Memorex MP3862 User Manual

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING:
Users of this product are cautioned not to make modifications or changes that are not
approved by MEM-CE, LLC., doing so may void the compliance of this product and may result in the loss
of the user's authority to operate the equipment.
DANGER: This symbol is intended to alert the user to the risk of exposure to invisible and hazardous laser
radiation if the cover or back is opened the interlock fails or is defeated. Direct exposure to the beam may
damage your eyesight.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND FULLY INSERT.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator
and your body.
CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
LASER SAFETY: This unit employs a laser. Only qualified service personnel should attempt to service this device due
to possible eye injury.
CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE PROCEDURE HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
SURGE PROTECTORS: It is recommended to use a surge protector for AC connection. Lightning and power surges
ARE NOT covered under warranty for this product.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
CLASS 1 LASER PRODUCT
CAUTION
INVISIBLE LASER RADIATION
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1 WHEN OPEN AND INTERLOCKS
DEFEATED.
PRODUCTO LASER DE CLASE 1
AVOID EXPOSURE TO BEAM
IMPORTANT SAFETY INSTRUCTIONS
1. Read these Instructions. 11. Only use attachments/accessories specified by the
2. Keep these Instructions. manufacturer.
3. Heed all Warnings. 12. Unplug this apparatus during lightning storms or when
4. Follow all Instructions. unused for long periods of time.
5. Do not use this apparatus near water. 13. Refer all servicing to qualified service personnel.
6. Clean only with a dry cloth. Servicing is required when the apparatus has been
7. Do not block any of the ventilation openings. Install damaged in any way, such as power-supply cord or
in accordance with the manufacturer's instructions. plug is damaged, liquid has been spilled or objects
8. Do not install near any heat sources such as have fallen into the apparatus, the apparatus has
radiators, heat registers, stoves, or other apparatus been exposed to rain or moisture, does not operate
(including amplifiers) that produce heat. normally, or has been dropped.
9. Do not defeat the safety purpose of the polarized 14. WARNING: To reduce the risk of fire or electric shock,
or grounding-type plug. A polarized plug has two do not expose this apparatus to rain or moisture. Do
blades with one wider than the other. A grounding- not place objects filled with water, such as a vase, on
type plug has two blades and a third grounding the apparatus.
prong. The wide blade or the third prong are 15. The AC mains plug is used as the power disconnect
provided for your safety. When the provided plug device and it should remain readily accessible and
does not fit into your outlet, consult an electrician operable during intended use. In order to completely
for replacement of the obsolete outlet. disconnect the apparatus from power, the mains plug
10. Protect the power cord from being walked on should be completely removed from the AC outlet
or pinched particularly at plugs, convenience socket.
receptacles, and the point where they exit from the 16. Use only with the cart, stand, tripod, bracket, or
apparatus. table specified by the manufacturer, or sold with the
Bluetooth CD Boombox
FlexBeats™
®
I'll Play Your Tunes
apparatus. When a cart or rack is moisture. The apparatus shall not be exposed to
used, use caution when moving the dripping or splashing and that objects filled with
cart/apparatus combination to avoid liquids, such as vases, shall not be placed on
injury from tip-over. apparatus
17. Do not install this equipment in a 20. WARNING: The battery (battery or batteries or
confined or building-in space such battery pack) shall not be exposed to excessive
as a book case or similar unit, and remain a well heat such as sunshine, fire or the like.
ventilation conditions at open site. The ventilation 21. WARNING: The mains plug is used as disconnect
should not be impeded by covering the ventilation device, the disconnect device shall remain readily
openings with items such as newspaper, table- operable.
cloths, curtains etc.
22. This equipment is a Class II or double
18. WARNING: Please refer the information on
insulated electrical appliance. It has been designed
exterior bottom enclosure for electrical and safety
in such a way that it does not require a safety
information before installing or operating the
connection to electrical earth.
apparatus.
23. Invisible laser radiation when open and
19. WARNING: To reduce the risk of fire or electric
interlocks defeated. Avoid exposure to beam of
shock, do not expose this apparatus to rain or
laser.
HOW TO USE THE MEMOREX MP3862
Congratulations on your purchase of the Memorex Bluetooth® CD Boombox!
