JDW CE124 Safety And Operating Manual

Petrol 99cc lawn mower
Hide thumbs

Advertisement

Table of Contents

Petrol 99cc Lawn Mower
Model: CE124
SAFETY AND OPERATING MANUAL
ASSEMBLY REQUIRED
Please read & understand this manual, paying particular attention to the safety instructions before use.
We reserve the right to change the product specification & livery according to continued product improvements.
1938108001 10-08-16

Advertisement

Table of Contents
loading

Related Manuals for JDW CE124

Summary of Contents for JDW CE124

  • Page 1 Petrol 99cc Lawn Mower Model: CE124 SAFETY AND OPERATING MANUAL ASSEMBLY REQUIRED Please read & understand this manual, paying particular attention to the safety instructions before use. We reserve the right to change the product specification & livery according to continued product improvements.
  • Page 2 CONTENTS SPECIFICATION COMPONENT SAFETY INSTRUCTIONS ASSEMBLY OPERATION MAINTENANCE TROUBLE SHOOTING GUARANTEE DECLARATION OF CONFORMITY SPECIFICATION Model CE124 Product No. 1938108001 Engine T100 4-stroke OHV 99cc Engine Power 1.5kw Engine Speed 3000rpm Cutting Width 398mm (16”) Height of Cut 25-75mm Height Adjustments...
  • Page 3 COMPONENTS 1. OPC Operating Lever 2. Handle Knob 3. Fuel Filler Cap 4. Air Filter 5. Primer Bulb 6. Spark Plug 7. Exhaust 8. Oil Filler Cap/Dipstick 9. Height Adjuster Handle 10. Grassbox 11. Recoil Handle Carefully remove the machine from its packaging and check that you have all the components. If parts are missing or damaged, please contact our Customer Service Team on 0871 231 2000...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS FOR FUTURE USE WARNING Read this instruction carefully before operating this lawn mower. Make sure that you are familiar with the controls and properly operate the machine. Following these instructions can reduce the risk of fire, electric shock and personal injury.
  • Page 5 INTENDED USE THE LAWN MOWER IS DESIGNED FOR DOMESTIC USE ONLY. Lawn mowers for domestic use are mowers whose annual use does not generally exceed 50 hours and that are primarily used for tending GRASS OR LAWN AREAS, but not in public facilities, parks or sports grounds and not for agricultural or forestry use.

  • Page 6: Operation

    OPERATION Do not operate the engine in a confined space where dangerous carbon monoxide fumes can  collect. Only operate the mower in daylight or in good artificial light.  Avoid operating the equipment in wet grass.  Always be sure of your footing on slopes. ...

  • Page 7: Maintenance And Storage

    MAINTENANCE AND STORAGE Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition.  Never store the equipment with petrol in the tank inside a building where fumes can reach an  open flame or spark. Allow the engine to cool before storing in any enclosure.

  • Page 8: Assembly / Pre-Operation

    ASSEMBLY ASSEMBLY/PRE-OPERATION Read these instructions in its entirety before you attempt to assemble and operate your new lawnmower. IMPORTANT: The lawn mower is shipped WITHOUT OIL OR PETROL in the engine. Your new lawn mower has been assembled and tested at the factory and therefore a very small residue of oil could be noted.
  • Page 9 You may now need to fit the clutch/brake cable to the brake handle. Remove the brake handle from the left side of the main handle (Fig. 3) by applying pressure to the brake handle. You will now be able to fit the clutch/brake cable to the hole of the brake handle (Fig. 4). Next feed the recoil starter rope and handle into the pigtail holder, located on the right side of the handle assembly (Fig.

  • Page 10: Rear Discharge

    To fit the front and rear wheels remove the nut and outer washer from the front axle. Put the smaller front wheel, washer and locking nut onto the front axle and tighten the nut with a spanner, Do not over tighten, this may stop the wheel rotating (Fig. 8). Place the larger rear wheel onto the rear axle and put a split pin into the hole in the rear axle (Fig.

  • Page 11: Add Petrol

    OPERATION CAUTION - YOUR LAWNMOWER IS SHIPPED WITHOUT OIL IN THE ENGINE BEFORE STARTING THE ENGINE, ADD OIL Before each use the oil level must be checked and if necessary the machine should be topped up with SAE30 4-stroke lawnmower engine oil. The oil level must be between the upper and lower limit marks of the dipstick as shown below.

  • Page 12: Starting The Engine

    STARTING THE ENGINE To start the engine, first make sure that the spark plug is in place, spark plug cap is secure and the machine is filled with sufficient oil and petrol. NOTE: Due to the protective coating on the engine, a small amount of smoke may be present during the initial use of the product and should be considered normal.

  • Page 13: Blade Maintenance

    MAINTENANCE IMPORTANT - Regular, careful maintenance is essential for keeping the safety level and original performance of the machine unchanged over time. 1. Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition. Regular maintenance is essential for safety and performance.

  • Page 14: Change Oil

    CHANGE OIL 1. Let the engine run out of petrol, and wait until the engine has stopped and cooled down. 2. Disconnect the spark plug cap and remove the spark plug. 3. When the engine is still warm, remove the oil drain plug (A). Drain the oil into an appropriate container.
  • Page 15 AIR FILTER Unclip the air filter cover and remove the sponge filter element, inspect the filter for cleanliness and damage, if necessary please replace. DRAINING THE FUEL TANK AND CARBURETTOR 1. Place an approved petrol container below the carburetor, and use a funnel to avoid spilling fuel. 2.

  • Page 16: Maintenance Schedule

    MAINTENANCE SCHEDULE Every REGULAR SERVICE PERIOD First Every 6 Every Before Every 3 Perform at every indicated month Month Months Year or Each Months or Years or or operating hour interval, 100hrs 25hrs Use 250hrs whichever comes first. 5hrs Use 50hrs Use Check Engine oil...

  • Page 17: Troubleshooting

    TROUBLE SHOOTING ENGINE WILL NOT START POSSIBLE CAUSE CORRECTION Out of fuel. Refuel Bad fuel; engine stored without 1. Check fuel. Drain the fuel tank and carburetor. treating, draining petrol or Refuel with fresh petrol. refueled with bad petrol Spark plug faulty, fouled, or Replace the spark plug.
  • Page 18 GUARANTEE JDW guarantees this product against manufacturing defects. We will repair (or replace at our option), if a manufacturing defect occurs within the guarantee period as long as it has only been subjected to domestic use. For the purpose of this guarantee, domestic use means any use of the product on the property belonging to the purchaser and forming part of the garden area of his/her dwelling.
  • Page 19 CONFORMS TO EUROPEAN STANDARDS Machine type: Petrol Lawn Mower Machine model: CE124 Mass in kg: 21.8 kg Cutting Diameter: 398mm Rated Power: 1.5KW This machine conforms to EU Machinery-Directive 2006/42/EC, to which this declaration relates & corresponds to the relevant basic safety and health requirements of Directive:...
  • Page 20 Customer Service Team: 0871 231 2000 Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
