GATEMAN A200-CH Quick Manual

Quick Guide
Manual
A200 - CH
Digital Door Lock
Install the Front Body on the outside of Door.
F ro nt
1
2
3
4
5
6
(Separate purchase)

Must Read This

※ This product can be included and operated in any Z-Wave network with other
Z-Wave certified devices from other manufacturers and/or other applications.
All non-battery operated nodes within the network will act as repeaters regardless
of vendor to increase reliability of the network.
※ This product(A200-CH) is Z-Wave security enabled device.
※ Security Enabled Z-Wave Controller must be used in order to fully utilize
this product.

Parts - Front (Front body)

1
Keypad(10- Key)
2
Battery Change Lamp
3 CardKey reader
4
Pull bar
5
Reset
6
Emergency power supply terminal

Parts - Back (Main body)

7 1.5V AA Alkaline batteries
Registration button
8
9 SD Card Slot
10 Auto / Manual relock setting button
11 Volume switch
12 Internal forced lock switch
13 Lock status check lamp
14
Push bar
※ SD Card Slot can be used for camera function adopted models only.
Please do not put anything, if product is not a camera model.
Install the Back Body on the inside of door.
Ba ck
7
8
9
MICRO SD CARD
10
11
12
13
14
15
Safe button
15
Battery cover
16
17
Slot for Remote controller module (Option)
Mortise
18
Door status check sensor
19
Hook deadbolt
20
Double swing latch bolt
21
16
17
