CYMEDICA Orthopedics QB1 User Manual

For the first time, CyMedica Orthopedics has
combined the following components to provide
advanced rehabilitation technology in a simple, easy-
to-use, and comfortable system for every patient.
Qb1 SYSTeM CoMpoNeNTS
CoNduCTive GarMeNT
• Simple wrap
• Compresses your leg to control
postoperative swelling
• Properly positions the muscle-
stimulating electrodes on your leg
ForM-FiTTiNG riGid braCe
• Protects, supports, and stabilizes
your knee
• Controls your knee's range-of-
motion based on your surgeon's
recommendations
NMeS CoNTroller
• Delivers cutting edge technology
anywhere in multiple short therapy
sessions
• Activates your muscles more
precisely to minimize or avoid
unnecessary pain and discomfort
• Constantly monitors and adjusts
stimulation to optimally deliver
comfortable therapy at a lower power
ask your doctor about the
CyMedica Qb1 rehabilitation
system today!
uSiNG The Qb1
aT hoMe
The QB1 system puts access to accelerated
recovery in your hands through just two functions:
the brace to stabilize and restrict your healing
knee and the NMES stimulation system to combat
muscle atrophy.
poST-op braCe
By wearing your brace throughout the day, you
benefit from both the stability and the control of
range of motion it provides, allowing your knee to
safely heal and regain function.
The brace comfortably secures your knee with
simple straps and, if recommended by your doctor,
can restrict your knee's flexion and extension with
the hinge lock.
NMeS SYSTeM
Unlike the brace, you will only use the NMES
stimulation three times a day for 20-minute
sessions. It's recommended that you do this six
days per week, to achieve best results.
3x
6
20 Min DAYS
PER
PER DAY
WEEK
CYMediCa Qb1 TM
proFeSSioNal-aThleTe rehabiliTaTioN
For everY paTieNT
Quadriceps muscle loss is a consistent
complication after ACL knee surgery but
it CAN be minimized and reversed with
PROVEN NMES technology and rigid
bracing.
While the electrical stimulation may feel unusual,
it should not be uncomfortable or hurt. Your quad
muscles will tense under stimulation for several
seconds, and then relax before another stimulation
round begins.
Each NMES session will follow a few simple steps:
(1) Remove electrode covers.
(2) Plug the controller into the brace connector.
(3) Select the treatment type on the screen as
directed by your doctor.
(4) Dial in the intensity level of both the knee
and thigh areas for a strong but comfortable
stimulation.
(5) Select "Start" to begin the 20-minute session.
(6) When you've finished your treatment session,
disconnect and power off the controller. Replace
the electrode covers.
During your session, you can enjoy passive, seated
activities while the QB1 system performs your
rehabilitation for you!
For more detailed information and an instructional
video, visit www.cymedicaortho.com/patients
Caution: Federal law restricts this device to sale by or on the
order of a practitioner licensed by the law of the state in which
he/she practices to use or order the use of the device.
Please see QB1 User's Manual for a complete
list of device instructions for use, indications,
contraindications, warnings, precautions and
adverse effects for the QB1 system.
1. Risberg et al. (1999). J Orthop Sports Phys Therapy. 29(7): 400-412.
2. Lewek et al. (2002). Clinical Biomechanics. 17(1): 56-63.
3. Snyder-Mackler et al. (1995). JBJS. 77(8): 1166-1173.
CyMedica Orthopedics Inc.
19120 N. Pima Rd., Ste. 135 / Scottsdale, AZ 85255 U.S.A.
customerservice@cymedicaortho.com
Fax: (866) 296-2772 / Phone: (844) CYM-2014 or (844) 296-2014
QB-0065-003 Rev.B
aCl repair
NeuroMuSCular STiMulaTioN braCiNG SYSTeM
rehab
like a pro
