- Page 1 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module User Manual January 2014 This manual applies to the following products: ® ® All EtherTRAK 2 (E2-) and Etherbus (EB-) I/O modules Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com...
- Page 2 01/31/2013 Fixed error in 16DI24 Specification 04/23/2013 Change UL mark from UL1604 to ANSI / ISA12.12.0.1 12/20/2013 Add French UL Safety Warnings 01/14/2014 Changed branding from Sixnet to Red Lion, added E2-MIX20884-D, improved wiring diagrams, clarified specifications, cold junction compensation redundancy feature.
-
Page 3: Table Of Contents
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module TABLE OF CONTENTS General Information ............................8 Overview ................................. 8 Specifications ................................8 1.2.1 General Specifications ............................8 1.2.2 E2/EB-MIX24880-D and E2/EB-MIX24882-D Specifications ................10 1.2.3 E2-MIX20884-D Specifications ........................11 1.2.4 E2/EB-32DI24-D Specifications ........................ - Page 4 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module High Density Discrete Inputs ..........................47 Sourcing/ Sinking Input Option ..........................47 Low Threshold Inputs ............................47 Isolated Discrete Inputs ............................47 Discrete Input Counter Feature ..........................48 High Speed Counters ............................. 49 Slow/Fast Response for All Discrete Inputs ......................
- Page 5 Red Lion will be free from defects in material and workmanship. Red Lion’s obligation under this warranty will be limited to repairing or replacing, at Red Lion’s option, the defective parts within two (2) years of the data of installation, or within two (2) years of the date of shipment from the point of manufacture, whichever is sooner.
- Page 6 In particular, Red Lion disclaims any responsibility for damages, either direct or consequential, that result from the use of this equipment in any application.
- Page 7 à chaud des modules dans les zones dangereuses Note: All information in this document applies to EtherTRAK-2 and Etherbus I/O modules except where otherwise noted. Refer to Red Lion website, the web server within the I/O module, or Red Lion I/O Tool Kit Windows software online help systems for detailed product specifications and configuration settings.
-
Page 8: General Information
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module General Information Overview This manual will help you install and maintain EtherTRAK-2 I/O modules. In summary, wiring for power, communications and I/O is connected to each module’s base. Then, setup choices are entered using a web browser looking at the embedded web server within the module itself or the Sixnet I/O Tool Kit Windows software. - Page 9 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Note: Not applicable to E2-MIX20884-D, and E2-16DIAC-D Ethernet (2 Ports) specifications Ethernet Port(s): 10/100BaseTx (auto-detecting) Connection: RJ45 (auto-crossover) Isolation: 1500 Volts RMS 1 minute (60 Hz.) Message response time is less than 1 ms per message Diagnostic LED’s, solid indicates link, blinking indicates activity Protocols supported: TCP/IP, ARP, UDP, ICMP, DHCP, HTTP, Modbus UDP/TCP Slave mode, Modbus UDP Master mode, Sixnet UDR UDP/TCP Slave mode, and Sixnet UDR UDP Master...
-
Page 10: E2/Eb-Mix24880-D And E2/Eb-Mix24882-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.2 E2/EB-MIX24880-D and E2/EB-MIX24882-D Specifications Discrete Input Channels Voltage range : 10 – 30 VDC Input Polarity: Sourcing (apply power to active) or sinking (ground closure) on 8 inputs Guaranteed ON voltage: 9 VDC Guaranteed OFF voltage: 5.0 VDC Guaranteed OFF current: 2 mA DC Input resistance: 10 Kohms... -
Page 11: E2-Mix20884-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Analog Output Channels (applies only to E2/EB-MIX24882-D) Analog output range: 4-20 mA D/A resolution 16 bits (less than 1 uA) Full scale accuracy +/-0.02% (at 20°C) Span and offset temp. +/- 50 ppm per °C typ. Max. - Page 12 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Non-Isolated Discrete Input Channels Channels: 5-12 Voltage range : 10 – 30 VDC Guaranteed ON voltage: 9.0 VDC Guaranteed OFF voltage: 5.0 VDC Guaranteed OFF current: 2 mA DC Input resistance: 10K Ohms Input current (@ 24 VDC) 3 mA Input Polarity: Sourcing (apply power to active) or sinking (ground closure) on 8 inputs Input Protection: High Impedance with overvoltage protection...
