- Page 1 V51 Kingguard User Manual Shenyang VS DIGITAL Technology Development CO.,LTD Website ： www.vsdigital.com Tel:+86-24-24500650 Website: www.vsdigital.com...
-
Page 2: Table Of Contents
1.4 Entry Checkpoint Tag in Software .........13 1.5 How to replace battery ............16 Part Two FAQ..................17 2.1 Can not read tag................ 17 2.2 Can not connect with the computer........17 2.3 Clock is inaccurate..............17 2.4 Can not read after changing battery........17 Tel:+86-24-24500650 Website: www.vsdigital.com... -
Page 3: Read Tag And Checkpoint Installation
Led light Read tag head Read tags: let reader head <1>side touch checkpoint tag,get vibration and blue LED flash <2> indication,it means read tag successfully.data has been record. Please do not read the same tag within one minute. Tel:+86-24-24500650 Website: www.vsdigital.com... - Page 4 V51 Kingguard Indication information prompt meaning remark Blue light flash with vibration Data read&recorded Normal successfully Blue light flash Read successfully Read same tag within a but not recorded minute Red light flash with vibration Low power, data can Replace battery ASAP...
-
Page 5: Download Patrol Data
Transmit data with IP downloader (GPRS or Ethernet downloader) * Set IP-downloader 1.Insert SIM card in GPRS IP-downloader and connect it and PC with the IPDL cable. 2.double click on your PC and then click , choose the IPDL-II as the following picture shows. Tel:+86-24-24500650 Website: www.vsdigital.com... - Page 6 6.Please insert into this IP and port : IP :112.124.102.106 Port:50002 7.APN setting:please contact your SIM card provider. All these setting is take web-based software as an example.if you are using other version software please insert your own IP and port. Tel:+86-24-24500650 Website: www.vsdigital.com...
- Page 7 3. Insert V51 into downloader then data will transferred to the online software actively. 3.Transmit data with rj45 downloader * Set RJ45-IP-downloader 1. please connect IP downloader with PC via IPDL cable only. 2. Plz click 2.double click on your PC and then click , choose the IPDL-II. Tel:+86-24-24500650 Website: www.vsdigital.com...
- Page 8 * Download data with RJ45 IP-downloader 1. Plz disconnect the red set cable. 2. Plug the round head power cable as well as the net cable 3. After scan tags, insert v51 into downloader then data will be uploaded. Tel:+86-24-24500650 Website: www.vsdigital.com...
-
Page 9: Entry Checkpoint Tag In Software
4 Entry Checkpoint Tag in Software 1. Login www.onlineguardpatrol.com with your company account. 2.Set site 1.Click the , you can set several sites according your needs. 2.Click the “Update”, then data saved. 3. Generated sites show here. Tel:+86-24-24500650 Website: www.vsdigital.com... - Page 10 1.Choose the site that you want to input the data. 2. Insert V51 into downloader. 3.“ Then Click then data in V51 will upload to the software 4.You need to choose the tag you hope it show on the online software. 5.Then click to generate. Tel:+86-24-24500650 Website: www.vsdigital.com...
-
Page 11: How To Replace Battery
AAA size alkaline batteries, easily purchase and replace. It supports about one year work, Or use more durable battery ER18505,open the V51 back-cover with the included small pipe,find the battery clamp(only for 3AAA alkaine battery) and replace the battery in right position. Close the back-cover again. Tel:+86-24-24500650 Website: www.vsdigital.com... -
Page 12: Part Two Faq
1, Make sure the internal clock is accurate each time after battery replacement, and especially the first time you use the system, meanwhile pay attention whether the time show on your computer is accurate. 2, Please don’t read the same tag in very short time(one minute). Tel:+86-24-24500650 Website: www.vsdigital.com...
