Page 9: Introduction
The DVS-7200’s image quality, superb keying, timeline control, and overall versatility pinpoints a broad range of applications, including studio production, post, and remote broadcast requirements. But above all, the DVS-7200 delivers its full range of features in a streamlined two M/E format — with all the input flexibility, customization capability, integrated performance, and ease of use that you’ve come to expect from Sony digital switchers.
Page 10 • Appendix B — Related Resources This appendix lists additional written and visual reference material available for further reading and research on the DVS-7200. • Appendix C — Sales and Service This appendix provides basic information about Sony sales, service, emergency response, and software support.
Page 11: Features And Benefits
DVS-7200 Feature Overview BKGD PRIOR This chapter outlines the DVS-7200’s features, and includes discussions of the functionality and benefits of the switcher’s basic and “power” tools. Concise explanations relating to the importance of each feature are provided. The following sections are included: •...
Page 12: Making Complex Tasks Simple
And whether the switcher is large-scale, mid-range, or compact in size, one important factor is constant across the product line — Sony switchers have the power to make complex tasks simple. That benchmark principle holds true with the new DVS-7200. Here are just a few examples: •...
Page 13: Basic Tools
Input Flexibility The DVS-7200 can be equipped with 12, 24, or 36 primary inputs and up to four component analog chroma key inputs. For flexibility, all SDI inputs can be switched (from the panel) between component digital (4:2:2) and composite digital (4fsc) operations.
Page 14: V-Proc
Effect Keyers and DSK In the DVS-7200, two powerful effect keyers are standard (per M/E), and up to two optional DSKs (Down Stream Keyer) can also be added. A variety of creative key “types” can be selected, as follows: •...
Page 15: Key Edge Adjustment
— without getting lost in menus. Key Edge Adjustment One aspect of the DVS-7200’s high quality key processing is the ability to fine tune and optimize the key signal — independent of the “fill.” Through the use of over- sampling, the key signal’s width can be modified in sub-pixel units.
Page 16: Superior Editor Interface
In the time it used to take to manually re-patch a switcher’s input configuration, on the DVS-7200 you can recall a snapshot that re-maps crosspoints, sets up the M/Es and initiates a transition — all with one button — making complex tasks simple.
Page 17: Switchable System Standard
The DVS-7200 offers superb features, and a little peace-of-mind, too. Power Tools This section outlines the features that operators value the most on the DVS-7200. Power tools not only simplify the daily job, but they add to that all-important category of creativity — the area in which a switcher’s artistic and aesthetic capabilities are greater than the sum of its parts.
Page 18: Integrated Dme Control
DME control panel. The DVS-7200 reverses this trend with the addition of two optional switcher panels: the BKDS-7030 Key Frame Control Panel and the BKDS-7031 DME Control Panel.
Page 19: Dual Matte Generators With Color Mix Capability
To this creative end, the DVS-7200 has provision for up to eight internal dual color matte generators — for Key-1 edge and Key-2 edge (for each M/E plus DSK), in addition to Wipe border and Color background (for each M/E).
Page 20: Auxiliary Buses
In fact, every signal that enters the switcher or is internally generated — can be placed on an Aux bus. The DVS-7200’s Aux bus feature is simple and logical. You can sometimes predict the signals you’ll need before an edit session or production, but once you’re in the midst of it, there’s a confidence in knowing that everything is accessible via the...
Page 21: Bus Link Mode
This action also delays the actual video switch by a certain number of fields — allowing the background and foreground to switch in sync. In operation, the GPI Link can be advanced or delayed from the initial “press” of the switcher crosspoint. Features and Benefits • • 13 DVS-7200 • Product Guide...
Page 22 SONY 14 • • Features and Benefits DVS-7200 • Product Guide...
Page 23: Configuration Guide
DVS-7200 Configuration To assist with configuration planning, this chapter describes the DVS-7200’s system components. In addition, a convenient quotation request form is included to assist with pre-sales planning and to simplify the DVS-7200 ordering process. The following sections are included: •...
Page 24: Basics
36 available inputs may be configured as composite analog. Refer to the “Input Configuration” section below for details. In the “Installation Guide” chapter, refer to the “DVS-7200 Chassis” section for a chassis diagram and list of chassis specifications.
