Axe-Fx III SETUP: MIDI/Remote

To remotely control the Axe-Fx III via MIDI commands of the MFC-101, the MIDI
channel on which the MIDI communication takes place must be defined. Likewise,
all control units you want to address must be assigned corresponding (unique)
Control Change Numbers (CC#). Up to 127 unique CC`s# can be assigned. By
default, they are all off (NONE), because there are many more entries in the Axe-
Fx III than the 127 that can be assigned. Here is my suggestion for a default CC#
assignment and further settings, which should normally be sufficient to control the
Axe-Fx III without conflicts with the MFC-101. All 127 possible uniquen CC# were
STEP 1: Axe-Fx III: SETUP -> MIDI/Remote Menu
General
GENERAL
MIDI Channel 1
Display Offset 1
Scene Revert ON
Eff. Bypass Mode VALUE
PC CONFIGURATION
Program Change ON
Ignore Redundant PC ON
Send MIDI PC OFF
MIDI PC Offset 0
PC Mapping OFF
Initial Value 100% for External Control 1: External Control 1 I use for the expression pedal, which controls the volume of the VOLUME 1 block. This Block is always placed
between amp block and post amp effects such as delay and reverb and is always active. My "Master Volume" pedal. That's why I didn't give a CC# entry for VOLUME1 BYPASS,
because it is always active and is not switched on or off.
[Axe-Fx III Manual: 12 Setup Menu | THE MIDI/REMOTE
General
INITIAL VALUE
External Control 1 100%
External Control 2 0%
External Control 3 0%
External Control 4 0%
External Control 5 0%
External Control 6 0%
External Control 7 0%
External Control 8 0%
External Control 9 0%
External Control 10 0%
External Control 11 0%
External Control 12 0%
External Control 13 0%
External Control 14 0%
External Control 15 0%
External Control 16 0%
assigned. If you need CC# for other entries, you can of course adapt the CC#
assignment to your individual needs.
Under SETUP -> Global Settings -> Config -> I recommend
to set default Scene to 1.
MENU]:
External CC#
External Control 1 1
External Control 2 2
External Control 3 3
External Control 4 4
External Control 5 5
External Control 6 6
External Control 7 7
External Control 8 8
External Control 9 9
External Control 10 10
External Control 11 11
External Control 12 NONE
External Control 13 NONE
External Control 14 NONE
External Control 15 NONE
External Control 16 NONE
Looper CC# Other
Record 123 Tempo Tap
Play 124 Tuner
Undo 125
Once 126 SCENE
Reverse 127 Scene Select
Scene Increment
Scene Decrement
I/O
Input 1 Volume
Input 2 Volume
Input 3 Volume
Input 4 Volume
Output 1 Volume
Output 2 Volume
Output 3 Volume
Output 4 Volume
CC#
13
120
15
NONE
NONE
NONE
NONE
NONE
NONE
121
NONE
NONE
NONE
