SGR-1 Antenna Software Setup

Select the GPS Correction

1.
Select
to access the GPS Settings screen.
2.
Select
to access GPS Correction selection.
3.
Use the up and down arrows to select the correction system.
4.
Select
to confirm your selection.
Refer to the AGA3663 System 110/150 Operator's manual
for more information on setting up the different correction
systems.
GX-45 Console
SGR-1 Quick Setup Guide
Part Number AGA4117 Rev. 1.1
This quick setup guide is to be used in
conjunction with the System 110/150
Operator's Manual P/N AGA3663
GX-45 Console SGR-1 Quick Setup Guide AGA4117
Rev 1.1