The MP3862, with built-in Bluetooth® Wireless Technology, makes it easy to
take your tunes anywhere. Choose from a variety of music sources, including
CD/ CD-R / CD-RW / MP3/ WMA formatted Discs, AM/FM Stereo Radio, Audio
devices through Line In port and wireless streaming from Bluetooth-enabled
devices. Please follow these operational instructions carefully. Save them for
future reference.
POWER SUPPLY
Before first use, check that the rated voltage of the unit matches your
local voltage.
• Connect AC adaptor and power cord to AC socket bk and plug into
AC outlet.
• When using batteries, disconnect the AC power cord. Battery power
will automatically cut off when cord is connected.
• Insert 8 "C" size batteries (not included). When the volume decreases,
or the sound starts to distort, replace all of the batteries with new ones.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Warning – Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
2. Use only the size and type of batteries specified.
3. Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. A reversed battery may cause damage to the device.
4. Do not mix dThis equipment should be installed and operated with minimum distance of
20cm between the radiator ifferent types of batteries together (e.g. Alkaline, Rechargeable
and Carbon-zinc) or old batteries with fresh ones.
5. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
6. Do not try to recharge a battery not intended to be recharged; it can overheat and rupture.
(Follow battery manufacturer's directions.)
7. Remove batteries promptly if consumed.
8. Clean the battery contacts and also those of the device prior to battery installation.
OPERATION
Pair a Bluetooth-Enabled Mobile Device
1. Turn on MP3862 by pressing Standby button
X
2. Press CD/BT button for two seconds and Standby LED
 an
blink Blue. The unit will automatically search for and pair a Bluetooth-
enabled device.
3. Turn on your mobile device's Bluetooth option in settings to search for a
discoverable device with a Bluetooth signal. Select "MRX-MP3862" from
the device results on your smartphone or tablet.
4. When the Bluetooth connection is enabled and the Stereo/BT indicator
will light solid when successfully paired.
5. Use "0000" if a pairing code is necessary on your mobile device. Find your
music selection on your mobile device, select play and enjoy!
6. While connected via Bluetooth, press the Play/Pause button
at
Pause and the Skip / buttons to go back or advance tracks.
ak al
7. To disconnect from paired Bluetooth device, press and hold Mode button
"M" . If connection is lost after successful pairing, check to make sure the
ap
distance between speaker and Bluetooth-enabled device does not exceed
33 feet /10 meters.
HOW TO USE THE MEMOREX MP3862
MP3/CD Player Operation (CD/CD-R/CD-RW)
1. Turn on MP3862 by pressing Standby button
2. Press CD/BT and gently lift the CD Door
 v
3. Insert a disc label side up, close door and press Play/Pause button
4. Press the Skip and buttons to play previous or next track. Press
ak al
and hold the Skip buttons to search track or within track.
ak
5. Press the Mode "M" button to REPEAT a single track, the repeat
ap
icon (single arrow ) will appear in the display. Press a second time to
repeat all tracks, REPEAT ALL PLAY (icon with double arrow
appear in the display. Press M again to cancel Repeat playback.
ap
6. While in the Stop mode, press the Program button "P"
Program setting mode. Select a track using the Skip
press the Program button again to save the song. Repeat for up to 20
aq
tracks. Press the Play/Pause button to play the program; "P" will appear in
at
the display. Press the Stop button to resume normal play.
ar
Note: If the CD skips or will not play, the disc may need to be cleaned. Wipe
the disc with a clean cloth. Keep CD lens clean from dust and fingerprints.
Listen to Music Using Radio
Enjoy your favorite AM or FM stations as desired.
1. Turn on MP3862 by pressing Standby switch
2. Select the AM/FM mode by pressing the FM/AM button
3. Change between bands by pressing the same FM/AM button
to toggle between both.
4. Select a station by rotating the tuning Channel Selection knob
When a station with a strong FM signal is playing, the Stereo/BT
indicator will light solid.
an
Headphones Jack
For private listening, insert Headphones with a standard mini plug into this
jack . The main speakers will be disconnected when the plug is inserted.
bt
Line-In Jack
Press AUX Button for LINE-IN mode. Insert one end of an audio cable
U
(not included) into the Line Out jack on your external audio unit and the other
end into the Line-In jack on this unit; the unit will automatically enter the
bt
Line-In mode. Start playback of the external unit and its audio output sound
will be heard through this unit's speakers.