Page 25: Input Configuration
SONY Input Configuration This section describes the input boards that can be added to a DVS-7200 system. • Three slots are provided for primary input boards (select any combination of the BKDS-7102 and BKDS 7110 boards). Up to three boards can be installed, for a maximum of 36 inputs.
Page 26: Output Configuration
SONY Output Configuration This section describes the output boards that can be added to a DVS-7200. The switcher has a total of 19 outputs (comprised of individual outputs and “groups”) that can be configured individually: • One Program group (four individual outputs, configured as one) •...
Page 27: Control Panel Options
SONY Control Panel Options This section describes the control panel options that can be added to a DVS-7200. In the “System Interconnection Charts” section, refer to the “DVS-7200 Control Panel Connections Chart” for an illustration of DVS-7200 control panel connections.
Page 28: Operation Software And Manual (Dme-7000)
RS-422 interconnect cables have a maximum length of 100 meters. BZS-7360 Remote Key Control Software The BZS-7360 Remote Key Control Software is required for operating the BKDS- 7060 Remote Key Control Panel. 20 • • Configuration Guide DVS-7200 • Product Guide...
Page 29: Remote Panel Interface
The BKDS-8062 Auxiliary Control panel installs with the BKDS-8060 Remote Panel Interface unit. Up to 14 combined BKDS-8062 plus BKDS-8060 units can be connected to the DVS-7200 chassis for remote control of Aux buses 1 through 14. The DVS-7200 supports five different configurations of crosspoint assignments for the BKDS-7015 control panel and BKDS-8062 —...
Page 30: M/E Auxiliary Control Panel
SONY BKDS-2010 M/E Auxiliary Control Panel The BKDS-2010 M/E Auxiliary Control Panel effectively turns the DVS-7200 into two one-M/E switchers. The Auxiliary Control Panel (same as the DVS-2000C’s Control Panel) connects to the processor chassis using an RS-422 interconnect. Note that RS-422 interconnect cables are not provided. In the “Options and Upgrades”...
Page 31: Options And Upgrades
Frame Memory Adaptor Board The BKDS-7445 Frame Memory Adaptor Board works in conjunction with the BKDS-2041 Basic Frame Memory Board to provide two frames of storage. The adaptor board permits the BKDS-2041 to be installed in the DVS-7200 chassis. BKDS-2070 Enhanced Wipe Option The BKDS-2070 Enhanced Wipe Option provides additional wipe patterns such as the Matrix, Heart, Star, and Diamond Dust wipes.
Page 32: Key Border Option
Control Port Expansion Board The BKDS-7001 Control Port Expansion Board (with mounting hardware and interconnect cables) adds an additional four RS-422 control ports to the DVS-7200 system. The board is required if you wish to control two or more channels of DME effects from the switcher panel, and is also required for the Peripheral II interface.
Page 33: Tally Interface Unit
Up to 4 relay states may be set for each tally function. The BKDS-7700 also provides an “S-Bus” interface to the Sony DVS “B” series routing switchers. In this configuration, the “B” series is accessed directly from the DVS-7200’s display for changing primary switcher crosspoints.
Page 34: System Cables, Rs-422
BKDS-8061, and BKDS-8062. BKD-RS15A Rack Mount Kit — Switcher RMM-18DV The BKD-RS15A or RMM-18DV Rack Mount Kits allows the DVS-7200 to be rack-mounted in a standard 19" rack. Either kit can be used. RMM-30 Rack Mount Kit — Tally The RMM-30 Rack Mount Kit allows the BKDS-7700 Tally Interface Unit to be rack-mounted in a standard 19"...
Page 35: Training
SONY Training This section describes training courses that are available for the DVS-7200 system. NN-TRNG/GEN1C Training — General Product This class provides one day (8 hours) of general BVE, DVS, or DME training at the customers location. The class is limited to 3 students, and is a pre-requisite for any additional DVS-7200 training.
Page 36: Order Guide - Dvs-7200
Fax: Contact: Title: Instructions The Request Form on the following page includes a table of all DVS-7200 system components. Use the table to configure the customer’s optimum DVS-7200 switcher system. Please perform the following steps: • As a prerequisite, review the information in the “Installation Guide” chapter: •...
Page 37: Request Forms
SONY Request Forms This section includes the DVS-7200 Input Configuration chart, the DVS-7200 Output Configuration chart, and the DVS-7200 System Components chart. DVS-7200 Input Configuration Chart Check off the one input configuration required, note the quantity and format of input boards that support the desired configuration, then transfer the information (and quantities) to the “DVS-7200 System Components”...
