Channel Vision IR-1204 User Manual

How IR repeating works
The IR receiver is wired to
the IR hub which routes the
signal to IR emitters
Point an
IR remote control
at the IR receiver
CD player
And the emitter
repeats the IR signal
in front of the component.
Be sure the emitter is attached directly over the component's IR receiver.
To locate the IR receiver, shine a flashlight into the unit and look for the
sensor.
CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in material or
workmanship which occurs during normal use of this product with new or rebuilt
parts, free of charge in the USA, for one year from the date of original purchase.
This is a no hassle warranty with no mail in warranty card needed. This warranty
does not cover damages in shipment, failures caused by other products not
supplied by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only to the
original purchaser, and a purchase receipt, invoice, or other proof of original
purchase date will be required before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-
0288 toll free. A Return Authorization number must be obtained in advance and
can be marked on the outside of the shipping carton.
This warranty gives you specific legal rights and you may have other rights
(which vary from state to state). If a problem with this product develops during or
after the warranty period, please contact Channel Vision Technology, your dealer
or any factory-authorized service center.
Specifications
Specifications: (typical)
Power Supply Voltage: 12 VDC 500mA Regulated
IR Freq. range supported: 36 kHz - 60 kHz
Maximum IR receivers: 6
Dimensions: 1.10" x 1.03" x 4.25"
IR emitter outputs: 3
Color: Black
Specifications subject to change without notice.
Expansion/Receiver
Inputs
The potentiometerl Adjusts the
Signal strength of the
top left emitter. Turning clockwise
lowers signal strength while turning
counter clockwise strengthens the
signal.
Features:
! 3 IR emitter outputs
!
Adjustable emitter signal
!
Status LEDs for power and IR signal indication
! Screw terminal or mini-plug connections for IR receivers
!
Easily mounts to any flat surface
500-401 rev A
Up to 1000'
(tested with CAT-5e)
IR-2401
The IR-1204 includes these items:
IR-1204
LED Status Indicators:
Power and IR data
DC Power Input
3 IR emitter outputs
Typical Operation
Power LED
IR data LED
Power supply
Using IR-3002,
up to 6 IR emitters
may be controlled