MAINTAINING YOUR SYSTEM FOR
CONTINUED ENJOYMENT
• When not in use, turn unit off.
• Keep the unit away from direct sunlight and excessive heat.
• CLEANING THE CD LENS: If the CD lens is dusty, clean it with a brush-
blower. Blow several times on the lens and remove the dust with the brush.
Finger prints may be removed with a cotton swab moistened with alcohol.
• CLEANING THE UNIT: Do not use volatile chemicals on this unit. Clean by
lightly wiping with a soft cloth.
• If an abnormal display indication or an operating problem occurs, disconnect
the AC power cord and/or remove the batteries. Wait at least 5 seconds,
then reconnect the AC power cord or reinstall the batteries.
will rapidly
TROUBLESHOOTING
Player not working:
• Check the AC connection and/or the batteries are installed properly
• Make sure power is on
an
Sound not clear or no sound:
• Check volume level
• Check distance between this unit and the connected device (Bluetooth)
• Clean CD lens
to Play or
No CD Playback:
• Disc is not inserted correctly
• Disc is not compatible
• Make sure CD function is selected
• Make sure the headphones or the LINE IN cable is not connected
Please read these instructions completely before operating this product.
LOCATION OF CONTROLS
u
X
at
) will
V W X
to enter the
aq
/ buttons then
ak al
ar aq ap ao an am alak
as bt
X
.
y
y
.
w
bk
SPECIFICATIONS AND COMPATIBILITY
Power Supply ......................................................... AC 120V~, 60Hz,17W or
DC 12V (8x1.5V "C" size,UM-2 batteries
Output ...................................................................................... 1.5W + 1.5W
CD Playback Frequency Response ..........................31.5Hz - 16kHz +/– 3dB
Whole Band Frequency Response ........................................ 250Hz - 6.3kHz
CD Signal to Noise Ratio .................................................................... ≥50dB
CD Sampling Frequency ..................................................................44.1 kHz
Frequency ............................................FM: 88-108MHz AM: 530-1710KHz
Bluetooth Reception Distance: ................................................................8m
Speaker Impedance ......................................................................... 4 Ohms
Dimensions ................................... 13.78" x 9.5" x 5.5" (350 x 242 x 140mm)
Weight .............................................................................. 3.73 lbs. (1.69 kg)
Specifications are subject to change without notice.
LIMITED WARRANTY
MEM-CE, LLC. warrants this product against defects for 90 days from the date of original
purchase. MEM-CE, LLC. shall not be responsible for any lost data or other incidental or
consequential damages related to this product. Some jurisdictions do not allow limitations
on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This
limited warranty gives you specic legal rights, and you may have other rights which may vary
from one state, province or country to another.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO
RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEM-CE, LLC.
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE, PLEASE VISIT OUR WEBSITE AT:
MEMOREXSUPPORT.COM OR CONTACT CUSTOMER SERVICE:
For customers calling within the United States and Canada, call 1-855-982-2538
MEM-CE, LLC. 11485 Valley View Road, Eden Prairie, MN 55344 USA MEMOREX-CE.COM
Memorex and the Memorex logo are trademarks of Digital Products International (DPI, INC.) and its
affiliates. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
®
and any use of such marks by MEM-CE Inc. is under license. All other trademarks are the property of
their respective owners.
For additional setup, operating assistance or an electronic version of this user manual, please visit
memorexsupport.com
User Guide
MEMOREX-CE.COM
MP3862
1. Handle
v
2. CD Door
3. Channel Selection
4. CD/BT (Bluetooth)
5. FM/AM
6. Aux (audio Line-in)
7. Volume dial
8. Bass
9. Standby
w
10. Play/Pause Button

U y
11. Skip Previous/
9
Fast Reverse
at
12. Skip Next/
:
Fast Forward
13. LCD Display Window
14. Standby/Bluetooth
Indicator
15. Stereo Speakers
16. Mode Button
17. Program Button
18. Stop Button

19. Headphone Port
20. Line In Jack
21. External AC
Power Port
22. Battery Compartment
(Bottom of Unit)
bl
