Damro BKOC - 004 Assembling Instruction Manual

ASSEMBLING INSTRUCTION MANUAL
04
03
01
03
12
07
08
11
03
05
06
A B
7X50 Screws 3/4x 6 P.H Screw
20 nos. 28 nos.
H I
3/4 x 6 S.T Screw
12 nos. 10 nos.
01
BKOC - 004 BKOC - 004
PANEL CODING SYSTEM
Please follow the panel numbers for assembling.
02
09
10
06
HARDWARE LIST
C
"L" Plate
01 nos.
J
Dowel Steel Knob
02 nos.
[01] Fixing Side Panel & Bottom .
I
OFFICE CUPBOARD OFFICE CUPBOARD
01 - Side Panel (L)
02 - Side Panel (R)
03 - Shelves I [03]
04 - Top
09
05 - Bottom
06 - Bottom Strip [02]
07 - Door (L)
08 - Door (R)
09 - Back Sheet I[02]
10 - Back Sheet II
11 - Shelves Supporter
12 - Shelves II
D E
Hinges (D.Type)
KD Plate
01 nos.
K
Lock
01 nos.
I
I
I
I
I
C
(1650x298x15mm)
(1650x298x15mm)
(750x296x15mm)
(750x297x15mm)
(750x297x12mm)
(749x50x15mm)
(1588x388x15mm)
(1588x388x15mm)
(389x1192x09mm)
(779x382x09mm)
(749x40x15mm)
(750x296x15mm)
F
Bottom Cup (15mm)
06 nos. 04 nos.
I
G
1/2 x 6 S.T Screw
43 nos.