Page 38: Dvs-7200 Output Configuration Chart
SONY DVS-7200 Output Configuration Chart For each of the 19 configurable DVS-7200 outputs (comprised of individual outputs and “groups”), select the desired output format, either composite analog (BKDS-7161) or SDI (BKDS-7162). Then transfer the information (and quantities) to the “DVS-7200 System Components” chart. Output modules are installed on the OUT-9 Mother Board.
Page 39: Dvs-7200 System Components Chart
SONY DVS-7200 System Components Chart Check off the basic and optional items required. Recommended items for a basic DVS-7200 system are marked with an X in the “Rec” column. Mark quantities (where appropriate), exceptions, and comments in the “Notes” column.
Page 40 1 day general BVE, DVS, or DME training at the customers Includes instructor travel and location. Class limited to 3 students. accommodations. Note: Refer to “Appendix B, Related Resources” for details on ordering additional DVS-7200 operations and maintenance manuals. 32 • • Configuration Guide DVS-7200 • Product Guide...
Page 41: Installation Guide
This chapter provides information and diagrams to assist with facility engineering and equipment integration requirements. The following sections are included: • The “DVS-7200 Control Panel” section provides detailed control panel diagrams, external dimensions, specifications, and detailed tables of connector pinouts.
Page 42: Dvs-7200 Control Panel
Control Panel Specifications • Control Panel Rear View • Control Panel Connectors Control Panel Top View The figure below illustrates a top view of the DVS-7200 Control Panel. DVS-7200 Control Panel Top View 34 • • Installation Guide DVS-7200 • Product Guide...
Page 43 Next Transition BKGD PRIOR Selection Buttons NEXT TRANSITION SUPER Transition Type WIPE Selection Buttons TRANSITION TYPE Auto Transition FRAMES Control Section AUTO TRANS Transition Indicator 4. Shot Box Section (BKDS-7033) SHOT BOX Installation Guide • • 35 DVS-7200 • Product Guide...
Page 44: Floppy Disk Drive
9. Utility Section UTILITY EDIT EDIT PANEL ENBL ENBL ENBL ENBL ENBL ENBL ENBL ENBL SAFE SAFE FREZE FREZE TITLE TITLE BKGD FREZE VIDEO EDGE RECUR NON- LIGHT GRAPH STAT SETUP 36 • • Installation Guide DVS-7200 • Product Guide...
Page 45 TRANSITION TYPE DSK1 FRAMES FRAMES FADE AUTO TRANS BLACK DSK2 13. Master E-File Section with Numeric Keypad SNAP SHOT TRANS RATE LASTX AUTO TRANS TRIM STORE LEARN DSBL ENTER RCALL USER GLBL Installation Guide • • 37 DVS-7200 • Product Guide...
Page 46: Control Panel External Dimensions
(in millimeters). Note that the illustrations shows all control panel options installed. View 1030 Side View Rear View 1034 1004 Control Console Cutout Top View Side View DVS-7200 External Control Panel Dimensions 38 • • Installation Guide DVS-7200 • Product Guide...
Page 47: Control Panel Specifications
SONY Control Panel Specifications The following table lists Control Panel specifications: DVS-7200 Control Panel Specifications Parameter Specification Dimensions 1030 (w) x 110 (h) x 496 (d) inches: 40.55 (w) x 4.33 (h) x 19.53 (d) Cutout Dimensions (Outer) 1034 (w) x 500 (d) inches: 40.71 (w) x 19.69 (d)
Page 48: Control Panel Rear View
SONY Control Panel Rear View The figure below illustrates a rear view of the DVS-7200 Control Panel. SWITCHER TERMINAL 1 TERMINAL 2 AC IN AC IN OPTION PANEL REMOTE 1 REMOTE 2 REMOTE 3 REMOTE 4 DVS-7200 Control Panel Rear View Rear Control Panel components are listed below: 1.
Page 49: Control Panel Connectors
Note that RS-422 interconnect cables are not provided. In the “Options and Upgrades” section, see the “System Cables, RS-422” heading for part numbers and information. RS-422 interconnect cables have a maximum length of 100 meters. Installation Guide • • 41 DVS-7200 • Product Guide...
