Roland DS-5 Owner's Manual

OWNER'S MANUAL
Thank you for purchasing the Roland Bi-Amp Monitor DS-8/7/5.
201b
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3, 4), and "IMPORTANT
NOTES" (p. 5). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a
good grasp of every feature provided by your new unit, Owner's manual should be
read in its entirety. The manual should be saved and kept on hand as a convenient
reference.
Main Features
● In Pursuit of High Sound Quality
The DS-8/7/5 powered monitor uses a two-way, bi-
amplifier design to achieve high sound quality.
The LF driver and dome HF driver use separate amps
sections for LF and HF, ensuring optimal sound quality.
In particular, the DS-8/7 feature completely discrete DC
power amps for the highest possible quality.
● Analog Input
In addition to an XLR connector, which provides for
balanced input, a 1/4" TRS phone jack accommodating either balanced or unbalanced input
is also provided. This assures broad-ranging connectivity.
● Digital Input
The digital inputs (coaxial and optical) support 24-bit digital audio data at sampling rates up
to 192 kHz. AES/EBU professional audio format digital input is also provided.
Digitally input signals are reproduced faithfully through 24-bit D/A conversion, thus
preventing noise or a drop in sound quality.
You can use the monitors with a wide variety of equipment and applications through
selective use of the analog and digital settings.
● Magnetically Shielded Low- and High-Frequency Drivers
This allows you to use the speakers next to CRT displays.
