AutoGate VPG-24 (LM) Installation & Operation Manual

Vertical pivot gate (vpg) system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation & Operation Manual
VPG Operator-24 (LM)
This product is to be installed and serviced
by a trained Gate Systems Technician only.
Contact AutoGate for a local professional in
your area.
1.800.944.4283
Vertical Pivot Gate (VPG) System
AutoGate Technical Support
AutoGate, Inc.
7306 Driver Road
P.O. Box 50
Berlin Heights, OH 44814
PH: 1.800.944.4283
FAX: 419.588.3514
www.AutoGate.com
Before attempting to install, operate or
maintain the operator, you
fully understand this manual and follow all
safety instructions.
MUST
read and
JULY 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPG-24 (LM) and is the answer not in the manual?

Questions and answers

Related Manuals for AutoGate VPG-24 (LM)

Summary of Contents for AutoGate VPG-24 (LM)

  • Page 1 This product is to be installed and serviced maintain the operator, you MUST read and by a trained Gate Systems Technician only. fully understand this manual and follow all Contact AutoGate for a local professional in safety instructions. your area. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 2: Safety Information

    Safety & Helpful Information AutoGate and the industry has endorsed three voluntary safety standards related to automatically operated gate systems. In the United States, UL 325 addresses the manufacturing and installation of gate openers and in Canada the standard is CSA 22.2 no. 247-14. ASTM F2200 addresses the design and construction of gates for vehicular traffic that are to be automated.
  • Page 3 This operator is provided with Type A built into the control board. The installer is required to install additional entrapment protection devices in each entrapment zone. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 4: Check Off List For Installer And End User

    IT IS RECOMMENDED THAT END USER & INSTALLER MUST RETAIN A COPY OF THIS CHECK OFF LIST FOR THEIR RECORDS 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 5: Table Of Contents

    Preparations Prior to Installation 12-14 Installation 15-17 DC & AC Power Connecting, Operator Testing 18-21 Accessory Components 22-23 Troubleshooting & Checking Control Board 24-25 Electrical Quick Check Guide Control Board Layout Maintenance 28-30 Drawings 31-42 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 6: Warning Instructions

    3. At NO time should the Gate Panel/Drop Arm be modified in any way. 4. Do not add any additional weight to the Gate Panel/Drop Arm without contacting AutoGate first. This can affect the balancing and operation of the system.

  • Page 7: Safety Instructions For Primary & Secondary Entrapment Protection

    APPROVED SECONDARY ENTRAPMENT DEVICES PHOTO BEAMS 1)EMX INDUSTRIES MODEL#: IRB-325 TRANSMITTER / RECEIVER TYPE 2)ALLEN BRADLEY MODEL#: 60-2728 RETRO-REFLECTIVE TYPE 3)OMRON / MMTC MODEL#: E3K-R10K4-NR RETRO-REFLECTIVE TYPE REVERSING EDGES (CONTACT EDGES) MILLER EDGE MODEL— ME-120 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 8: Safety Instructions For Installers & Owners

    DO NOT affix any adhesive material within 30 days of receiving the system.  DO NOT attach anything to the gate over four (4) pounds total weight or four (4) square feet without consulting AutoGate for re-balancing instructions. The gate must remain balanced to ensure safe and reliable operation. ...

  • Page 9: Orientation

    ORIENTATION The AutoGate Vertical Pivot Gate (VPG) in this manual you will see it referred to as “system” .The VPG has many features that make it effective, reliable, and easy to use, and some of these important features are summarized in the table below. Note that not all systems are identical as width, gate panel implementation, finish, accessories such as lights, and other accessory component options vary order to order.

  • Page 10: Orientation

    Cycle Counter Drive Motor Drive Pullies (“Bullwheels” ) NEMA 4x Electrical enclo- Electrical sure is hiding the Enclosure 2nd Bullwheel Battery Shelf Slide Assembly GFCI Service Outlet (120 VAC, 15A Pivot Shaft Footpads Extension Springs 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 11 LED warning lights on the Gate Panel/Drop Arm. Pre-installed amp meter and cycle counters are a standard on all systems from AutoGate with the Liftmaster Control Board..

