OWNER'S MANUAL
Red Ember Willow Aluminum Square Propane Gas Fire Pit Table/
Red Ember Juneau 44 in. Square Aluminum Fire Pit
SKU WTL257-1/WTL302-1
Supplier Item #: 62404/62416
Conforms to ANSI Z21.97-2014/CSA STD 2.41-2014
Outdoor Decorative Gas Appliances
R
R
1
WARNING
This product can expose you to chemicals
including carbon monoxide which is known to the
State of California to cause birth defects or other
reproductive harm. For more information go to
www.P65Warnings.ca.gov.
R
C
US

Advertisement

loading
Need help?

Need help?

Do you have a question about the WTL257-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Red Ember WTL257-1

Summary of Contents for Red Ember WTL257-1

  • Page 1 OWNER’S MANUAL Red Ember Willow Aluminum Square Propane Gas Fire Pit Table/ Red Ember Juneau 44 in. Square Aluminum Fire Pit SKU WTL257-1/WTL302-1 Supplier Item #: 62404/62416 WARNING This product can expose you to chemicals including carbon monoxide which is known to the State of California to cause birth defects or other reproductive harm.

  • Page 2: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Burner Cover Table Top Burner Burner Bracket Side Panel 1 Side Panel 2 Side Panel 3 (Burner Controls) Side Panel 4 Door Frame) Guard Bar Gas Tank Bracket Gas Tank Support Bolt 8 60mm Nut M8 Washer Spring Washer Bolt 6 25mm Washer Screwdriver Wrench...

  • Page 3: Hardware Contents

    HARDWARE CONTENTS Bolt(8*60mm) Bolt (6*25mm) Screwdriver Nut(M8) Washer Washer Spring washer Qty. 8 Qty. 4 Allen wrench Glass beads Bolt (6*22mm) Wrench Washer Qty 1 Qty. 4 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product.
  • Page 4 SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This fire pit is a combustion appliance. All combustion paper or cardboard, a safe distance away from the appliances produce carbon monoxide (CO) during the fire pit as recommended by the instructions.
  • Page 5 SAFETY INFORMATION WARNING WARNING BURN HAZARD fire pit unattended when hot or in use. is invisible, odorless, and flammable. An odorant is normally added to help detect leaks and can be described as a rotten egg smell. The odorant can fade over time so leaking gas is not always detectable WARNING by smell alone.
  • Page 6 ASSEMBLY INSTRUCTIONS 1. Connect Side Panels E/F/G/H using Bolt (6*25mm) and Washer (M). Loosely tighten with Allen Wrench (P). Make sure that Panel G is positioned as seen in the figure for Step 1 as the hole will be used for the Connecting Rod to operate the burner controls.
  • Page 7 ASSEMBLY INSTRUCTIONS 3. Place the Burner Bracket (D) onto the assembled panels. Make sure the burner controls are facing towards Side Panel 3 (G) with the small hole and set Burner (C) into Burner Bracket. Remove the Cotter Pin from the end of the Connecting Rod (S), then insert the Connecting Rod (S) though the hole in Side Panel 3 (G) and burner control into the Burner (C).
  • Page 8 ASSEMB LY INSTRUCTIONS 5. Pour the Glass Beads (Q) around the Burner (C). Be careful not to obstruct pilot light housing. Put the Burner Cover (A) on the Burner when the fire pit is NOT is use. When completely cooled, you may cover the fire pit with the Protective Fire Pit Cover (R).
  • Page 9 ASSEMBLY INSTRUCTIONS A dented , rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a p ropane cylinder with a damaged valve connection. The propane cylinder must be constructed and ma rked in accordance with the specifications f or LP gas cylinders of the U.S.
  • Page 10 NEVER perform a leak test when smoking. Underside of burner...
  • Page 12 OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When fire pit is ON: Burner will display tongues of blue and yellow flame.

  • Page 13: Care And Maintenance

    OPERATION INSTRUCTIONS 9. Fire pit is away from gasoline or other flammable liquids or vapors. 10. Fire pit is away from windows, air intake openings, sprinklers and other water sources. 11. Fire pit is at least 24 in. on rear and at least 24 in. on sides from combustible materials. 12.
  • Page 14 Caution: Always allow fire pit to cool before attempting service.
  • Page 16 (866-985-7877) 5 YEAR LIMITED WARRANTY – Customers in the Continental US All components are warranted for a period of 5 years after date of purchase by the original owner against defects in materials and workmanship under normal use. This warranty does NOT cover normal wear and weathering, assembly and/or maintenance OR use in a commercial application if model is not designated as a commercial model.