- Page 13 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Analog Input Channels Analog Input Range: 4-20 mA A/D resolution 16 bits (0.003%) 10 bits (fast option) Full scale accuracy: +/- 0.02% (at 20 °C, 16 bit mode) Temperature coefficient +/- 50 ppm per °C (span and offset) Input impedance (resistance): 100 ohms Protection: Self-resetting short circuit protection fuses DMRR (differential mode) 66 db at 50/60 Hz...
-
Page 14: E2/Eb-32Di24-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.4 E2/EB-32DI24-D Specifications Discrete Input Channels Voltage range: 10 – 30 VDC Input Polarity: Sourcing Guaranteed ON voltage: 9 VDC Guaranteed OFF voltage: 5.0 VDC Guaranteed OFF current: 2 mA DC Input resistance: 10 Kohms Input current (@ 24 VDC) 3 mA Input Protection: High Impedance with overvoltage protection... -
Page 15: E2-16Diac-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.6 E2-16DIAC-D Specifications Environmental Specifications Hazardous locations (Class 1, Div 2, Groups A, B, C, D) UL 1604, CSA C22.2/213 (Does not comply with Cenelec EN50021 Zone 2) Discrete Input Channels Voltage range E2-16DIAC-D: 60 –... -
Page 16: E2/Eb-16Do24-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.8 E2/EB-16DO24-D Specifications Discrete Output Channels Output voltage range 10-30 VDC Max. output power: 1A Per channel, 16A per module, .8A at 60ºC 8 channels at 24 VDC Max. off state leakage: 0.01 mA (less than 10 uA) Short circuit protection: self-reset fuses (trip above 1.5 Amp) Min. -
Page 17: E2/Eb-32Ai10V-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.11 E2/EB-32AI10V-D Specifications Analog Input Channels Analog Input Range: 0 to +10 VDC A/D resolution 16 bits (0.003%) Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode) Temperature coefficient +/- 50 ppm per °C (span and offset) Input impedance (resistance): 200 Kohms DMRR (differential mode) 66 db at 50/60 Hz Fastest update time [# of chan.]: 880 ms [all] -16-bit;... -
Page 18: E2/Eb-16Isotc-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.14 E2/EB-16ISOTC-D Specifications Analog Input Channels Analog Input Ranges: +/-250 mV, Thermocouples supported J,K,E,R,T,B,L,N & S A/D resolution 16 bits (0.003%) Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode) Temperature coefficient +/- 50 ppm per °C (span and offset) Input impedance (resistance): 200 Kohms DMRR (differential mode) 66 db at 50/60 Hz... -
Page 19: E2/Eb-16Ai8Ao-D Specifications
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 1.2.16 E2/EB-16AI8AO-D Specifications Analog Input Channels Analog Input Range: 4-20 mA A/D resolution: 16 bits (0.003%), 10 bits (fast option, Channels 1 and 2 only) Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode) Temperature coefficient +/- 50 ppm per °C (span and offset) Input impedance (resistance): 100 ohms Protection: Self-resetting short circuit protection fuses... -
Page 20: Sixnet Software Tools
Red Lion I/O Tool Kit The Red Lion I/O Tool Kit is a configuration, calibration and maintenance tool for Red Lion hardware. It is the preferred method of configuring I/O modules when the module will be an integral part of a Red Lion project under the control of a Red Lion RTU or process controller. -
Page 21: Getting Started With Sixnet Hardware
Use the Test I/O window in the I/O Tool Kit software or the Web Server to verify proper I/O operation of all Red Lion stations. Refer to the I/O Tool Kit or web server on-line help system for further instructions. -
Page 22: Usb Installation Instructions
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module USB Installation Instructions To use the USB please follow the instructions below. Run the sxusb.exe install The USB driver will automatically be installed when the Tool Kit configuration utility is installed. Connect the Dual Ethernet module to the PC Once the USB device is connected the hardware installation wizard will appear. - Page 23 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module The computer will locate the driver and confirm that you would like to install the unverified driver. Select “Continue Anyway” and click finish to complete the installation. View the USB COM port number To view the COM port the USB device has been assigned to, open the Windows Device Manager.
