- Page 1 ModieLamp Digital lamp and phase Sequence meter - Low input impedance - Phase sequence testing - Dangerous voltage alarm - 4.5-digit 6000 count LCD resolution - Peak voltage capture mode - Hold voltage reading mode - High accuracy true RMS readings...
-
Page 2: Safety Information
SAFETY INFORMA TION Safety Information To ensure safe operation and service of the ModieLamp, please follow these instructions. Failure to observe warnings can result in severe injury or death. • Ensure that user is competent, qualified and authorised to carry out the required work. -
Page 3: Intended Use
A phase sequence indicator. Intended Use: • Modielamp’s intended use is as a set of test lamps for low voltage neutral and phase identification (polarity testing) on three phase (3ø) and single phase (1ø) systems, overhead lines and underground cables, and for general electrical installation testing and fault-finding. -
Page 4: Part Identification
Disconnect unit before removing cap. Fixed Probe (Options) Flat Spike or Round point (Option) Peg clip CAT IV 300V Charging Kit (option) • 240VAC to USB 5VDC • 12VDC to 5VDC • USB Lead 700mm Long Page : 4 GL McGavin ModieLamp Manual... - Page 5 LOW BATT indicates a battery voltage of less than 2.048VDC. If this is displayed, the ModieLamp must be recharged using the charger provided, or via a computer or vehicle USB port. Place the ModieLamp test probes on to the test points.
-
Page 6: General Instructions
Ensure only appropriately trained and qualified personnel use the ModieLamp. Standard Test-Lamp Usage: The ModieLamp can be used as a standard set of test-lamps with 480VAC, 415VAC, 240VAC and Load-Glow being readily identifiable from the brightness of the incandescent lamps. - Page 7 Use the ModieLamp probes to make contact at the test points. Should the ModieLamp fail to indicate the presence of voltage, it is essential to test the ModieLamp with the Modieprove proving unit immediately. If the...
- Page 8 ModieLamp from the testing points, unscrew and remove one of the lamps from the lamp socket, and re-attach the ModieLamp to the test points. The digital voltmeter (DVM) will now measure the Line to Earth voltage. This should be equal to the nominal Phase-Neutral voltage.
-
Page 9: Continuity Testing
Phase sequence testing Connect the ModieLamp to any 2 phases. Ensure that both the green and orange phase rotation indicator neon lamps light up. Connect lead provided to 4mm socket labelled L2. Connect all 3 connections in the appropriate sequence, e.g.. L1 to Aø... -
Page 10: User Maintenance
USER MAINTENANCE The only user maintenance permitted by the manufacturer is cleaning the ModieLamp outer shell and the replacement of the fuse and lamps with the recommended types. Any other maintenance performed will invalidate the warranty. Lamp Replacement: Lamp type: 25W 240VAC E14 Edison screw Using a small flat blade screw driver undo locking screw (keep safe). -
Page 11: Charging Unit
• 12VDC to 5VDC car adaptor (optional). charge light will indicate unit is charging (unit will automatically turn off). When ModieLamp fully charged, the charge light will turn off. Remove lead and replace sealing plug. Page : 11 GL McGavin ModieLamp Manual... -
Page 12: Section 4 Testing Procedures
SECTION 4 TESTING PROCEDURES PART 4.2 ACCEPTABLE NEUTRAL VOLTAGE CRITERIA ModieLamp can be used to measure the voltage between the Neutral conductor and an independent Earth, following removal of the customer multiple earthed neutral (MEN) link. The acceptance criterion according to this Australian Standard stipulates Neutral voltage levels of 6V, 15V and 32V in Sect: 4.2. -
Page 13: Impedance Method
IMPEDANCE METHOD: Using a ModieLoad unit (available together with, or as a separate item to, the ModieLamp) as a suitable test load between incoming Phase and Neutral conductors following the methodology as for (1) above, the user can obtain an accurate measure of Neutral Impedance by using Chart 1 or Table 1. Loop Impedance can be obtained under the conditions stated. -
Page 14: Part 4.5 Phase Rotation Test
PART 4.5 PHASE ROTATION TEST Phase sequence should be recorded prior to disconnection. Re-connection should be in accordance with the previously recorded direction of phase rotation. Modielamp kit a 1 * Modielamp (Any Model) 1* ModieProve (Lamp Tester) • 1 * Prove test 1 * Recharge Kit •... -
Page 15: Equipment Maintenance
Clean Unit With damp Cloth. May use House hold surface spray on Cloth,(do not direct spray). Do not Submerge in any liquid. CAUTION : Do not open Fuse Cap with power on and leads connected. Deactivate Unit as per procedure before removing cap. Page : 15 GL McGavin ModieLamp Manual... -
Page 16: Postal Address
Lambton NSW 2299 Australia Phone: 02 4952 6304 Phone Int: +61 2 4952 6304 Fax: 02 4956 1054 Fax Int: +61 2 4956 1054 Email: sales@dn.eng.com.au Web: www.glmcgavin.com.au ModieLamp Manual version 4 20130814 © Copyright 2013 GL McGavin Pty. Ltd.
