Model : User’s Manual Thank you very much for purchasing the 360 degree omnidirection camera CFC-360F-IP. Please read this manual carefully before using the product for proper operation and your safety. Preserve this manual and use this when it is necessary.
Contents: Contents............................1 Operating Environment ........................1 Name of Part..........................2 Advice for Installing Camera (under Ceiling)..................3 Installation of Application Software ....................5 Connection (Initial Setting) .......................7 PC IP Address Setting ......................7 Connection ..........................10 Setting of the “DDIPS Viewer”....................11 Connection (Personal Setting) .....................14 Change of the setting value for camera ................14 Connection ..........................16 Setting of the DDIPS Viewer ....................16...
Page 3
For Safety Use – Warning Please read this manual carefully before using the product for proper operation. The followings are very important notices for the safety use of the product. Make sure to follow the instructions described here. This product is a general operating-oriented product and not designed to treat people's life, property, and etc…...
Page 4
For Safety Use – Caution & Remarks Neglecting the instruction may cause risks of Caution ! injury or property damages. • Installation or wiring of the product must be done with the power off. Otherwise it may cause fire, electric shock, or injury. •...
Contents (1) Camera (CFC-360F-IP) : 1 pc (2) Application CD : 1 pc D・DIPS Operating Environment OS: Windows XP SP1 and later, Windows Vista, Windows 7 PC: The environment for proper functioning for the above OS and the below listed hardware specification.
Advice for Installing Camera (under Ceiling) (1) Drill a through hole of φ100 mm at the suitable place of ceiling to install the camera. (2) Line a LAN cable come through the hole. (3) Connect the LAN cable to the Network Connector (②) of the camera. →...
Page 8
(4) Insert the camera into the hole with pushing three Blade Springs (③) toward the camera body. φ100 mm Push three Blade Springs toward the camera body. Push three Blade Springs toward the camera body. Applicable thickness of the ceiling board is 5~25 mm Note 1: Applicable thickness of the ceiling board is 5~25 mm.
Installation of Application Software ① Execute “DDIPSInst” in the enclosed CD. ② The following window will open. Click 「次へ」. ③ The following window will open. Assign a folder to install the file, and then click 「次へ」. ④ Click 「次へ」 at the following window.
Page 10
⑤ Installation is executed. ⑥ When the following window is indicated, the installation is completed. Click 「閉じる」 to end up the process. The below icon will appear on the display.
Connection (Initial Setting) The setting process explained here indicates how to connect the Camera to your PC 1:1 directly with keeping the IP address of camera as the default setting. PC IP Address Setting The default value for the IP address of the camera is the following: IP address 192.168.1.100 Sub net mask...
Page 12
(4) “Local Area Connection Properties” is indicated. (5) Select “ Internet protocol (TCP/IP)” and click “Properties” (6) “Internet Protocol (TCP/IP) Properties” is indicated.
Page 13
(7) Check at “Use the following IP address” and type the IP address as following. (8) Click “OK”. (9) Click “Close”.
6.2 Connection (1) Connect the “DATA+PoE” port of the PoE supported HUB with the camera by an Ethernet cable of Category 5e and more. (2) Connect the [DATA] port of the PoE supported HUB with the PC. (3) Power ON the PoE supported HUB. (4) Check the connections.
6.3 Setting of the “DDIPS Viewer” “DDIPS Viewer” is an application software to monitor the image from the camera. With the following process, register the camera to connect on the “DDIPS Viewer”. (1) Start up the “DDIPS Viewer” (2) The following window is indicated. (3) Click “Setting”.
Page 16
(4) Directly type as the followings. Server Name Camera1 IP/DDNS 192.168.1.100 Port 7501 User ID root Password root As the Server Name, you can type an arbitrary easy name. In the above, “Camera1” is Note: an example name. After you complete the input of values, click the “Add” button. The information you set is registered in the Camera List.
Page 17
(6) Click the “Connect” button in the Viewer screen. The image from the connected camera is indicated in the screen. (The mode of image to be indicated depends on the setting of the camera.) (7) Click the “Connect” button again to disconnect the connection.
Connection (Personal Setting) If connecting the camera in the LAN environment, it is required to set the IP Address of the camera to be identical to the specified IP address. In this section, it is explained to change the camera IP address information into the below example and connect to a PC.
Page 19
(3) Type “root” in both of the ID frame and the Password frame. **** is indicated in the Password frame. (4) Click the “Apply” button. (5) “Admin Tool” is indicated, in which the setting value for the camera can be changed. The values currently applied are indicated for the IP Address and other factors.
(7) After complete to type, click the “Apply” button. (8) When “Setup Data sent!” is indicated, click the “OK” button. (9) If “Setup Data sent!” is indicated, click the “OK” button. Now, the process of changing the camera setting value is completed. When re-start the camera (by turning OFF/ON the power for PoE supported HUB), the system will start working with the newly set values.
