HD262
True Day/Night Indoor Fixed
Minidome Camera with IR LEDs

Quick Installation Guide

800-11990 - B - 06/2012

1. Warnings and Cautions

WARNING
Installation and servicing should be performed
only by qualified and experienced technicians to conform to all
local codes and to maintain your warranty.
WARNING
24 V AC/12 V DC cameras require the use of CSA
Certified/UL Listed Class 2 power adapters to ensure
compliance with electrical safety standards.
WARNING
This device is configured for 24 V AC or 12 V DC
operation. Do not connect to a higher voltage. Use only with
NRTL-approved Class 2 power supplies.
CAUTION
The light emitted from the near-infrared light emitting
diodes (LEDs) provide illumination over a wide area. This light is not
considered a risk to the unshielded human eye. However, as with any
light source, it is recommended that normal precautions be taken to
avoid unnecessary exposure. For example, avoid staring into the beam or
viewing the LEDs directly with optical instruments at close range.
CAUTION
IR LEDs may be warm after prolonged use.
THIS SYMBOL INDICATES THAT
CAUTION
DANGEROUS VOLTAGE
RISK OF ELECTRIC
CONSTITUTING A RISK OF
SHOCK
ELECTRIC SHOCK IS PRESENT
DO NOT OPEN
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
THIS SYMBOL INDICATES THAT
SHOCK, DO NOT REMOVE THE COVER.
IMPORTANT OPERATING AND•
NO USER-SERVICEABLE PARTS INSIDE.
MAINTENANCE INSTRUCTIONS
REFER SERVICING TO QUALIFIED SERVICE
ACCOMPANY THIS UNIT.
PERSONNEL.
FCC Compliance Statement
Information to the user: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
CAUTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Canadian Compliance Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada.
Warranty and Service
Subject to the terms and conditions listed on the Product warranty, during the warranty
period Honeywell will repair or replace, at its sole option, free of charge, any defective
product returned prepaid.
In the event you have a problem with any Honeywell product, please call Customer Service
at 1.800.796.CCTV for assistance or to request a Return Merchandise Authorization (RMA)
number.
Be sure to have the model number, serial number, and the nature of the problem available
for the technical service representative.
Prior authorization must be obtained for all returns, exchanges, or credits. Items shipped
to Honeywell without a clearly identified Return Merchandise Authorization (RMA)
number may be refused.

2. Important Safety Instructions

Read and keep these instructions.
Please ensure that your installation area can safely support the
weight of the camera.
Do not install the camera in extreme temperature conditions.
Only use the camera where temperatures are within the limits
shown in the specifications section of the guide. Be especially
careful to provide ventilation when operating under high
temperatures.
Do not aim the camera toward an extreme light source to
prevent damage to the CCD.
This camera is rated for indoor operation. Do not expose this
camera to rain or moisture.
Do not touch the camera lens, dome, or bezel (front glass
plate).
Do not drop the camera or subject it to physical shock.
Do not use a strong or abrasive detergent when cleaning the
camera.
800-11990 - B - 06/2012
