REQUIRED TOOLS: (Not Included)/OUTIL(S) REQUIS : (Non compris)
•
Phillips head screwdriver/Tournevis de type Phillips
SKU 3217708
Darcey Cast Iron Daybed/
Lit De Jour En Fonte Darcey
Assembly/Assemblage
Customer Relations/Service à la clientèle: (800) 245-4595
Email/courriel: customerservice@pier1.com
Find assembly instructions and more at pier1.com/Instructions d'assemblage et plus sur pier1.com
PARTS: (Included)/PIÈCES : (Comprises)
Made in China/Fabriqué en Chine
Distributed by Pier 1 Imports
Fort Worth, Texas 76102 USA
LABEL
DESCRIPTION
ÉTIQUETTE
SIDE LEG/
A
PATTE LATÉRALE
TOP/
B
MODULE SUPÉRIEUR
BACK/
C
DOSSIER
5/16" HEX BOLT CAP/
D
ÉCROU HEXAGONAL 5/16 PO
5/16" FLAT WASHER/
E
RONDELLE PLATE 5/16 PO
5/16" OPEN END WASHER/
F
RONDELLE OUVERTE 5/16 PO
5/16"
x 1-9/16" CROSS HEAD SCREW/
G
VIS CRUCIFORME
5/16 PO
x 1-9/16 PO
5/16"
WRENCH/
H
CLÉ
5/16 PO
PAGE 1 OF/DE 2
QTY
ILLUSTRATION
QTÉ
2
1
1
8
10
10
10
1
830
Advertisement
Table of Contents
Related Manuals for Pier 1 Imports Darcey Cast Iron Daybed
Summary of Contents for Pier 1 Imports Darcey Cast Iron Daybed
- Page 1 PAGE 1 OF/DE 2 Darcey Cast Iron Daybed/ Lit De Jour En Fonte Darcey Assembly/Assemblage PARTS: (Included)/PIÈCES : (Comprises) REQUIRED TOOLS: (Not Included)/OUTIL(S) REQUIS : (Non compris) • Phillips head screwdriver/Tournevis de type Phillips LABEL DESCRIPTION PICTURE ÉTIQUETTE ILLUSTRATION QTÉ...
- Page 2 PAGE 2 OF/DE 2 Darcey Cast Iron Daybed/ Lit De Jour En Fonte Darcey Assembly/Assemblage Ensure that all bolts are tightened before use. Check and tighten all bolts periodically throughout use of the product. S’assurer que tous les boulons sont serrés avant d’utiliser le produit. Vérifier et serrer périodiquement les boulons tout au long de la durée de vie du produit.
