SKIMDEVIL Camio SX15 User Manual

Robotic pool cleaner

SKIMDEVIL ROBOT CONTROL

On the robot, Press the ON button

-Two(2) beeps, followed by a beep every 6 seconds means Skimdevil is turned on an awaiting instructions

Pressing START on the robot will commence the preset cleaning schedule

Connect through the App and press START to commence cleaning

-Three(3) beeps means the unit has been shut off.

The screen after a successful connection to the Skimdevil App should look like this:

The line below - the Status Bar - is showing the currently selected function (ie. the time of cleaning, cleaning

intervals and other useful information.) The START, STOP and OFF buttons function exactly the same way

as those buttons on the unit. (Note: Using the red OFF button shuts the unit off completely and you will

have to turn the unit on by pressing ON button on the unit to activate the bluetooth connection.) After

commencing the cleaning process with green START button, the following screen will be displayed:

The blue RC button in the middle is for remote control/manual cleaning. Below is the screen for this function:

The top of the screen displays the current water temperature,

power wattage supplied by solar panels, battery charge status

and strength of the bluetooth signal.

Here you can see that robot is performing All Day Cleaning, is in

use, and 29min and 52 sec left to the Pause. By pressing STOP

button, the cleaning process will be terminated the App screen

will go back to previous picture.

You can control the speed forward and backwards and set it

steady by activating HOLD button. With the right hand button

you can control the left and right directions. This feature can be

used to access specific pool areas for spot cleaning and can offer

great fun and entertainment for the whole family.
