360 degree Omnidirection Camera
NM33D-F
Dome Type
Model :
User's Manual
Thank you very much for purchasing the 360 degree omnidirection camera
NM33D-F. Please read this manual carefully before using the product for
proper operation. Preserve this manual and use this when it is necessary.
◆ The description may be modified without any notice.
V. 1.30
Page 1
Advertisement
Table of Contents
Related Manuals for OPT Corporation NM33D-F
Summary of Contents for OPT Corporation NM33D-F
- Page 1 User’s Manual Thank you very much for purchasing the 360 degree omnidirection camera NM33D-F. Please read this manual carefully before using the product for proper operation. Preserve this manual and use this when it is necessary. ◆ The description may be modified without any notice.
- Page 2 For Safety Use – Warning Please read this manual carefully before using the product for proper operation. The followings are very important notices for the safety use of the product. Make sure to follow the instructions described here. Neglecting the instruction may cause death or Warning ！...
-
Page 3: Other Remarks
• OPT Corporation is not responsible for any loss or missing of the taking image. • Don’t block the product with other items from the easiness for the maintenance and the heat radiation purpose. - Page 4 １．Contents (1) Camera (NM33D-F) : 1 pc (2) Camera Fixing Screw (3.5 × 20) : 2 pcs (3) AC Adaptor (5V2A) : 1 pc Caution: Use only the AC Adaptor (5V, 2A) originally supplied with the product. (4) USB Extension Cable (3 m) : 1 pc Note: According to the package you purchase, other accessories may be enclosed.
-
Page 5: Name Of Part
２．Name of Part ① ③ ④ ② ⑤ ⑫ ⑥ ⑪ ⑦ ⑧ ⑨ ⑩ ⑭ ⑬ 《 view with Bottom Cover on 》 《 view with Bottom Cover off 》 Name of Part ① Dome Cover ⑧ Bottom Cover Fixing Screw （3 places） ②... -
Page 6: Dome Cover
３．Construction of Camera ① Bottom Cover ② Dome Base ③ Dome Inner Cover ④ Dome Cover ① Bottom Cover This is necessary to place the camera on the table. Remove it when installing the camera on the wall or under the ceiling. ②... - Page 7 4．Advice for Installing Camera ① when Installing on the wall or under the ceiling Remove Bottom Cover when installing the camera on the wall or under the ceiling. Please refer to the section 6 for the installation. For the Installation vertically, align USB Packing downward. (Ceiling) (Wall) USB Packing...
- Page 8 ５．Advice for Cable Lining In a normal case, BNC/DC Cable would like to be located behind the camera bottom with Bottom Cover taken off. If installing the camera on a concrete wall (no room behind the wall), it is impossible to line the cables behind the camera.
- Page 9 ６．Installation (Ceiling, Wall) - Preparation ① Remove Bottom Cover Remove Bottom Cover Screws and remove Bottom Cover from Dome Base. ② Remove Dome Cover and Dome Inner Cover Hold Dome Cover and Dome Base firmly by hands, rotate Dome Cover counterclockwise to remove Dome Cover from Dome Base.
- Page 10 ６．Installation (Ceiling, Wall) – Mark the install position ③ Mark at the place to install the camera and make a through hole for lining the cables. Make a through hole of （Φ30mm）at the center of the place to install the camera. Through hole (φ30 mm) to line the cables Outer diameter of the...
- Page 11 ６．Installation (Ceiling, Wall) – Fixing the Camera ④ Line the cables in the hole and fix Dome Base Lining BNC/DC Cable in the hole, push Dome Base against the installation surface, then fix Dome Base to the ceiling or wall by Camera Fixing Screws. Note 1: The Camera Fixing Screws provided with the camera are for the plaster board.
- Page 12 ６．Installation (Ceiling, Wall) – Connecting Cables ⑤ Connect Signal and Power Connectors Connect AC Adaptor and BNC cable to the connectors of BNC/DC Cable as shown in the below figure. AC outlet (separate construction） AC Adaptor BNC/DC Cable BNC female connector (separate construction) Note 1: If excessive load is applied on the connection of BNC/DC Cable or AC Adaptor, the power line may be disconnected.
- Page 13 ７．Adjust Output Image ① Connect the camera to a PC Connect the camera with a PC by the enclosed USB Extension Cable (between USB Socket and the USB port of the PC. PC for adjustment Camera Enclosed USB Extension Cable Ferrite Core Note 1: If using AC Adaptor simultaneously with USB power, supply of power from AC Adaptor must be done before connecting USB Cable.
-
Page 14: Troubleshooting
８．Trouble Shooting If you are facing any trouble with the product, please check the followings. Phenomenon Please Check No image output Is the power provided to the camera properly? Are the cables connected properly? Is the power to the recorder or the monitor turned ON properly? →... -
Page 15: Specification
９．Specification Items Value Remarks Product 360 degree Omnidirection Camera ( Model : NM33D-F ) Power Voltage： 5.00 V ± 5% （ Absolute Maximum Rated Voltage:：-0.3 ～ 6 V） Maximum Current Consumption : 500 mA Dimensions Size : 122.5(W) x 122.5(D) x 93.7(H) [mm] Weight : 400 g 5 ～... - Page 16 １０．Appearance ［Unit：mm］ ( Camera ) φ70 φ122.5 ※ Length of BNC/DC Cable Whole length (A - C) : 430 mm Exposed length (B - C) : 350 mm 《 view with Bottom Cover off 》 ( AC Adaptor ) Page 16...