Connections (connect to the multiple number of cameras) In this section, it is explained to connect multiple number of cameras with one PC in a network. 8.1 Registration the camera to the DDIPS Viewer (1) First, open the Setting window of the DDIPS Viewer. Assume that one camera of the below IP Address: 192.168.1.100 has been registered.
(4) After completed the typing, click “Add”. The new information is added into the Camera List. (5) Click “OK”. 8.2 Connection to the newly registered camera (1) Open the Setting window of the DDIPS Viewer. (2) Check that the information in the above RED frame is the newly registered camera information. If the information in the RED frame is the one of other camera and the information of the newly registered camera is indicated in the below list (RED arrow in the above Figure), double clicking the camera information to operate will indicate it in the above area.
(4) Click “Connect” again to display the image from the newly added camera. (5) Click “Connect” again to disconnect the connection. 8.3 Switch the Cameras If you want to see the image from another camera, click “Setting” and double click the camera to select in the Camera List.
About the Software 9.1 DDIPS Admin This is a software to handle the setting of the camera. Note: When setting, connect the camera with a PC one by one. Please refer to the description in the section 2. Connection (Initial Setting), and set the IP address of the PC to the same group of the IP address of the camera.
(3) Input the setting information IP Address : type the IP Address of the camera to access. Default value : 192.168.1.100 Port : type the port number of the camera to access. Default value : 7502 (using port No. is 7501~7505, and the second value 7502 is used for the setting.)...
(5) Type the setting information. ID : type the ID of the camera to access. Default value : root Password : type the password of the camera to access. Default value : root Note: Password is indicated as “ **** “. (6) After complete the typing, click “Apply”.
Page 27
■ Server Name Change Type an arbitrary camera name. Default value : NM33 IP-T ■ Remote Service Port Number Type the first port number to be used by the camera. (One camera can use 5 ports.) Default value : 7501 ■...
Page 28
(3) User Setting Do the setting of the user information, who can access to the camera. Check the left frame of the “User Setting Change”. The setting becomes possible with a RED check mark. Note: The number of users possible to access to one camera is up to 5. ■...
9.2 DDIPS Viewer This is a software to access to the connected camera. As well as monitoring the image from the camera, controlling the camera is possible. Double click “DDIPS Viewer” on the desktop, and the Viewer is indicated as below. 2...
4X : tetrameric screen : Indicate the images from up to 4 cameras . Full : full size screen : Indicate the image in the maximum size of the display. 9.2.3 Date (③) Indicates the current date and time. 9.2.4 Network (④) Indicates the condition of the camera currently connected.
9.2.5 Camera Control Panel (⑤) (1) P/T/Z Operation Panel This is the panel to control the Pan/Tilt/Zoom of the camera. Operation Buttons: Buttons to move the zoom area (the center button is not functional). Zoom Button / Auto Pan Bar : Zoom In : click to zoom-in.
About the Switching the camera mode The image mode of the camera can be switched by the “Menu” button and the “Select” button in the DDIPS Viewer in the following order. To be switched by the Menu button switched by the Select button Wide Mode Zoom area Panorama Mode 2...
9.2.6 Main Operation Button (⑥) (1) Connect : To connect with the camera selected by the Setting procedure. Click to connect and another click to disconnect the connection. (2) Setting - Connect : To add, delete, and change the information of the camera to be connected as well as to select the camera to be connected.
Edit, Save Button : To change any camera information registered in the Camera List. Click the camera name among the Camera List to change, and click the “Edit” button to change. The information of the selected camera is indicated in the Input / Indication area, then change the information.
Page 35
Note : The capacity of the image from the camera through DDIPS is approx. 600 Kbyte/s. But it depends on the line condition and the camera mode. Note : To confirm the setting, click the “OK” button. To confirm the set value, click the “OK” button. (4) Capture : To save the still image by clicking this button when the image is monitored.
(4) Record : To record the monitored camera image. The recorded image can be played back by the “DDIPS Player”. ① Click the “Record” button. The “Saving Image” is indicated. ② Select the folder to record the data, type the file name, and click “Save”. ③...
Page 37
② Date : to indicate the current date / time and the time of play back. Date indicator : indicates the current date and time. Play back time : indicates the playback time. ③ Controller : to control the playback image. Reverse Play : playback in reverse.
Double click the file name to select. Product Specification Item Description Product Name 360°camera (model: CFC-360F-IP) Lens Object distance: 0 ~ infinity mm (from the surface of lens) Angle of view: 180+360 degree Image sensor 1/2 inch Single-panel CMOS color method (RGB primary colors) Effective Pixels: H:2048 ×...
