- Page 1 C D M A 1 x R T T S e r i a l C e l l u l a r D a t a M o d e m User Manual 001-0003-819 Revision 1; February 2008...
- Page 2 REVISION HISTORY Released February 2008...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION 1 – PREFACE ......................5 SECTION 1 – PREFACE Copyright Notice......................5 Modem Use........................5 Interference Issues ......................5 Mobile Application Safety ....................6 SECTION 2 – PRODUCT OVERVIEW SECTION 2 – PRODUCT OVERVIEW ..................7 Module Identification....................... - Page 4 TABLE OF CONTENTS Mechanical Specifications....................45 SECTION 12 – ABBREVIATIONS ..................46 SECTION 12 – ABBREVIATIONS SECTION 13 – SERVICE AND SUPPORT ................47 SECTION 13 – SERVICE AND SUPPORT Product Warranty, RMA and Contact Information............... 47 RMA Request ....................... 47 Product Documentation ....................
-
Page 5: Section 1 - Preface
– – Copyright Notice ©2008 CalAmp. All Rights Reserved. This manual covers the operation of the CalAmp 819-1XRT Serial Cellular Data Modems. Specifications described are typical only and are subject to normal manufacturing and service tolerances. CalAmp reserves the right to modify the equipment, specifications or this manual without prior notice, in the interest of improving performance, reliability or servicing. -
Page 6: Mobile Application Safety
Mobile Application Safety • Do not change parameters or perform other maintenance of the 819-1XRT while driving • Road safety is crucial. Observe National Regulations for cellular telephones and devices in vehicles • Avoid potential interference with vehicle electronics by correctly installing the 819-1XRT. -
Page 7: Section 2 - Product Overview
– – Module Identification Label Information The label contains the CalAmp DataCom part number, serial number, FCC ID and the ESN number. The ESN number is required by your cellular carrier when activating your data contract. The ESN number is provided in decimal and Hex formats; format is dependent on your carrier type. -
Page 8: External Connections
External Connections Front panel connections Fig. 2.1 819-1XRT Front Panel 819-1XRT front panel indicators include: PWR: Green LED indicating power to unit. Tx: Red LED indicating Transmit activity. DCD: Amber LED indicating Data Carrier Detect from cellular network. Rx: Green LED indicating Receive activity. RF: SMA female, primary antenna connection. -
Page 9: Rs-232 Serial Port Integration Parameters
RS-232 Serial Port Integration Parameters Table 2.1 provides the serial cable design information to integrate the 819-1XRT into your system. Table 2.1 Standard RS-232 DE-9 Pin out Name Direction Description «— Carrier Detect «— Receive Data —» Transmit Data —» Data Terminal Ready System Ground «—... -
Page 10: Section 4 - Getting Started
– – Package Contents • 819-1XRT cellular data modem (specific to CDMA cellular provider) • Information card Setting up the 819-1XRT Modem using the CDMA 819S Driver: You may download the necessary modem driver files from our website at http://www.calamp.com. If you are installing the modem using the drivers from the website, refer to these steps: 1. - Page 11 2. Select the “Modem” tab. Select “Add...” and complete the Wizard. Check “Don’t Detect My Modem”. 001-0003-819 Rev 1 Page 11 of 48...
- Page 12 3. Select "Have Disk…" Click “Next”. 4. Browse to the file location where the CDMA 819S modem driver was downloaded. 001-0003-819 Rev 1 Page 12 of 48...
- Page 13 5. Select the KYOCERA WIRELESS CORP. manufacturer and Kyocera High-Speed CDMA Wireless Modem model. Click “Next”. 6. Assign the modem to the COM port connected to the modem. Click “Next”. 7. Click “Finish”. 001-0003-819 Rev 1 Page 13 of 48...
-
Page 14: Setting Up The Cdm-819S Using Native Windows Drivers
Setting up the CDM-819S using native Windows drivers: 1. Click on Start --> Settings --> Control Panel. Select "Phone and Modem Options". 2. Select the “Modem” tab. Select “Add.” Complete the Wizard. Check “Don’t Detect My Modem”. 3. Select "Standard 19200 bps Modem." Click “Next”. 4. - Page 15 2. From the Network Connections screen, select “Create a new connection”. Follow the Wizard as it goes through the steps to create a dial-up connection by selecting “Next”. 3. For the connection type, select “Connect to the Internet”. Click “Next”. 001-0003-819 Rev 1 Page 15 of 48...
- Page 16 4. Select “Set up my connection manually”. Click “Next”. 5. For the Internet connection, select “Connect using a dial-up modem”. Click “Next”. 001-0003-819 Rev 1 Page 16 of 48...
- Page 17 6. Check the box by the modem for the CDMA device. Click “Next”. 7. Type in a connection name. Click “Next”. 001-0003-819 Rev 1 Page 17 of 48...
- Page 18 8. Type in #777 for the phone number to dial. This is the number for 1xRTT packet data calls. 9. Typically the username and password are left blank. Click “Next”. 10. Click “Finish” in the Wizard. The network connection should now be available on the Network Connections screen.
