- Page 2 Hello! Thank you for choosing the CreativeXP products. Your recognition & support is our motivation and it is our greatest pleasure to serve you! Before using the rearview mirror CAR DVR, please read this guide carefully. In addition, due to production date, different batches, instructions may differ from the actual use of the product.
-
Page 3: Product Specifications
Product specifications MODEL LANGUAGE XP PRO1 12 languages IMAGE JPEG format; 12M VIDEO FORMAT Front and rear SCREEN SIZE CAMERA LENS 5.0 inch Front 170°/ Rear SHOOTING ANGLE LENS APERTURE 140° F2.0 MSC8328P Dual core PROCESSOR CORE NUMBER Maximum support... -
Page 4: Product Overview
II. Product Overview 1. Power button • Hold the power button to turn ON/OFF • When connected to charger - automatic start • Disconnect the charger - 8 seconds automatic shutdown 2. Menu button • It is used to switch between the available mirror dash cam main functions of the recorder: the video interface, the photo interface, and the file view interface. - Page 5 4. UP button • Upward selection • Adjust the volume of the recorder 5. DOWN button • Downward selection • Adjust the volume of the recorder 6. Power USB interface • A power supply interface inserted into a car or a step-down line 7.
- Page 6 III. A step-by-step Installation Guide 1.Turn off your vehicle engine. 2. Insert the MicroSD card into the slot. ***Please use the high-speed SD card (Class 10 and above), capacity not less than 512M. MicroSD card maximum support 64GB. 3. Fix the mirror to the original car rearview mirror, using the included rubber straps. 4.
- Page 7 ***Charger extension line can lay along the edge of the windshield when wiring or can be tucked in. 6. The backup camera is installed in the rear of the vehicle. Pay attention to the direction of installation. Wiring can be positioned along the vehicle roof or through the car and trunk.
- Page 8 5. Does this mount over existing rearview mirror or replace existing mirror? A: The HD Mirror Dashcam Pro1 will mount over the existing rearview mirror in most cases and it's much easier this way. Some of our customers who had very big existing mirrors replaced them with our mirror dashcam but they had it done professionally.
- Page 9 13. Does it record front and rear at the same time or just record when I’m going forward or reverse it? A: Our HD Mirror Dashcam Pro1 will record both front and rear at the same time (not only when you reverse it) but the backup camera appears on the screen when you reverse if you connected the camera cable to the rear lights.
- Page 10 15. Does the backup screen view pop out automatically in the mirror when engaging reverse? A: Yes, it will pop out automatically if you hook up the rear camera cable to the reverse lights - the power in them will cause the rear camera to automatically pop out on the screen for parking assistance.
- Page 11 19. What is the highest temperature this camera can handle? A: The highest temperature our dash camera can handle is around 110 F. We recommend not letting it on the windshield every day during summer because the battery will lower its performance over time. 20.