-
Page 24: Assembly And Instruction
Be sure to allow ample space between DIN rails for wire ducts. For most EtherTRAK-2 base I/O and power screw terminal sizes used on Red Lion products are M3 and can support wire sizes of 30-12AWG. The recommended torque is 5 IN/LB. -
Page 25: Replacing The Logic Module
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Replacing the logic module The logic module can be removed from the base in a system that is powered on (hot-swap). The module maybe removed and replaced with another one for troubleshooting or repair/replacement purposes. To remove the module first open the lock tabs on the top and bottom of the module as show in the picture below. -
Page 26: Jumper Settings
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Jumper Settings Setting the Network Jumper This jumper sets the network configuration for the two (“dual”) Ethernet ports. Network Mode Jumper Location The Network Mode jumper is located on the wiring base assembly. To locate the jumper, you must first remove the I/O module from the wiring base. - Page 27 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Network Mode This jumper sets network configuration for the two (or “dual”) Ethernet ports on the base. One of three modes can be set: Pass-thru (Ethernet An unmanaged switch in the module passes Ethernet traffic Message Pass-thru) between the ports.
-
Page 28: Setting The Di Com Jumper
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Setting the DI COM Jumper The Discrete Input Common (“DI COM”) jumper sets a select number of discrete input circuits as either “Sourcing” or “Sinking” on certain types of modules only (as listed below). All 32 inputs are Sourcing (by default) and the first 8 channels can be Sinking (by jumper). - Page 29 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Determine Sinking or Sourcing Mode The default jumper setting is sourcing (jumper to “DC–“) which is appropriate for most situations in which a positive voltage is applied to an input to indicate an "ON" condition. Select Sinking (jumper to “DC+”) for "ON" inputs corresponding to ground closures that require a positive reference as an opposing return connection.
-
Page 30: Rs485 Jumper On The E2-Mix20884-D Base
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module RS485 Jumper on the E2-MIX20884-D base On the E2-MIX20884-D module has a jumper to set the RS485 termination instead of the “TERM” screw terminal on the other EtherTRAK-2 bases. The “storage” position should be used when termination is not required on the RS485 port. When a termination is used on the RS485 network and the EtherTRAK-2 is one of the end points the jumper should be put into the “termination”... -
Page 31: Power Wiring Alternatives
(2 Amp) or ST-PS-024-05 (5 Amp). Current Requirements To calculate the supply current requirements, add the wattage required for the Red Lion and other units in use. Next, divide the total wattage by the DC power source voltage. Then, add any current needed for user instrumentation loops and output loads. -
Page 32: Etherbus Poe Option
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Etherbus PoE Option Etherbus I/O provides the capability to utilize Power over Ethernet (PoE) to power the I/O module and associated instrumentation directly from the Ethernet cable. Etherbus PoE Power – PoE power supplied to Ethernet port #1 will power the module’s intelligence, communication and input channels as well as supply +24 VDC power for external loads. -
Page 33: Base Power And Communication Wiring Diagram
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Base Power and Communication Wiring Diagram The diagram below details the base subassembly which is common to all products in the EtherTRAK-2 I/O Module family. The power and RS485 wiring (screw terminals 1 through 10; see below base diagram) are also common to most products in the family (E2-MIX20884-D has a slightly different power and RS485 wiring). - Page 34 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Upper Row Lower Row Term # Function Term # Function RS485(+) Power In_2 (+) [Does not power DO and AO] RS485(-) Power In_1 (+) [power all module functions] RS485-Gnd Power Ground Watchdog Output Earth Ground RS485...
-
Page 35: Module Wiring / Screw Terminal Assignments
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Module Wiring / Screw Terminal Assignments Screw Terminal Guidelines The screw terminals used on the E2-BASE-1 can accept 30 to 12 AWG wire. The screw size is M3 and the recommended torque is 5 IN/LB. - Page 36 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Screw Terminals (11 – 44) for Specific Modules (9 - 44 for E2-MIX20884) The table below lists the available I/O modules. Click on the link (right column), or turn to pages 37-45, to display the associated Screw Terminal Assignment table.
- Page 37 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module ® 2. Modules listed may include an optional Etherbus Power over Ethernet (PoE) feature (EB-). Address definitions listed in the table below: Discrete Input (Din) registers Analog Input (Ain) registers Discrete Output (Dout) registers Analog Output (Aout) registers...