Page 50: Rs-422A Dme Connector Specifications
Clear to send signal ** — — Pins 1, 4, and 6 are shorted together on the CN-1143 board. Note: ** Pins 7 and 8 are shorted together on the CN-1143 board. 42 • • Installation Guide DVS-7200 • Product Guide...
Page 51: Rs-422A Remote 1-4 Connector Specifications
— — Common ground RX-B Received data (+) TX-A Transmitted data (–) — — Note: * Remote connectors 2, 3, and 4 are active only if the BKDS-7001 board is installed. Installation Guide • • 43 DVS-7200 • Product Guide...
Page 52: Option Panel Connector Specifications
Control signal for switch read and LED light Switch read data Ground TSEQ Control signal for character display TQC:L Control signal for character display +12 V Power supply +12 V +12 V Power supply +12 V Ground 44 • • Installation Guide DVS-7200 • Product Guide...
Page 53: Additional Control Panels
BKDS-2010 — M/E Auxiliary Control Panel • BKDS-7060 — Remote Key Control Panel • BKDS-8060 — Remote Panel Interface • BKDS-8061 — Shot Box Control Unit • BKDS-8062 — Auxiliary Control Panel Installation Guide • • 45 DVS-7200 • Product Guide...
Page 54: Bkds-2010 - M/E Auxiliary Control Panel
AUX BUSES PRIOR BLACK COLOR BLACK BKGD BKGD KEY BUSES NEXT TRANSITION COLOR BLACK WIPE BKGD TRANSITION TYPE PGM BUS AUTO COLOR BLACK TRANS BKGD PST BUS BKDS-2010 Control Panel Top View 46 • • Installation Guide DVS-7200 • Product Guide...
Page 55: Bkds-2010 Control Panel Rear View
BKDS-2010 Control Panel External Dimensions The figure below illustrates external BKDS-2010 dimensions (in millimeters): more than 100 Control Console Cutout Top View Top View Side View 61.7 Rear View BKDS-2010 External Control Panel Dimensions Installation Guide • • 47 DVS-7200 • Product Guide...
Page 56: Bkds-2010 Control Panel Specifications
VD (+) VD signal input (+) from Processor RX-COM Signal Ground RX-B Received data (+) from Processor TX-A Transmitted data (–) to Processor VD (–) VD signal input (–) from Processor 48 • • Installation Guide DVS-7200 • Product Guide...
Page 57 Signal Function Received line signal detector signal Received data Transmitted data Data terminal ready signal Signal ground Data set ready signal Request to send signal Clear to send signal — — Installation Guide • • 49 DVS-7200 • Product Guide...
Page 58: Bkds-7060 - Remote Key Control Panel
HOME MENU BKDS-7060 Control Panel Top View BKDS-7060 Control Panel External Dimensions The figure below illustrates external BKDS-7060 dimensions (in millimeters): View Side View Rear View BKDS-7060 External Control Panel Dimensions 50 • • Installation Guide DVS-7200 • Product Guide...
Page 59: Bkds-7060 Control Panel Specifications
The figure below illustrates a rear view of the BKDS-7060 Keyer Control Panel. CONTROL PANEL BKDS-7060 Control Panel Rear View Rear Control Panel components are listed below: 1. Control Panel Connector (D-sub 15-pin male) RS-232C Installation Guide • • 51 DVS-7200 • Product Guide...
Page 60: Bkds-7060 Control Panel Connectors
POWER SUPPLY UNIT TERMINAL BKDS-7060 Power Supply Front View Front Power Supply components are listed below: 1. Power Indicator 2. Terminal Connector (D-sub 9-pin female) RS-232C 3. Blank Panel for rack mounting 52 • • Installation Guide DVS-7200 • Product Guide...
Page 61: Bkds-7060 Power Supply External Dimensions
Control Out 2 Connector (rear panel) 9-pin D-sub connector (RS-422A) Female Operating environment +5°C to +40°C Power requirements 100 to 240 V AC ± 10%, 50/60 Hz Current consumption 0.4 A (max.) Installation Guide • • 53 DVS-7200 • Product Guide...
Page 62: Bkds-7060 Power Supply Rear View
BKDS-7060 Power Supply RS-232C Terminal Connector Specifications (Female) Pin # Signal Function Data carrier detect Received data Transmitted data Data terminal ready Signal ground Data set ready data Request to send data Clear to send data — — 54 • • Installation Guide DVS-7200 • Product Guide...
