SMS only), and combines mobile communication with Internet perfectly. It supports data and SMS services
through the mobile phone network, enabling you to communicate anytime and anywhere.
Specification
The following table shows the specification of your device.
Interface Type USB 2.0 high speed
Systems supported Supports most types of laptop and desktop PC.
Operating systems supported Windows XP, Vista, Windows 7, MAC 10.4, 10.5, 10.6
Functions SMS service, data service, applications management, etc.
Network Standards. HSDPA/WCDMA/EDGE/GPRS/GSM
HSDPA: 3.6 Mbps DL
Transmission
WCDMA: 384 Kbps UL/DL
Storage: -40°C ~ +80°C
Temperature
Operation: -10°C ~ +60°C
76mm x 26mm x 11mm (without cap)
Dimension
Weight About 21g
Multi colors indicating the modem working status
LED
Getting to know your device
The following figure shows the appearance of the etisalat easynet HSDPA modem.
It is only for your reference.
1 Indicator
It indicates your modem status.
2 Fornt Cover
It protects the front face of the modem.
3 Modem Cap It protects your modem USB port when it is not used.
4 SIM/USIM Card Holder
This is the subscriber identity module/UMTS subscriber identity
module (SIM/USIM) card slot.
5 USB Connector
Connects your modem to the laptop or desktop computer.
Set up your modem
1) Insert the SIM/USIM card into the USB modem