- Page 19 From the Properties window, confirm the correct modem driver is checked under “Connect using:” and select Configure. 001-0003-819 Rev 1 Page 19 of 48...
- Page 20 In the Configuration window, confirm the maximum speed (bps) is set to 115200, as shown in the Modem Configuration Screen. Click OK to exit out of each screen. Refer to Packet Data Call Setup in Section 5 for further information on call setup procedures. 001-0003-819 Rev 1 Page 20 of 48...
-
Page 21: Operational States
Operational States The modem has three operational states: • Command State • Online State • Online Command State When first powered on, the modem is in the Command State where it is able to accept AT commands. When instructed to dial out or to answer a data call, the phone is in the Online State. Activating your Modem 1. - Page 22 6. Confirm your registration on the cellular network with the AT+CSS? command. A reply of +CSS? 2,Z,99999 indicates the modem is not registered on the network. It may take up to 15 seconds after power-up to register on the network. Once registered, a typical response is +CSS?: 1,A,4152 where 1 is the band class, 1=800 MHz, 2=1900 MHz, A-F is the band (Z indicates the modem is not registered on the network), 4152 is the SID, i.e.
-
Page 23: Section 5 - 819-1Xrt Fast-Track Call Setup Guides
– – Circuit Switch Data (CSD) Call Setup 1. Connect the modem to an active COM port on a PC with an RS-232 9 pin straight through cable. 2. Attach the antenna and power connector. 3. Connect with a Hyper-Terminal session set to 115,200, 8 Bits, No Parity, 1 Stop Bit, and Hardware Flow Control enabled (the default speed of the modem). -
Page 24: Packet Data Call Setup
18. To further test CSD termination, connect another modem, (landline or cellular) to an available COM port on a PC. Configure that modem and the COM port to your required speed, i.e. 9600, with AT+IPR=9600. 19. Start HyperTerminal on the PC’s COM port and call the LandCell modem from this terminal window with the following command. - Page 25 10. Confirm you are registered on the cellular network with AT+CSS? A reply of +CSS? 2,Z,99999 indicates you are not registered. It may take up to 15 seconds after power-up to register on the network. Once registered a typical response will be +CSS?:1,A,4152 where 1 is the band class, 1=800 MHz, 2=1900 MHz, A-F is the band (Z indicates not registered on network), 4152 is the SID, i.e.
-
Page 26: Section 6 - Carrier Specific Information
– – Verizon Wireless Subscribers For Verizon Wireless subscribers residing in the United States, the standard provisioning procedure is by issuing the command AT+CDV*22899. If the modem will not provision and you have verified the serial number is activated in the Verizon system, manually key in the phone number. -
Page 27: Sprint Pcs Subscribers
Sprint PCS Subscribers Sprint PCS uses IOTA (IP-based Over The Air) for their over-the-air provisioning system. IOTA uses packet data calls to transfer configuration data to the phone. These IOTA data sessions can be network or client initiated. Network initiated IOTA is the preferred method. An automatic network initiated IOTA session occurs when the module first registers onto the Sprint network. -
Page 28: Alltel Subscribers
Alltel Subscribers Alltel uses both OTAPA and a manual process for provisioning modems. The OTAPA process is for voice phones and is not normally possible with a modem. The manual process must be followed. The ESN is entered into their database and an MDN and MIN number are assigned to the account. -
Page 29: Telus (Canada) Subscribers
Telus (Canada) Subscribers The standard procedure to provision the modem is by issuing the command AT+CDV*22803. If the modem will not provision and you have verified the serial number is activated with Telus, manually key in the phone number. In cellular terminology, the phone number is known as the Mobile Directory Number (MDN). -
Page 30: Section 7 - Troubleshooting
– – This section provides important information relating to the setup and diagnosis of your 819-1XRT modem. If you are having trouble communicating with the modem, please read this "Troubleshooting" section in full. If, after reviewing this section, you are still having problems connecting, call our Technical Support line at: 507-833-8819 for more assistance. -
Page 31: Altering The Modem's Cellular Parameters
To test the link between your modem and the cellular network, try to call your cell phone. Type in: AT+CDV<phone number to call> (without spaces and angle brackets) and press enter. This command will perform a voice call similar to the type a standard home phone would make. If your modem has been activated correctly, your cell phone should ring and display the number of the modem. -
Page 32: Unlocking The Service Programming Code (Spc)
Unlocking The Service Programming Code (SPC) As a safety precaution, to keep unauthorized users from gaining access to the device, the modem carries a Service Programming Code (SPC). The default SPC is 000000. Without entering this code, you cannot alter the modem's configuration. To unlock the modem and allow write access, enter the SPC with this command: AT$KWSPC=000000 Entering The Mobile Directory Number (MDN) The MDN is the phone number used to call the modem from other devices. -
Page 33: Section 8 - User Profiles
– – There are 3 user profiles; two profiles are editable. The third profile contains the factory default settings. All user-configurable parameters which can be saved may be stored into a profile with the &Wn command, listed below where n is profile 1 or 2. Note: saving to a profile does not activate that profile. -
Page 34: Section 9 - Common At Command Reference Guide
– – Commonly used AT commands in day-to-day modem operation Entering Access Codes: To retrieve the Serial Number of the modem (in hexadecimal format): AT+GSN To perform Over-the-Air Service Provisioning (OTASP): AT+CDV*22899 To change to Offline Digital mode: AT$KWMODE=1 To enter the SPC and unlock the modem for programming: AT$KWSPC=000000 To enter the Mobile Identification Number (MIN): AT$KWDIR=<MIN>... - Page 35 Miscellaneous Commands: Echo commands in command state or in online state: ATE1 Do not echo commands in command state or in online state: ATE0 Display result codes as numbers: ATV0 Display result codes as words: ATV1 Dump configuration parameters: AT&V Return to Online State from Command State: ATO Reset to default configuration: ATZ AT commands Digit/Word Cross Reference:...
