- Page 1 LS6000 Logic Net eStation Kitchen Video Controller with Ethernet Interface USER MANUAL AND INSTALLATION GUIDE...
- Page 2 This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Logic Controls cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product.
- Page 3 7. We recommend all servicing done on this product be done by qualified service personnel. Aside from upgrades or swapping out the compact flash please refer all other servicing to the Logic Controls RMA Dept or a repair provider that has been certified by Logic Controls.
-
Page 4: Table Of Contents
TABLE OF CONTENTS FEATURES ......................1 PRODUCT DESCRIPTION..................3 CONNECTOR PINOUTS..................5 HARDWARE INSTALLATION ................6 LS6000 SETUP AND SELF-DIAGNOSTIC TESTS ..........7 SYSTEM SETUP ....................10 TROUBLE SHOOTING ..................11 SOFTWARE DEVELOPMENT ................13 SPECIFICATIONS.....................14... -
Page 5: Features
FEATURES The LS6000 Logic Net eStation is the Ethernet version of Logic Net, the industry’s leading kitchen video display system solution. It has succeeded the advantages of Logic Net and yet facilitates network implementation with the most popular Ethernet connections. - Page 6 » Minimize Obsolescence Problems • Upgrade LS6000 units with remote downloadable firmware and character fonts » Extensive Free Software Development Support • High-level language software utilities allow developers to write application software with Visual Basic or Visual C++ • OCX control covers all of the Logic Net's command sets •...
-
Page 7: Product Description
VGA monitor and to read key codes of keys entered on the keyboard. RESET Button Press the RESET button located on the front of the LS6000 to reset the unit and access Setup or self-diagnostic tests. Power/Status LED The power/status LED is located on the front of the LS6000. - Page 8 AC. Operation at any voltage within these ranges will meet the output requirements and will not cause damage to the supply. The power supply output is connected to the LS6000 with locking connectors. Nominal Voltage: 100–240 V AC...
-
Page 9: Connector Pinouts
CONNECTOR PINOUTS Ethernet interface (8 pin RJ45 connector with 2 LED indicators) RS-232 interface (9 pin DSUB male connector) RS-232 interface (8 pin RJ45 connector – EIA-561 pin out) Keyboard interface (6 pin RJ-11 connector) DATA No connection Signal GND +5 V dc Chassis GND VGA interface (15 pin DSUB female connector) -
Page 10: Hardware Installation
Component Placement The following is recommended when you plan the Logic Net setup: • Place the LS6000 so that you can use the mounting brackets located at the bottom of the unit. • Place the LS6000 so that the RESET button is accessible. -
Page 11: Ls6000 Setup And Self-Diagnostic Tests
LS6000 SETUP AND SELF-DIAGNOSTIC TESTS Each time the LS6000 is powered on, it will run a self diagnostic and display the system information on the screen. There is also a ROM-based setup and diagnostic program that is used to set system parameters and provide problem determination information. To enter the... - Page 12 If device driver is enabled, this will setup and test the device with the driver. If device driver is disabled, connect a wrap plug to the port for testing serial port function. If the test fails, the LS6000 is not able to work with the attached RS-232 device. If the test is passed but the port does not work with the peripheral device, check the serial cable for proper connection and pin-out.
- Page 13 LS6000 and host server. Check the IP settings and Ethernet cable connections. Note that the LS6000 and host server must be in the same IP group. EXIT menu 1. Exit and Save: Save the changes made and exit setup.
-
Page 14: System Setup
Verify that the values on the boot up screen shows the correct set up values. If not, repeat step 2 to 5 to correct the settings. The setup for one LS6000 is now completed. Repeat as necessary for each LS6000 in the system, ensuring a unique IP address for each LS6000. Always verify the setting on the boot up screen. -
Page 15: Trouble Shooting
3. Check that the VGA cable is plugged in properly. 4. Check that the LS6000 is properly connected to its power supply adapter. 5. If the LS6000 is connected to a power supply but the power LED is off, replace the power supply. - Page 16 1. Check the keyboard cable connections at both the keyboard and the LS6000. Unplug the cable and re-insert fully. Check whether it snaps in correctly. 2. Reset the LS6000 and hit [Del] or [Down Arrow] key at boot up screen to enter setup. Navigate to the LS6000 DIAGNOSTIC menu and start the Keyboard test.
-
Page 17: Software Development
Logic Net eStation command set. The command set is available to software developers on request. As the LS6000 is derived from Logic Net, software development support tools are similar to those for Logic Net, such as the OCX control. Application software written for Logic Net can be easily converted to work with LS6000 with minimal changes. -
Page 18: Specifications
SPECIFICATIONS MECHANICAL INTERFACE Weight 2.25lbs To host server Ethernet 10BaseT Dimension (in Inches) 6.3W x 1.0H x 5.1D VGA Port Standard VGA Keyboard Serial Port RS232C ELECTRICAL (Power Adapter) Baud Rate 2400, 4800, 9600, 19200 Input voltage 100 to 240VAC Parity None Input frequency...
