- Page 1 MP50 asics MODEL CONTROLLER/COMPRESSOR PATENT PENDING Instruction Manual Part No. 95258 2-15-10 P.O. Box 3726 Ann Arbor, MI 48106-3726 USA 1-800-624-2026 Fax (734) 995-1170 info@qedenv.com www.qedenv.com...
- Page 3 MP50 Basic Setup Pump Air Supply Pump Discharge Well Optional MP50 MP30 Drawdown Controller Meter Tubing Well Wizard Bladder Pump...
-
Page 4: Table Of Contents
Contents Topic Page Safety Warnings Conventions and Diagrams Introduction / Quick-Start Bladder Pump Operation in Low-Submergence Applications Turning the MP50 On Opening Display MicroPurge Mode Using CPM Sampling Use with the MP30 Level Sensing Water Level Meter ID Mode User Time Set (MN) Mode... -
Page 5: Safety Warnings
Do not over pressurize your controller. Failure to operate the controller within the pres- sure limits could result in failure. Read all operating instructions before operating the MP50 controller. - Page 6 Diagrams / Conventions Diagrams And Conventions Used In The Text (Cont.) MP50 Control Keys: In MP Mode In Other Modes Cycle Per Minute key - Changes Scrolls cursor cycle per minute MicroPurge Basics Controller MP Micro Purge MN Manual Time Set...
- Page 7 Diagrams / Conventions Diagrams And Conventions Used In The Text (Cont.) MP50 Display: Time Refill time ID for time remaining setting in settings in the cycle seconds 00.1 10.0 Discharge time setting in >05.0 MP CPM4 seconds Cycles per The mode the...
-
Page 8: Introduction / Quick-Start
Use of the MP50 with the MP30 is detailed later in this manual. Insert Batteries: Remove the battery cover on the top of the MP50. Insert 3, AA alkaline bat- teries into the battery holder and carefully replace the holder in the carrier. Replace the battery cover and tighten the 4 screws. - Page 9 Note: An option to use an external air source is built into the MP50. To use external air source (rather than the built-in air compressor) simply connect the air source to the “Air In” port.
-
Page 10: Bladder Pump Operation In Low-Submergence Applications
In wells in which this water column height is 5 feet or less, the pump is considered to be in a low-submergence application. QED sampling bladder pumps fill by hydrostatic pressure. As the inside of the pump's bladder fills with water, the bladder expands. This filling and expanding of the bladder is referred to as the "refill"... -
Page 11: Turning The Mp50 On
The MP50 displays an opening screen for 5 seconds, after which it displays the default Micro- Purge screen. At this point the MP50 is in MicroPurge mode (MP) but not cycling the pump. This initial state allows the user to adjust time and throttle settings before the pump starts to operate. -
Page 12: Micropurge Mode
MicroPurge Mode Most MP50 users will leave the controller in the default MicroPurge (MP) mode. See Figure 2 for an example of the MP50 in MP mode. MP mode lets you to use the UP and DOWN keys to directly increase and decrease pump flow rates. The MP50 has a broad range of other CPM settings to ensure the availability of a time setting that will match your specific conditions. - Page 13 Operation With this method, the number of complete pump cycles per minute is fixed, within a range of 1 to 6; 4 CPM is the default value which appears at startup. Each time the up/down arrow keys are pressed, the pump refill and discharge times are both automatically adjusted to maintain the selected CPM value.
- Page 14 Automatic Cycling state. During Hold and Sample a HELD is displayed to remind you that the controller is in a paused state. Figure 3 shows an example of the MP50 in MP mode, but HELD in the Sample state.
-
Page 15: Use With The Mp30 Level Sensing Water Level Meter
Use with the MP30 Automatic Drawdown Control The MP50 may optionally be used with the MP30 MicroPurge Drawdown / Water Level Meter. See Figure 4 for an example of the MP50 in MP mode with the controller in a level paused state enacted by an MP30 meter. - Page 16 Operation Figure 5 MP50 MP30 Use MP10 MP50 MP30 Normal Static Level Maximum Point of Drawdown Figure 6 MP50 MP30 Use Connector for optional MP30 Drawdown Control MP10 MODEL Compressed gas source asics CONTROLLER connection MicroPurge Mode Quick Guide MicroPurge Mode Quick Guide 1.
-
Page 17: Sampling
A submerged probe in all modes is indicated by a solid green light. When the MP50 is paused by the MP30 the MP 50 display indicates this as shown in Figure 4 "DRAWDOWN CONTROL"... -
Page 18: Id Mode
Additional information on the MP30 is given in the MP30 O&M manual ID Mode Figure 6 shows an example of the MP50 in ID time set mode. Once you've used the MP50 in MP mode and found proper settings for your wells, subsequent sampling events are speeded along by using the controller in ID mode. -
Page 19: User Time Set (Mn) Mode
ID. The UP and DOWN keys are used to change the ID number (the MP50 has IDs that range from 1-165) up or down in value. Sampling in ID mode is the same as explained, above, for MP mode. -
Page 20: Mp50 Battery
MP mode. The MP50 does not attempt to translate a user set time into a corresponding ID or CPM. Also, any settings you have entered in MP or ID modes are lost once you press the MODE key to enter MN mode. -
Page 21: Troubleshooting
Troubleshooting Troubleshooting Use the following troubleshooting table to assist in troubleshooting the MP50: Symptom Possible Cause Action / Fix Display not showing Low or dead batteries Check battery voltage on Batteries installed wrong opening display (>3.6 volts required) Replace batteries... -
Page 22: Mp50 Specifications
Connection to MP30 Drawdown Meter: Heavy-Duty Cable (Supplied with MP30) *Pump flow rates in deeper wells (>100 feet) will be reduced, especially for pumps with less than 10 feet liquid submergence. For additional assistance contact QED Service at: 1-800-624-2026 Phone:... -
Page 23: Qed Service Contacts
Warranty QED Monitoring System WARRANTY QED ENVIRONMENTAL SYSTEMS, ("Q.E.D.") warrants to the original purchaser of its products that, subject to the limitations and conditions provided below, the products, materials and/or workmanship shall reasonably conform to descriptions of the products and shall be free of defects in materials and workmanship. -
Page 24: Qed Warranty
2. Specifying where, when, and from whom the product was purchased. 3. Describing the nature of the defect or malfunction covered by this warranty. 4. Sending the malfunctioning component, after authorization by Q.E.D. to: QED Environmental Systems 6155 Jackson Rd. Ann Arbor, Michigan 48103... -
Page 25: Appendix 1 Id Data Table
Appendix Appendix 1 ID Data Table NOTE: Bold Shaded values are default for that CPM CYCLES / min (CPM) 1 / min 2 / min 3 / min 4 / min 5 / min 6 / min Disch Refill Disch Refill Disch Refill... - Page 26 P.O. Box 3726 Ann Arbor, MI 48106-3726 USA 1-800-624-2026 Fax (734) 995-1170 info@qedenv.com www.qedenv.com...