-
Page 38: Table A Modules E2/Eb-Mix24880 And Mix24882
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.1 TABLE A Modules E2/EB-MIX24880 and MIX24882 Module E2/EB-MIX24880-D and E2/EB-MIX24882-D screw terminal assignment. Equivalent DC Input Circuits Sinking Input Switch Sourcing Input Switch Return - Return - DC Power + DC Power + Jumper Jumper... -
Page 39: Table B Modules 32Di24, 32Do24, 32Ai20M, 32Ai10V
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.2 TABLE B Modules 32DI24, 32DO24, 32AI20M, 32AI10V High density discrete and analog input module screw terminal assignment. E2/EB-32DI24-D E2/EB-32DO24-D E2/EB-32AI20, -32AI10V-D (sourcing or sinking DI, first 8 channels) (sourcing DO) (sourcing DO) (sourcing DI) (sourcing DI) -
Page 40: Table C Modules 16Di24, 16Diac, 16Do24
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.3 TABLE C Modules 16DI24, 16DIAC, 16DO24 16 Channel Discrete I/O Module screw terminal assignment Note: These modules have individually isolated I/O and therefore two screw terminals per channel. Load Equivalent Equivalent Digital DC Output Circui... -
Page 41: Table D Modules 8Ao20M, 16Ai20M, 16Ai8Ao
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.4 TABLE D Modules 8AO20M, 16AI20M, 16AI8AO Analog Output and Combination Analog Input and Output modules. Note: Assignments are a template showing 16 analog input and 16 analog output channels. Fewer channels may be present on the specific module being installed. -
Page 42: Table E Modules 10Rtd
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.5 TABLE E Modules 10RTD Upper Row Lower Row Term # Function Term # Function EXC-1 EXC-2 SNS-1 (AX0) SNS-2 (AX1) RTN-1 RTN-2 EXC-3 EXC-4 SNS-3 (AX2) SNS-4 (AX3) RTN-3 RTN-4 EXC-5 EXC-6... -
Page 43: Table F Modules 16Isotc
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.6 TABLE F Modules 16ISOTC Panel 10 - 30 VDC User Power RS485 Device Upper Row Lower Row Term # Function Term # Function AX0 – TC 1 (+) Earth AX0 –... -
Page 44: Table G Module 16Iso20M
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.7 TABLE G Module 16ISO20M Upper Row Lower Row Term # Function Term # Function AX0 – Channel 1 (+) AX0 – Channel 1 (-) AX1– Channel 2 (+) AX1– Channel 2 (-) AX2 –... -
Page 45: Table H Module 16Dorly
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.8 Table H Module 16DORLY Upper Row Lower Row Term # Function Term # Function Y0 – Channel 1 (NO) Y0 – Channel 1 (COM) Y1 – Channel 2 (NO) Y1 –... -
Page 46: Table I Module E2-Mix20884-D
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 5.2.9 Table I Module E2-MIX20884-D Equivalent DC Input Circuits Sinking Input Switch Sourcing Input Switch Return - Return - Equivalent Digital DC Power + DC/AC Input Circuit DC Power + (Isolated) Jumper Jumper... -
Page 47: O Functions
9 volts. This is accomplished by soldering a resistor into the wiring base which is located alongside the DI COM jumper. NOTE 1: This modification is recommended for advanced users only. Please contact Red Lion Technical Support regarding details for this modification. -
Page 48: Discrete Input Counter Feature
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Discrete Input Counter Feature Applicable to: E2-MIX24880, E2-MIX24882, E2-MIX20884, E2-32DI24, E2-16DI24, E2-16DIAC Counter Modes: Count Up, Pulse Timing and Pulse Rate To enable counters (16 registers: AX8 though AX23) or (12 registers AX8 through AX19 on E2-MIX20884), using the I/O Tool Kit or the module’s web interface, go to the "Discrete Options"... -
Page 49: High Speed Counters
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module High Speed Counters Applicable to: E2-MIX24880, E2-MIX24882, E2-MIX20884, E2-32DI24, E2-16DI24 High speed counters can be enabled on the first two to four channels. In the web server or I/O Tool Kit software “Discrete Options”... -
Page 50: High Density Discrete Outputs
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module High Density Discrete Outputs Applicable to: E2-32DO24 High density discrete outputs provide: A. Individual maximum outputs rated for 1 Amp per channel, 8 Amps total per module. Short duration inrush current as high as 2 Amps is permissible. B. -
Page 51: Time Proportioned Outputs (Tpo)
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 6.12 Time Proportioned Outputs (TPO) Applicable to: E2-MIX24880, E2-MIX24882, E2-MIX20884-D, E2-32DO24, E2-16DO24 The discrete output channels in all EtherTRAK-2 I/O modules are capable of functioning as time proportioned outputs. Time proportioned outputs pulse ON and OFF with a duty cycle proportional to an analog value stored in a corresponding analog output register. -
Page 52: Ma Analog Input Wiring
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 6.13 4-20 mA Analog Input Wiring Applicable to: E2-MIX24880, E2-MIX24882, E2-MIX20884, E2-32AI20M, E2-16AI20M, E2-16AI8AO The analog input channels accept 4-20 mA signals from a variety of devices and are protected by self-resetting current shunts to prevent shunt overheat/damage. -
Page 53: Analog Outputs
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 6.17 Analog Outputs Applicable to: E2-MIX24882, E2-MIX20884, E2-8AO20M, E2-16AI8AO Analog outputs on all applicable I/O modules in this product family have a 4-20 mA output range and may be incremented (varied) with a full 16 bit resolution corresponding to the value in the associated analog output (AY) register. - Page 54 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module FAULTY (-2000): In this state the module will determine if the CJC sensors are reading realistic values. If one or more of the CJC sensors are reporting unrealistic temperature values then the value reported in the analog registers will be -2000.