-
Page 36: Section 10 - At Command Reference
– – All modem functions are controlled using the same industry-standard AT commands used to control landline modems. A knowledge of these commands is not required but are provided as a reference. AT Command Types There are five types of AT commands; •... -
Page 37: Basic At Parameters
Table 10.1: Result Codes Digit Verbose Description Command executed without errors CONNECT Connected to remote modem RING Incoming Call NO CARRIER Carrier from remote modem lost or never present ERROR Error in the command line NO DIAL No dial tone detected within time out period BUSY Busy signal detected Five seconds of silence not detected after ring back when @ dial... -
Page 38: Basic Action Commands
Table 10.3: S-Registers Register Value Description Automatic answering. Number of rings before answering. 0 to 255 Disable automatic answering=0. Default is 0 Carriage return character. Default is 13 Line feed character. Default is 10 Backspace character. Default is 8 2 to 10 Length of time in seconds to pause before dialing. - Page 39 Note: while spaces are ignored everywhere else, spaces are significant inside the quotation marks. To read back a value, use the READ command: +CMD? To test if a particular command is supported, along with the range of values it supports, use the TEST command: +CMD=? An extended command must be terminated with a semicolon if another command follows it in the...
-
Page 40: Cellular Cdma Commands
The <parity> argument is only valid when <format> is set to 2. The default settings for the modem are AT+ICF=3,1. Cellular CDMA Commands Cellular CDMA commands use the same syntax as other extended commands. Numeric values are decimal. Table 10.6 describes cellular CDMA commands. Table 10.6: CDMA AT Parameter Commands Command Description... - Page 41 Um Interface Data Compression +CDS This extended-format compound parameter controls the V.42bis data compression function on the Um interface Configuration String The string (up to and including the termination character) will be stored by +CFG the MT2 and sent to the base station prior to dialing. Each transmission of a +CFG command from the TE2 replaces the contents of the previous string.
- Page 42 Break Handling In Error Control Operation. This extended-format compound parameter is used to control the manner of V.42 operation on the PSTN link (if present in the IWF) Frame Check Sequence This extended-format numeric parameter controls the use of the 32-bit +EFCS frame check sequence option in V.42 on the PSTN link (if present in the IWF)
- Page 43 Cellular AT Command extensions in support of voice services commands allow the data terminal to be used as an automatic dialer for voice calls. The format of these commands is shown in Table 10.7. Table 10.7: Cellular AT Command Extensions in Support of Voice Services Command Description +CHV<value>...
-
Page 44: Section 11 - Specifications
– – Product specifications are subject to change without notice. General Specifications Interface Connectors: RS-232 DE-9S Connector (DCE) Power Connector: 2.1mm/5.5mm DC Barrel Jack (Center Positive) LED Indicators: Power, Tx, DCD, Rx Antenna Interface: SMA female Size: 4.10 x 2.61 x 1.10 in. Weight: 7.0 oz. -
Page 45: Mechanical Specifications
Mechanical Specifications This section provides the exterior dimensions of the 819-1XRT and the use of mounting flanges to secure the modem to any surface (surfaces can be drilled to secure the modem). All drawings are actual size. The drawings may be used as layout reference, but CalAmp advises a physical comparison be made to the modem before proceeding with the mounting process. -
Page 46: Section 12 - Abbreviations
– – Abbreviation Description CDMA Code Division Multiple Access Clear to Send Data Carrier Detect Electronic Serial Number EVDO Evolution Data Optimized GPRS General Packet Radio Service Global Positioning System IOTA Internet Over the Air Light Emitting Diode Over the Air OTASP Over the Air Service Provisioning Point to Point Protocol... -
Page 47: Section 13 - Service And Support
– – Product Warranty, RMA and Contact Information CalAmp guarantees every 819-1XRT Cellular Modem will be free from physical defects in material and workmanship for one (1) year from the date of purchase when used within the limits set forth in the Specifications section of this manual. The manufacturer's warranty statement is available in Appendix 1. -
Page 48: Appendix 1 - Warranty Statement
– – CalAmp DataCom warrants to the original purchaser for use ("Buyer") that data telemetry products manufactured by DRL ("Products") are free from defects in material and workmanship and will conform to DRL's published technical specifications for a period of, except as noted below, one (1) year from the date of shipment to Buyer.
