Temperature and Humidity Control
Installation, Use & Care Manual
Vinotemp International Corp
17631 S Susana Road Rancho Dominguez, CA 90221
Tel: (800) 777 VINO
Fax: (310) 886-3310
Email: i
nfo@vinotemp.com
Read and save these instructions
WM-CONTROL-SS
www.vinotemp.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Winmate WM-CONTROL-SS
Summary of Contents for Winmate WM-CONTROL-SS
- Page 1 Temperature and Humidity Control Installation, Use & Care Manual WM-CONTROL-SS www.vinotemp.com Vinotemp International Corp 17631 S Susana Road Rancho Dominguez, CA 90221 Tel: (800) 777 VINO Fax: (310) 886-3310 Email: i nfo@vinotemp.com Read and save these instructions...
- Page 2 Temperature and Humidity Control WM-CONTROL-SS 15S-601 is microprocessor-based controller to be connected to the 15S-602 keypad by means of a two-wire cable at a distance of up to 100 ft. It is provided with four relay outputs to control liquid line solenoid valve, evaporator fan (adjusting humidity), and alarm auto-dialer and cellar heater.
- Page 3 2) How to lock and unlock the keys Press until POF is displayed to lock the keys; Press until PON is displayed to unlock the keys. 3) Display During normal operating conditions, the display shows the value measured by the air temperature probe.
- Page 4 3. How to see temperature set-point 1) Press and immediately release SET key, the display will show the set-point. 2) Press again and immediately release the SET key to display the probe value. 4. How to change the set-point 1) Press and hold the SET key until the “°C” or “°F” LED starts flashing and the set-point is displayed.
- Page 5 probe calibration (°) minimum set-point (°) maximum set-point (°) defrost cycle interval time (hour) defrost cycle endurance time (min) temperature alarm type rE: relative to set-point high temperature alarm (°) low temperature alarm (°) alarm recovery differential (°) temperature alarm delay (min) temperature alarm delay on startup (hr) heater set-point...
- Page 6 NOTES: • Use a forced air heater to warm up the wine cellar. • If there is a thermostat on the heater, bypass it or set the thermostat at the highest level. • If the heater runs more than 10 A current, use a 120VAC coil contactor. 13.
- Page 7 2) AIR HANDLER 120V Electrical Wiring (WM-SFCA, WM-SFCH, WM-SFCR, WM-SFCV) CONDENSING UNIT 120V Electrical Wiring (WM-150~450SCUR) - 6 -...
- Page 8 4) CONDENSING UNIT 120V Electrical Wiring (WM-650SCUR) 5) CONDENSING UNIT 120V Electrical Wiring (WM-850SCUR) - 7 -...
- Page 9 6) CONDENSING UNIT 230V Electrical Wiring (WM-1203SCUR) 7) CONDENSING UNIT 120V Electrical Wiring (WM-250~650SCUR-WC) - 8 -...
- Page 10 8) CONDENSING UNIT 120V Electrical Wiring (WM-850SCUR-WC) 9) CONDENSING UNIT 230V Electrical Wiring (WM-1203SCUR-WC) - 9 -...
-
Page 11: Customer Support
Customer Support If you need further assistance, please contact us at: Vinotemp International 17631 South Susana Road Rancho Dominguez, CA 90221 Tel: (310) 886-3332 Fax: (310) 886-3310 Email: info@vinotemp.com - 10 -... -
Page 12: Warranty
Warranty Thank you for choosing a Vinotemp cooling unit. Please enter the complete model and serial numbers in the space provided: Model______________________________________________________ Serial No.___________________________________________________ Attach your purchase receipt to this owner’s manual. 1. Limited Warranty VINOTEMP warrants its products to be free from defects due to workmanship or materials under normal use and service, for twelve months after the initial sale. - Page 13 determined to be faulty and is within the twelve month warranty period VINOTEMP will, at its discretion, repair or replace the unit and return it free of charge to the original retail customer. If the unit is found to be in good working order, or beyond the initial twelve month period, it will be returned freight collect.
