About The Cover Photo; Revision History - Applied Data Systems Bitsy User Manual

Revision History

ADS document # 110111-1003A.
REV
1
A

About the Cover Photo

The cover photo shows a fully populated Rev B Bitsy with 16MB of onboard flash.
ADS document # 110111-1003A
DESCRIPTION
Initial release
Correct Header Information
1.2:
Clearify Features
1.3:
Update Block Diagram
J7:
Add Illustration for pin locations
J1:
Add note
Correct Pin 28 description
J3:
Modify Descriptions for Pin 1, 2, 16 and 18
J6:
Modify Pin 1 description to 5-12V
Added 4.1.3 Using Compact Flash Interface
Added 4.1.4 Using USB Interface
4.3.1:
Modified Maximum voltage 10 12V
4.3.2:
Modified to maximum 12V
4.3.7:
Added notes
4.4:
Removed VDDI (1.75V) and +30V for J3
and Panel VEE for J1 from table
4.5:
Corrected mA reference for fully populated
board
Removed footnote 1
4.7:
Added Protection
4.8:
Added information to 4.8.1 Analog Inputs
Added SA1111 information
5.1.2:
Corrected Rev B description to 12V
Bitsy User's Manual
DATE BY
06/20/01 HW
07/03/01 PD
Page i
