- Page 1 Instruction manual MD50 MD50 W...
- Page 2 MD50 MD50 W...
- Page 3 Introduction Operating parts With these spotting scope from MINOX you have chosen a 1. Eyepiece product of highest optical quality and mechanical precision. 2. Zoom These instructions are to help you benefit from the full 3. Lens performance spectrum of your MINOX spotting scope.
- Page 4 Use with and without glasses Those who wear glasses must leave the rotating eyecup on the eyepiece in the original position (as delivered) or, if necessary, turn the eyecup in clockwise direction until it noticeably engages. In this setting you can enjoy the entire field of view without disturbing interference at the edges.
- Page 5 For shake-free viewing we recommend the use of a tripod, especially for high-power magnification. For this reason, the MINOX MD 50 / W is equipped with an especially large support and a 1/4 ˝ tripod screw hole for fastening the tripod.
- Page 6 What to do when ... Problem While viewing, a circular image – without vignetting – cannot be obtained. Operational error (a) The viewers pupil is not at the exit pupil of the eyepiece. (b) The position of the eyecup is not set properly for use with or without glasses.
- Page 7 Technical data MD 50 MD 50 W Magnification 15 x ~ 30 x 16 x ~ 30 x Front lens diameter 1.97 inch / 50.0 mm 1.97 inch / 50.0 mm Exit pupil 0.12 ~ 0.06 inch / 3.3 ~ 1.67 mm 0.12 ~ 0.06 inch / 3.13 ~ 1.67 mm...
