LG LB-B2156QC2 Owner's Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. Air Conditioner
  5. LB-B2156QC2
  6. Owner's manual
LG LB-B2156QC2 Owner's Manual

LG LB-B2156QC2 Owner's Manual

Low static hide away type air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIR
CONDITIONER
Please read this manual carefully before operating
your set and retain it for future reference.
TYPE : LOW STATIC HIDE AWAY TYPE AIR CONDITIONER
For single duct low static models
MFL62760203
CALL CENTER
1800-180-3575
(Toll Free)
CLICK
CALL
Regd. Office : LG Electronics India Pvt. Ltd., A Wing (3rd Floor), D-3, District Center, Saket, New Delhi - 110017
www.lg.com/in/support
cac.service@lgepartner.com
www.facebook.com/lgindiapage
www.twitter.com/LGIndiaTweets
To know more about LG, visit www.lg.com
For Corporate/Instutional enquiries,
please write to enquiries@lgindia.com