-
Page 55: Watchdog Output
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 6.20 Watchdog Output Applicable to: All I/O modules A microprocessor in the module continuously monitors several user-selected system functions. Additionally, an independent CPU watchdog microprocessor in the module also monitors the main CPU and can be used to indicate a failure of the main CPU. -
Page 56: Communications
4. The default state of this configuration option is “follow the Jumper”, so the initial set up can be done with out the configuration of the Red Lion I/O Tool Kit. In the Ethernet configuration screen, and choose one of these four options that is appropriate for your... -
Page 57: Communication Ports Overview
802.11 pin-outs. These ports have fixed unique MAC addresses. The IP addresses can be set with the Red Lion I/O Tool Kit software or through a web browser. Further details are available in the I/O Toolkit documentation or the web browser documentation. -
Page 58: Rs-485 Modes Of Operation
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module The RS 485 port is not isolated (with the exception of the E2/EB-10RTD-D and E2-MIX20884-D), therefore you must use a common power ground between stations in order to connect the 485 signal grounds. Some applications make use of longer distances where a common ground may not be possible. -
Page 59: Ethertrak 2 Status Led's
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module EtherTRAK 2 Status LED’s EtherTRAK-2 LEDs Every EtherTRAK-2 I/O module has an array of LEDs on its front panel. These LEDs can be useful for system diagnostics. These LEDs can be observed in the following states: Power LED Indication Each module has 3 green Power LED’s which are Power 1, Power 2, and PoE. -
Page 60: Alert Led Indication
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Alert LED Indication There is a single ALERT OK which is red in color and is used to display critical errors in the module. The ALERT LED has the following behavior: Full OFF Everything is OK. -
Page 61: Ethernet Link Activity Indication
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module Ethernet Link Activity Indication Each Ethernet port (E1 and E2) has a single corresponding LED which is used to indicate link and activity. The LED’s are green in color and have the following behavior. OFF Completely Unlinked / Disconnected ON Solid... -
Page 62: Configuring Ethertrak-2 I/O Modules
Note: Recommended web browsers are Internet Explorer, Mozilla Firefox and Chrome. When using Internet Explorer please disable native XMLHTTP by going to ToolsInternet OptionsAdvanced. Note: A load through the Red Lion Tool Kit must be done once or I/O channels will not work. Setting the IP Address The default IP address, as shipped from the factory is: 10.1.0.1... -
Page 63: Adding User Documents To The Web Server
Sixnet I/O Tool Kit Software As an alternative to configuring I/O modules with their embedded web server, the Red Lion I/O Tool Kit Windows software may be used. The Windows software is strongly recommended in situations in which multiple devices (RTUs and I/O modules) will be interconnected in a coordinated system. -
Page 64: Ethertrak-2 Module To Wiring Base Keying
® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module 10 EtherTRAK-2 Module to Wiring Base Keying This section is recommended for ADVANCED USERS ONLY that are in need of utilizing an existing wiring base with a different module than as originally received. Wiring bases shipped with I/O modules are pre-configured with their alignment keys in the appropriate position for that type of I/O module. - Page 65 ® ® EtherTRAK 2 and Etherbus Dual Ethernet I/O Module EtherTRAK-2 I/O Module key Configuration table See above diagram for key orientation Part Number Prefixes Part Number (Module w/ Base) Description E2- or EB- MIX24880-D Combination I/O with one isolated input counter (see Note 1) E2- or EB- MIX24882-D...
-
Page 66: Service Information
11 Service Information We sincerely hope that you never experience a problem with any Red Lion product. If you do need service, call Red Lion at +1 877 432-9908 for Technical Support. A trained specialist will help you to quickly determine the source of the problem.
