Bioenno Power SC-122030WM MPPT Series User Manual
SOLAR CHARGE CONTROLLER WITH MAXIMUM POWER POINT TRACKING
THIS CONTROLLER IS FOR USE WITH LITHIUM IRON PHOSPHATE BATTERIES ONLY
OVERVIEW
Thank you for choosing the Bioenno Power SC-122430WN Series MPPT Enhanced Solar Charge
Controller. Your product comes in 30A Maximum Load Current and is designed to be used with Lithium
Iron Phosphate (also commonly known as LiFePO4 or LFP) batteries only. The controller uses our
proprietary CC/CV Constant Current/ Constant Voltage circuitry to ensure maximum compatibility and
performance with Bioenno Power battery. Your Solar Charge Controller makes use of MPPT Maximum
Power Point Tracking technology and is compatible with a multi-panel solar set-up and additionally
features our smart technology chipset which allows your Solar Charge Controller to automatically
function at the correct mode of operation.
SPECIFICATIONS
Rated Voltage: 12V/24V
Maximum Load Current: 30A
Input Voltage Range: 12V~24V/24V~40V
Float/Absorption: 13.7V~14.4V/27.4V~28.8V
Load Disconnect: 10.5V~11V/ 21V~22V
Efficiency: 95%~97%
Operation Temperature: -13°F ~ 131°F (-25°C ~ 55°C)
Dimensions: 7.6 in. x 4.3 in. x 2 in. (193 mm x 109.2 mm x 55 mm)
Weight: 1.4 lbs. (0.6 kg.)
Advertisement
Related Manuals for Bioenno Power SC-122030WM series
Summary of Contents for Bioenno Power SC-122030WM series
- Page 1 CC/CV Constant Current/ Constant Voltage circuitry to ensure maximum compatibility and performance with Bioenno Power battery. Your Solar Charge Controller makes use of MPPT Maximum Power Point Tracking technology and is compatible with a multi-panel solar set-up and additionally features our smart technology chipset which allows your Solar Charge Controller to automatically function at the correct mode of operation.
- Page 2 OPERATION 1) Make sure the total rated current of the solar panel and loads are less than the rated current of your Solar Charge Controller – in this case your maximum current is 30A 2) Make sure the polarity of the wiring from your panel, battery and load correctly match the polarity of the screw terminals on you Solar Charge Controller 3) Mount you Solar Charge Controller to your selected surface and fasten it securely using screws 4) Check whether the battery voltage and solar panel array voltage is within the requested range...
- Page 3 the load or wing...