  • Page 12: Preparations Prior To Installation

    4’ X 7’ Operator Pad Options: Full Pad, Minimum depth of 36" or below local frost line 10"-12” thick pad with five (5) 12" dia. x 36" deep holes or below local frost line 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 13 If you are constructing the loops on-site, be certain to use D.O.T. approved materials and methods. Test the function of the loops thoroughly by using vehicles once installed to verify correct operation Figure 2.4 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 14 DO NOT REMOVE T/M PIN. ONLY REMOVE HAIR PIN RETAINER TO REMOVE THE KEYS THEN REPLACE HAIRPIN. (See Figure 2.3) 4. Any transmitter, antenna, or other ordered accessories will be boxed inside your operator cabinet. 5. Unpack gate panel crating very carefully. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 15: Installation

    Operator on pad, if necessary). 5. Secure Yoke with four (4) 1/2” dia. Anchor bolts (provided). If installing a Ground Yoke, allow a minimum space of two (2") inches between bottom of Gate and Yoke. 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 16 Installing Other Components Cable Wind Bracing Masted Wind Bracing 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 17 (Photo Beam) is shown in blue lowing: Fencing, installation of provided gate including beam path. Additionally, installation of an guard, or entrapment protection devices approved B2 contact sensor is shown in bright green. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 18: Dc & Ac Power Connecting, Operator Testing

    1. Connecting Batteries - Required A. Install two (2) 12 VDC Batteries (not provided) on the battery shelf. AutoGate recommends Group 24, 100 Amp hour deep cycle marine batteries for extended battery back up. At a minimum use seven (7) AH batteries for battery back up.
  • Page 19 SURGE UNIT MUST BE GROUNDED TO A TRUE EARTH GROUND. AC OUTLETS ARE HOT AT ALL TIMES. OUTLETS ARE FOR SERVICE USE ONLY. OPERATOR MUST BE GROUNDED TO TRUE EARTH GROUND LUG LOCATED ON FRAME 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 20 Control Box. The circuit board is factory set and should not be altered in any way or the Warranty may be voided. If an adjustment has to be made, consult your Control Board Instructions for details. If you need any further assistance, please contact your local AutoGate Dealer or call AutoGate at 1-800-944-4283. Timers and Mode Selections (S1) SEE DIAGRAM BELOW Full Speed Run Timer –...
  • Page 21 MARY MUST GO TO TERMINAL 4 OF SEC- ONDARY. TERMINAL 1 OF SECONDARY MUST GO TO TERMINAL 4 OF PRIMARY. SECONDARY - J3 TERMINAL 2 OF PRIMARY WILL GO TO TERMINAL 2 OF SECONDARY. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 22: Accessory Components

    Warning Signs, Reflective Tape, Warning injury or death. Speed limits should also be posted. Contact Lights AutoGate for specific Warning Signs, Reflective Tape, and Warning Lights that can be affixed to the Drop Arm. 1.800.944.4283 AutoGate Technical Support...
  • Page 23 3. The N.O. & Common signal wires to open the gate need to be attached to the Circuit Board #’s 1, 2, or 3 (Open) & 9, 10, 11, or 12 (Common). (Refer to Manufacturer’s Instructions.) 4. We recommend using a ground rod to minimize lightning damage. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 24: Troubleshooting & Checking Control Board

    4. If D14 (AC) & D5 (BRAKE) are on, then gate has repeatedly sensed obstructions. Clear obstruction, turn off AC and DC power. Now turn AC and DC power back on and test system. 5. If steps above do not restore operation contact AutoGate Tech Support at 1.800.944.4283. 1.800.944.4283...
  • Page 25 6. Secure the belt tension lever in the locked position to re-apply tension to the belts. NOTE: It only takes 16 - 30 lb. of force to open gate. If more is required, contact your dealer or AutoGate. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 26: Electrical Quick Check Guide

    Replace any blown fuse with same Sizing and Rating. If fuses are 3 Amp on front of good—Check for good batteries and A/C from building circuit breaker. Battery Tray If any fuse blows instantly at power on—Bad Circuit Board F3 Fuse on Control Board REPLACE 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 27 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 28: Maintenance

    Every 6 months Every month Check and verify proper operation of all secondary entrapment devices. Check and verify proper operation of all primary reversing feature. Every month Check gate balance Four months after install, they annually 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 29 Step 9) Replace chain tension bolt. NOTE: Grease fitting after any spring change. Refer to balancing instructions at must point up! Tighten bottom nut. NOTE: Chain MUST www.AutoGate.com or the instructions on Page 30. remain level and not twisted once tightened. 1.800.944.4283 AutoGate Technical Support JULY 2016...

  • Page 30: Quick Reference Guide

    Touch-Up Paint For scratches and following minor repairs use Rustoleum® Painters Touch 2x Ultra Cover to match the AutoGate Standard Colors. All colors Gloss Black, Dark Gray, Kona Brown, Hunter Green, & White. Balancing a Gate Recommended four (4) months after installation, then annually. It is recommended to check the balance of the Operator.

  • Page 31: Drawings

    1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 32 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 33 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 34 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 35 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 36 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 37 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 38 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 39 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 40 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 41 1.800.944.4283 AutoGate Technical Support JULY 2016...
  • Page 42 1.800.944.4283 AutoGate Technical Support JULY 2016...
