18V Li-ion Cordless Leaf Blower
Assembly Manual
Y0R-SP01-120
Important
- Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from your cordless
blower, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 0845 034 2279
prior to returning product to store.
May 2013 Rev A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Qualcast Y0R-SP01-120
Summary of Contents for Qualcast Y0R-SP01-120
- Page 1 Qualcast 18V Li-ion Cordless Leaf Blower Assembly Manual Y0R-SP01-120 Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your cordless blower, ensuring it is assembled correctly and safely.
-
Page 2: Table Of Contents
Contents Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols Safety Information .............................3 Warning Symbols ............................3 The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembling and operating the blower. General Safety ..............................3 This symbol indicates there is a danger of serious personal injury or death if you do not observe the Personal Safety ............................3... -
Page 3: Parts
In the Box Assembly Parts Preparing to Assemble the Blower WARNING! Always take care when removing the packaging to prevent damage to you or to the Blower Charger Station Charger (shared Battery Pack blower. (shared with hedge with hedge trimmer) (share with hedge Blower Tube trimmer) -
Page 4: Step 2 - Charging The Battery Pack
Assembly Assembly Step 2 - Charging the battery pack Step 2 - Charging the battery pack (continued) 1. Plug the charger into an appropriate AC power outlet. The green LED light comes on indicating the charger is ready for use. 2. -
Page 5: Step 3 - Using The Battery Pack
Assembly Step 3 - Using the battery pack To fit the battery pack 1. Place battery pack in your blower. Align raised rib on battery pack with groove inside the blower. 2. Make sure the latches on each side of your battery pack snap in place and battery pack is secured in blower before operation. - Page 6 Qualcast 18V Li-ion Cordless Leaf Blower Operation and Maintenance Manual Y0R-SP01-120 Important - Please read these instructions fully before operating or maintaining your blower. These instructions contain important information that will help you get the best from your cordless blower, ensuring it is assembled correctly and safely.
- Page 7 Contents Safety Information Important - Please read these instructions fully before operating or maintaining Warning Symbols on the Unit Safety Information .............................3 Warning Symbols on the unit ........................3 The following warning symbols appear through this manual and indicate the appreciate safety measures you should take when operating and maintaining the blower.
-
Page 8: Safety Information
Safety Information Safety Information Important - Please read these instructions fully before operating or maintaining Important - Please read these instructions fully before operating or maintaining Warning Symbols on the charger General Safety WARNING! Keep this operating and maintenance manual in a safe place for furture reference. Warning! WARNING! Read the instructions carefully. -
Page 9: Personal Safety
Safety Information Safety Information Important - Please read these instructions fully before operating or maintaining Important - Please read these instructions fully before operating or maintaining Personal Safety Operation Safety a) Be certain the parts are fully tightened before operating the tool. Check it periodically for a) Use personal protective equipment(PPE). -
Page 10: Maintenance And Storage
Safety Information Operating the Blower Important - Please read these instructions fully before operating or maintaining Step 1 - Switch on /off Maintenance and Storage WARNING! Always wear goggles and sound barriers(ear plugs or ear mufflers) when doing any work on the blower. a) Maintain tools with care. -
Page 11: Step 2 - Blowing
Operating the Blower Maintenance and Repair Step 2 - Blowing Maintenance and Repair Blowing WARNING! Always switch the product off, disconnect it from the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! 1). Before blowing,loosen leaves that are stuck to the ground using a broom or rake. 2). -
Page 12: Troubleshooting
Troubleshooting Technical Data General Troubleshooting Appliance WARNING! Only perform the steps described within these instructions! Voltage……………………………………………………………………….....………...18V DC All further inspection, maintenance and repair work must be performed by an authorised Max. Air speed……………………………………………………………....……………125 mph Service centre or a similarly qualified specialist if you cannot solve the problem yourself! Battery type……………………………………………………………………….…………….....Li-ion Battery capacity………………………………………………………………………....…..1.5Ah Suspected malfunctions, disturbances or damages are often due to causes that the user can fix... -
Page 13: Recycling And Disposal
Recycling and Disposal Guarantee Disposal Instructions 1. Recycle unwanted materials instead of disposing of them as waste. All tools, hoses Dear Customer, and packaging should be sorted, taken to the local recycling centre and disposed of in an In the unlikely event that your device develops a fault, please contact our Customer service environmentally safe way. -
Page 14: Declaration Of Conformity
We hereby certify that the product stipulated above complies with all the relevant provisions of the following EC new approach directive/s. This declaration of conformity is issued under the sole responsibility of the manufacturer Type of Product: 18V Li-ion leaf blower Model Number: Y0R-SP01-120 Cat / Article Number: 206662 Product Description: 18V DC,1500mAh Li-ion Photograph: battery pack ,Max.