Page 63 Frame Ground RX-A Received data (–) TX-B Transmitted data (+) Common ground VD-B Received VD signal (+) Common ground RX-B Received data (+) TX-A Transmitted data (–) VD-A Received VD signal (–) Installation Guide • • 55 DVS-7200 • Product Guide...
Page 64: Bkds-8060 - Remote Panel Interface
BKDS-8060 Remote Panel Interface Rear View Rear BKDS-8060 components are listed below: 1. AC Input 2. Panel Connector (D-sub 15-pin female) 3. Control Out Connector (D-sub 9-pin female) 4. Control In Connector (D-sub 9-pin female) 56 • • Installation Guide DVS-7200 • Product Guide...
Page 65: Bkds-8060 External Dimensions
9-pin D-sub connector (RS-422A) Female Operating temperature +5°C to +40°C Storage temperature -20°C to +70°C Humidity 10% to 90% Power requirements 100 to 240 V AC ± 10%, 50/60 Hz Current consumption 5 W (max.) Installation Guide • • 57 DVS-7200 • Product Guide...
Page 66: Bkds-8060 Connectors
Signal ground L; SW SW data (negative logic) Signal ground Signal ground +5 V (LED) +5 V Power supply (for LED lighting) +5 V (LED) +5 V Power supply (for LED lighting) 58 • • Installation Guide DVS-7200 • Product Guide...
Page 67 Transmit data (+) to cascade connecting unit Signal ground No connection Signal ground RX1 (+) Receive data (+) from cascade connecting unit TX1 (–) Transmit data (–) to cascade connecting unit Signal ground Installation Guide • • 59 DVS-7200 • Product Guide...
Page 68: Bkds-8061 - Shot Box Control Unit
The figure below illustrates a rear view of the BKDS-8061 Shot Box Control Unit. CASCADE CASCADE BKDS-8061 Shot Box Control Unit Rear View Rear BKDS-8061 components are listed below: 1. Cascade In Connector (D-sub 15-pin male) 2. Cascade Out Connector (D-sub 15-pin female) 60 • • Installation Guide DVS-7200 • Product Guide...
Page 69: Bkds-8061 External Dimensions
15-pin D-sub connector (Control) Male Cascade Out Connector 15-pin D-sub connector (Control) Female Operating temperature +5°C to +40°C Storage temperature -20°C to +70°C Humidity 10% to 90% Power requirements Supplied by BKDS-8060 Installation Guide • • 61 DVS-7200 • Product Guide...
Page 70: Bkds-8061 Connectors
Signal ground L; SW SW data (negative logic) Signal ground Signal ground +5 V (LED) +5 V Power supply (for LED lighting) +5 V (LED) +5 V Power supply (for LED lighting) 62 • • Installation Guide DVS-7200 • Product Guide...
Page 71: Bkds-8062 - Auxiliary Control Panel
The figure below illustrates a rear view of the BKDS-8062 Auxiliary Control Unit. CASCADE CASCADE BKDS-8062 Auxiliary Control Unit Rear View Rear BKDS-8062 components are listed below: 1. Cascade In Connector (D-sub 15-pin male) 2. Cascade Out Connector (D-sub 15-pin female) Installation Guide • • 63 DVS-7200 • Product Guide...
Page 72: Bkds-8062 External Dimensions
15-pin D-sub connector (Control) Male Cascade Out Connector 15-pin D-sub connector (Control) Female Operating temperature +5°C to +40°C Storage temperature -20°C to +70°C Humidity 10% to 90% Power requirements Supplied by BKDS-8060 64 • • Installation Guide DVS-7200 • Product Guide...
Page 73: Bkds-8062 Connectors
Signal ground L; SW SW data (negative logic) Signal ground Signal ground +5 V (LED) +5 V Power supply (for LED lighting) +5 V (LED) +5 V Power supply (for LED lighting) Installation Guide • • 65 DVS-7200 • Product Guide...
Page 74: Dvs-7200 Chassis
Chassis Specifications • System Timing Requirements • Chassis Connectors Chassis Front View The figure below illustrates a front view of the DVS-7200 chassis. SONY DIGITAL VIDEO SWITCHER DVS-7200 DVS-7200 Chassis — Front View Front chassis components are listed below: 1. Power Switch (Supply 1) 3.
