Damro BKFR-002 Assembling Instruction Manual

ASSEMBLING INSTRUCTION MANUAL
04
03
01
09
05
A
7X50 Screws
16 nos.
01
BKFR - 002 BKFR - 002
PANEL CODING SYSTEM
Please follow the panel number for assembling.
02
06
HARDWARE LIST
B
3/4x 6 P.H Screw
22 nos.
[01] Fixing Side Panel & Bottom .
C
C
F
Back side up
FILING RACK FILING RACK
01 - Side Panel (L)
02 - Side Panel ®
07
03 - Shelves I
04 - Top
05 - Bottom
06 - Bottom Strip [02]
07 - Back Sheet I
08
08 - Back Sheet II
09 - Shelves II
06
C D
Bottom Cup (15mm)
Dowel
08 nos. 04 nos.
C
C
C
E
3/4 x 6 S.T Screw
08 nos.
C
C
(1035x230x15mm)
(1035x230x15mm)
(570x227x15mm)
(570x227x15mm)
(570x227x15mm)
(570x50x15mm)
(598x373x09mm)
(600x598x09mm)
(570x227x15mm)
