B
P
E
B
P
E
Photo Beam with battery
powered Transmitter
Not UL325 compliant
Operating Instructions
This product is an accessory or part of a system.
Always read and follow the manufacturer's
instructions for the equipment you are connecting
this product to. Comply with all applicable codes and safety
regulations. Failure to do so may result in damage, injury or
death!
Product Overview
™
-
5
0
-
5
0
The BPE-50 photo beam system uses 12 -24 VDC/AC on
the transmitter and receiver with the transmitter offering the
option of using the two 3.6 Volt batteries for power
(included).
ERAA 3V6 2400
WARNING ...
Never use product as sensing devices for personnel protection.
Doing so could cause serious injury or death.
These sensors do NOT include the self-checking redundant circuitry
necessary to allow their use in personnel safety applications. A sensor failure or
malfunction can cause either an energized or de-energized sensor output
condition. UL 325 Non-compliant
Technical Specifications
Power Supply
Current Draw
Relay Type
Temperature
Wavelength
Frequency
Environmental
Detect Indicator
Connector
Relay contact
Housing Material
Size
Range
Detection Angle
Sensitivity
Detection delay
Reset delay
Recommended battery replacement is the
.
Not to be used for Personnel Protection
12-24 VDC 24 VAC (2-3.6 Volt Lithium
Batteries for transmitter optional
/included)
Expected battery life up to 2 years
approx.
RX = <50mA standby 100mA activated, TX
= < 500uA
2 Form C DPST contact rating .5A @ 24VDC
/ 120VAC
-20C – 55C
880 nm
High 90 Hz Low 48 Hz (Ext power 787 Hz)
IP 65
Red LED
Terminal block
0.5Amp
PA6 30% FG
H 4.4in (112mm) x W 2.05in (52mm) x D
1.3in (33mm)
Up to 50 feet (if TX on 12/24 V 90 feet)
+/- 5%
Jumper J1 on receiver
< 30 ms
< 120 ms
Connections
(Fig 1)
Transmitter
1
Power Positive (+)
2
Power Negative (-)
Varta
3
NC Security Contact
(join if not used)
4
Security edge
(join if not used)
5
Security edge
(join if not used)
Terminal connection as viewed from the front, left to right
Receiver
Power Positive (+)
Power Negative (-)
Internal Relay
Normally Open
Internal Relay
Common
Internal Relay
Normally Closed Output
