- Page 1 All-in-one Handheld Ground Station User Manual v 1.1 2018.03...
-
Page 2: Table Of Contents
INDEX Disclaimer ........................1 Cautions .........................1 Installation note ...................... 1 Precautions for Use ....................1 Introduction ........................2 Check List ........................2 Product Diagram ......................3 Receiver parts ......................3 Remote Controller Parts ..................4 Receiver Installation Guide .................5 Remote Controller Operation ................6 Tablet Computer Power ON and OFF ............. -
Page 3: Disclaimer
Cautions When using the T20, if it is not operated properly, the aircraft may cause a certain degree of injury or damage to property. Please be careful when using it. Installation note 1. -
Page 4: Introduction
Introduction T20 is a water, sun & shock resistant handheld ground station that integrates an industrial-grade computer with Windows system and an integrated link remote control system.The transmitter can be used to control the aircraft or a gimbal with real-time flight and remote status feedback, route planning, and other functions. It supports most of the ground station software on the market. -
Page 5: Product Diagram
Product Diagram Receiver parts ⑥ ⑦ ⑧ ③ ② ① ④ ⑤ ①Power port Use XT30 power plug，Supply voltage：7.4-12V ②S-BUS port Use a servo wire to connect the S-BUS port of a flight controller or other equipment ③COM port The COM port is TTL ,used to connect to the COM or API port of a flight controller ④Signal strength indicators S1 S2 S3 are signal strength indicators ⑤Data transmission indicator... -
Page 6: Remote Controller Parts
Remote Controller Parts ⑤ ⑥ ⑦ ⑧ ⑩ ⑨ ④ ③ ⑪ ② ⑫ ① ① Remote Controller ② ③ Computer Power Indicator Joystick Power Button Indicates computer power and Control flight status (There are 4 joystick Turn on and off the whether it is charging modes that can be setup by built-in remote controller... -
Page 7: Receiver Installation Guide
Receiver Installation Guide Tighten and install the antenna to the transmitter SMA connector. 2. Fix the transmitter to the plane, with the antenna vertically down TX GND RX Flight Controller S-BUS TXGNDRX DC:7.4~12V Figure 1-1 3. As shown in Figure 1-1, use the servo wire to connect the COM port and S- BUS of the transmitter with other devices. -
Page 8: Remote Controller Operation
Remote Controller Operation Tablet Computer Power ON and OFF 1. Press and hold the computer power button.When you see the startup screen, release the button. 2. After the computer is turned on, you can check the remaining power through the battery indicator in the lower right corner of the desktop. If the power is less than 20%, please charge it in time. -
Page 9: Remote Controller & Receiver Indicators
Remote Controller & Receiver Indicators Remote Controller Indicators Indicator Prompt tone Status Boot Successfully Solid Red D-long tone Shutdown Successfully Red goes out D-long tone Low Battery Alarm Flashing Red D-D-D... Receiver Indicators Indicators Status The receiver and remote controller are Flashing Blue connected successfully The receiver is currently in configuration... -
Page 10: Remote Control Assistant Software Operation
Remote Control Assistant Software Operation Channel monitoring and calibration Figure 1-2 1. Turn on the remote controller and computer power button, and then open tablet remote control assistant software. 2. Figure 1-2 is the monitor interface. Toggle each switch or joystick to check if they are working. -
Page 11: Channel Configuration
Channel configuration Figure 1-3 1. Click on “Function” button. The channel configuration interface is shown as figure1-3. CH01-CH04 are default flight channels and CH05-CH14 are auxiliary channels 2. The configuration of REVERSE, SUB-TRIM and END POINT are the same as common remote controller setting method.（Please refer to FUTABA remote controller setting）... -
Page 12: Receiver Pairing And Configuration
Receiver pairing and configuration Figure 1-4 1. As shown in figure 1-4，Before the receiver is powered on, long press the SET button with a pin until the L2 indicator lights up solid blue, and then release. 2. As shown in figure 1-5，connect the receiver and remote controller using the equipped configuration cable. - Page 13 3. Turn on the remote controller and open the assistant software. Click on“Link” button, then the interface will be shown as in Figure 1-6. Figure 1-6 4. When changing any value of remote controller or receiver, the corresponding receiver or remote control value will change too. “Change ID”：The receiver and remote controller IDs will be changed randomly at the same time after clicking this button.
-
Page 14: Remote Controller Charging
Receiver Parameters Modification Name Value Comment method Unique ID code for pairing Device ID Random 0-65535 between receiver and remote controller 1200、2400、4800、 This baud rate setting needs to Serial baud Manually 9600、 be set according to the required 19200、3400、57600、 rate baud rate for the flight control modify 115200... -
Page 15: Faq
1：Q: When pressing the remote controller power, there is no “beep” boot sound and the power indicator only flash red one time. Please confirm whether the tablet has enough battery. 2：Q: Receiver powers up normally but there is no signal output. Please make sure the ID, channel, and airspeed of the receiver are set to be the same as the ones of the remote controller.