Page 75: Chassis Rear View
SONY Chassis Rear View The figure below illustrates a rear view of the DVS-7200 chassis. AC IN AC IN AUX BUS M/E 1 CRK INPUT/ SERIAL TERMINAL PANEL 1 INPUTS INPUTS TALLY OUTPUTS OUTPUTS D1 PRIMARY M/E 2 OUTPUTS B-Y/B...
Page 76 30. DME 4 (9-pin D-sub, female) RS-422A 31. Editor B / Remote 2 (9-pin D-sub, female) RS-422A 32. DME 3 (9-pin D-sub, female) RS-422A 33. Editor A / Remote 1 (9-pin D-sub, female) RS-422A 68 • • Installation Guide DVS-7200 • Product Guide...
Page 77: Chassis External Dimensions
SONY Chassis External Dimensions The figure below illustrates external chassis dimensions (in millimeters): Top View Side View DVS-7200 External Chassis Dimensions Chassis Specifications The following table lists chassis specifications: DVS-7200 Chassis Specifications Parameter Specification Dimensions 424 (w) x 443 (h) x 450 (d) inches: 16.69 (w) x 17.44 (h) x 17.72 (d)
Page 78 SONY DVS-7200 Chassis Specifications (continued) Parameter Specification Connectors (continued) Direct Input Configurable, analog composite or digital With BKDS-7162 for EDIT PVW output Serial digital video signal output, BNC (x1), 75 ohms Signal level: 800 mV ±10% With BKDS-7161 for EDIT PVW output...
Page 79 SONY DVS-7200 Chassis Specifications (continued) Parameter Specification Connectors (continued) Matrix 9-pin D-sub, female, RS-422A Terminal 9-pin D-sub, female, RS-232C Serial Tally 9-pin D-sub, female, RS-422A DME 1 9-pin D-sub, female, RS-422A DME 2 9-pin D-sub, female, RS-422A DME 3 9-pin D-sub, female, RS-422A...
Page 80: System Timing Requirements
SONY System Timing Requirements The chart below shows input and output timing for the DVS-7200. -0.5H +0.5H +1.0H +1.5H +2.0H INPUT -0.4H +0.4H Window -127CK +128CK Input Phase Reference Video Output -30µ Sec +90µ Sec OUTPUT DVS-7200 System Phase Timing Chart Please note the following important points: •...
Page 81: Chassis Connectors
Function Frame Ground DSK TX-A Transmitted data (–) DSK RX-B Received data (+) Common ground — — Common ground DSK TX-B Transmitted data (+) DSK RX-A Received data (–) Frame Ground Installation Guide • • 73 DVS-7200 • Product Guide...
Page 82: Rs-232C Terminal Connector Specifications
Serial Tally RX-A Received data (–) Serial Tally TX-B Transmitted data (+) Common ground — — Common ground Serial Tally RX-B Received data (+) Serial Tally TX-A Transmitted data (–) Frame ground 74 • • Installation Guide DVS-7200 • Product Guide...
Page 83: Rs-422A Matrix Connector Specifications
DME 1 - 4 RX-B Received data (+) Common ground — — Common ground DME 1 - 4 TX-B Transmitted data (+) DME 1 - 4 RX-A Received data (–) Frame Ground Installation Guide • • 75 DVS-7200 • Product Guide...
Page 84: Rs-422A Panel 1 Connector Specifications
Transmitted data (–) CON RX-B Received data (+) Common ground VD-B Transmitted VD signal (+) Common ground CON TX-B Transmitted data (+) CON RX-A Received data (–) VD-A Transmitted VD signal (–) 76 • • Installation Guide DVS-7200 • Product Guide...
Page 85: Rs-422A Editor A/Remote 1 Connector Specifications
Edit B TX-A Transmitted data (–) Edit B RX-B Received data (+) Common ground — — Common ground Edit B TX-B Transmitted data (+) Edit B RX-A Received data (–) Frame Ground Installation Guide • • 77 DVS-7200 • Product Guide...
Page 86: Gpi Connector Specifications
Note: A and B of the same number constitute a pair of relay contacts. (Relay) (Open collector GPI Out XB GPI Out 5-8 output) GPI Out XA GPI Out Com X; 1-4 78 • • Installation Guide DVS-7200 • Product Guide...
