QUICK START GUIDE
HITRON
CGNV21

Connect to the network

Connect your phones (Optional)

Set up your wireless network (Optional)

Connect the cable port

STEP
Connect your cable outlet to the device's CABLE connector.
2

Connect your phones / fax machines (optional)

STEP
Use the cables to connect your phones and fax machines to the
4
LINE port. Do this only if you ordered phone/ fax service.

Connect wireless computers (optional)

STEP
Y ou can connect computers to the wireless network. Look at the
6
sticker on the bottom of the device, and make a note of the S S ID
and Wireless PassPhrase.
Next, look at the LEDs (lights) on the
front of the device. Wireless LED on, or
blinking? If so, the wireless network is on.
If not, turn the wireless network on by pressing the WPS button on
the side of the device for 1 second.
Press the WPS button more than 5 secconds for WPS function.

Check the box contents

STEP
Read me
1
first!

Connect the power

STEP
3

Connect wired computers (optional)

STEP
5
Open the wireless network connections from the taskbar and select the S S ID
that belongs to the CGNV21 then press "Connect".
Another window will popup, input the Security Key (PassPhrase) assigned to
the S S ID you wish to connect then press Accept.
Look in the box and make sure you have the following:
POWER ADAPTOR
ETHERNET CABLE
Connect the power adaptor to the POWER port.
You can use the included Ethernet cable to connect a computer to
one of the LAN ports.
Once connected, the S S ID will be on the top
of the list and marked as "Connected".
HITRON CGNV21
QUICK S TART GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGNV21 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hitron CGNV21

  • Page 1: Connect To The Network

    LAN ports. Connect wireless computers (optional) Open the wireless network connections from the taskbar and select the S S ID that belongs to the CGNV21 then press "Connect". STEP Y ou can connect computers to the wireless network. Look at the Another window will popup, input the Security Key (PassPhrase) assigned to...
  • Page 2 This equipment complies wit h FCC radiat ion exposure limit s set fort h for an uncont rolled environment . This equipment should be inst alled and operat ed wit h minimum dist ance 20cm bet ween t he radiat or & your body. COPYRIGHT © 2015 HITRON TECHNOLOGIES, INC.
