Introduction of the original car display

1. 6.5 -inch LCD screen resolution of 480 * 234.
2. Using the current popular capacitive touch panel, let users experience the
capacitance touch sensitive and convenient.
3. Display and high-speed stability an LVDS signal transmission ensure that
image quality.
4. The car is not with factory GPS navigation and reversing rear camera
system.
5. The radio and monitor is separated version with 4PINS round connector
LVDS system.

Introduction of video interface

For 2013 GOLF7 with hand-written navigation systems, can add after-market
NAVI GPS, mobile digital TV, DVD, reversing camera and parking auxiliary
guideline system.
1. Retain the original car display system; ensure the quality of image display
and sound effects.
2. Use the original car capacitive touch screen for operating after –market
GPS navigation and digital TV and DVD.
3. Directly to get the original touch screen coordinates from the CAN network,,
no need to split and open the monitor , which can touch operate the
after-market NAVI GPS, to keep the car original connection as well as
efficiency and safety.
4. Use the car original buttons MENU to switch video interface.
www.car-solutions.com
2013 GOLF 7 Video Interface
Press MENU: Radio-
RGBS-av1-av2-Radio--
