Operating manual Please read these instructions carefully before starting up the machi- 1. Table of contents 1. Table of contents 2. General Information 3. Work- and safety- instructions 4. Technical Data 5. Operative range and determined application 6. Transport 7. Connection and Assembly 8.
Operating manual 2.1 General Information In the further text the operating manual is marked as BA. Besides this, the following abbreviations are used: Abb. - illustrations Tab. - table - not shown - list of spare parts This symbol will be found where special attention is to be paid, so that instructions, notices and the correct sequence of work is kept and also to prevent damage or destruction of the machine and other parts.
Operating manual 3. Work- and safety-instructions The loor saw has been built corresponding to the latest techniques. Nevertheless dangers can appear in case of use by uninstructed per- sonnel or improper application, not in accordance with the informati- on laid out in this manual. Each person using or maintaining the machine must have read and understood the complete operator’s manual and especially the safety instructions.
Page 5
Operating manual Before commencing the job the operator should get acquainted with the surroundings of the site. This is to avoid putting other persons and/or objects in danger. Make sure the site has been secured and that notice has been given and received that you are about to com- mence.
Operating manual 5. Operative range and determined applica- tion The loor saw KDF-800E was manufactured for the purpose of cut- ting to a maximum depth of 320 mm in concrete, brickwork or similar building materials. Any application other than the ones described are to be considered illicit.
Operating manual 7. Connection and Assembly 7.1 Connection of water hoses and cables The cool water connection is done with a „Gardena“ connection. Use clean water only! For the electric connection you need a 16A CCE cable (min 5x2mm² / cable length 25m).
Page 10
Operating manual 7.2 Mounting the saw blade The saw blade should always be mounted to the loor saw by hexa- gon screws. The blade can be mounted either to the right or left side of the loor saw. The Screw left from the belt guard is a lefthand screw.
Operating manual Operation 8.1 Notice After checking the guard has been lowered over the blade safely one can now engage the loor saw. Remember that only people, who have read the manual may work with this machine. 8.2 Marking the cutting line Mark the cutting line with crayon or similar.
Page 12
Operating manual 8.5 Feed Manipulate the lever of the brake that the loor saw can be pushed. Move the loor saw by steady pushing. High pushing let the loor saw mounting out of the cut. In danger, activate the emergency switch immediately. 8.6 Stop cutting Lift the saw blade out of the cut, close the ball valve at the water tank, activate the brake and turn the switch at the engine off.
Operating manual 9. Maintenance Read operating safety instructions when carrying out maintenance work. Disturbances caused by a insuficient or improper maintenance can lead to high repair costs. Regular maintenance is there for essential. Disconnect tools before servicing. Be certain that the carriage cannot move down.
Page 14
Operating manual To tension or change the drive belt, the belt guard and the cover must irst be removed. (See section 6.1) Then, by loosening the hexagon nut on the threaded rod, the motor together with the console plate can be swiveled forward and the drive belt pulled from the pulleys.
Operating manual 10. Trouble shooting Go to the search systematically for an error occurring. Please use the following table and diagrams for electrical systems.If you can not ix the error yourself, you should contact our customer service Note the following points: - The more precise description of the error, the quicker and better we can help you.
Operating manual 11. Customer Service Eine regelmäßige Wartung und Plege ist Voraussetzung für die stän- dige Funktion und Einsatzbereitschaft. Zur Bestellung von Ersatz- For this machine to perform correctly a regular maintenance is ab- teilen bedienen Sie sich bitte der nachfolgenden Ersatzteilliste. Zur solutely necessary.
Operating manual 12. Disassembling In the event of deterioration and scrapping of the machine, the fol- lowing items must be in accordance with the requirements of the legislation in force. Main materials: Motor: Aluminium (AL), Steel (AC), Copper (CU), Polyamid (PA) Machine: Steel sheet (AC), Cast iron (FT), Aluminium (AL) 13.