Page 87: Bkds-7700 Chassis
Front chassis components are listed below: 1. Power Switch (Supply 1) 2. Power Indicator (Supply 1) 3. Power Switch (Supply 2, Backup) 4. Power Indicator (Supply 2, Backup) 5. Operations Status and Program Selector Button Installation Guide • • 79 DVS-7200 • Product Guide...
Page 88: Bkds-7700 Chassis Rear View
8. Serial Tally 2 (9-pin D-sub, female) RS-422A 9. Switcher (9-pin D-sub, female) RS-422A 10. Through Out (9-pin D-sub, female) RS-422A 11. Terminal (9-pin D-sub, female) RS-232C 12. Remote (BNC) 13. Reference In, Loop (BNC) 80 • • Installation Guide DVS-7200 • Product Guide...
Page 89: Bkds-7700 Chassis External Dimensions
50-pin D-sub, female, RS-422A Terminal 9-pin D-sub, female, RS-232C Switcher 9-pin D-sub, female, RS-422A Through Out 9-pin D-sub, female, RS-422A Serial Tally 1 9-pin D-sub, female, RS-422A Serial Tally 2 9-pin D-sub, female, RS-422A Installation Guide • • 81 DVS-7200 • Product Guide...
Page 90: Bkds-7700 Chassis Connectors
RS-232C Terminal Connector Specifications (Female) Pin # Signal Function Data carrier detect Receive data Transmitted data Data terminal ready Ground Data set ready Request to send Clear to send — — 82 • • Installation Guide DVS-7200 • Product Guide...
Page 91: Bkds-7700 Switcher Connector Specifications
Frame Ground RX-A Received data (–) TX-B Transmitted data (+) Common ground VD-B Transmitting VD signal (+) Common ground RX-B Received data (+) TX-A Transmitted data (–) VD-A Transmitting VD signal (–) Installation Guide • • 83 DVS-7200 • Product Guide...
Page 92: Bkds-7700 Serial Tally 1, 2 Connector Specifications
RS-422A Serial Tally 1, 2 Connector Specifications (Female) Pin # Signal Function Frame Ground RX-A Received data (–) TX-B Transmitted data (+) Common ground — — Common ground RX-B Received data (+) TX-A Transmitted data (–) Frame Ground 84 • • Installation Guide DVS-7200 • Product Guide...
Page 93: Bkds-7700 Tally In/Gpi Connector Specifications
P-In 26 P-In 2 P-In 27 P-In 3 P-In 28 P-In 4 P-In 29 P-In 5 P-In 30 P-In 6 P-In 31 P-In 7 P-In 32 P-In 8 Ground P-In 9 Ground Installation Guide • • 85 DVS-7200 • Product Guide...
Page 94: Bkds-7700 Tally Enable Connector Specifications
Enable 42 Enable 18 Enable 43 Enable 19 Enable 44 Enable 20 Enable 45 Enable 21 Enable 46 Enable 22 Enable 47 Enable 23 Enable 48 Enable 24 Ground Enable 25 Ground 86 • • Installation Guide DVS-7200 • Product Guide...
Page 95: Bkds-7700 Tally Out 1-9 Connector Specifications
149B 173B 197B Tally Out: 104A 128A 152A 176A 200A Tally Out: 104B 128B 152B 176B 200B Tally Out: 107A 131A 155A 179A 203A Tally Out: 107B 131B 155B 179B 203B Installation Guide • • 87 DVS-7200 • Product Guide...
Page 96 192B 216B Ground • Notes: Relay contact 30V 0.1 A • A and B of the same number constitute a pair of relay contacts. (Relay) Tally Out xB Tally Out xA 88 • • Installation Guide DVS-7200 • Product Guide...
Page 97: System Interconnection Charts
SONY System Interconnection Charts This section includes a variety of detailed system interconnection charts, as follows: • DVS-7200 System Interconnection Chart — Video • DVS-7200 System Interconnection Chart — Control • DVS-7200 Control Panel Connections Chart • DVS-7200 Video Paths with Router Chart •...
Page 98: Dvs-7200 System Interconnection Chart - Video
SONY DVS-7200 System Interconnection Chart — Video The simplified diagram below illustrates a typical DVS-7200 system. Video connections only are shown. SDI Sources Reference Distribution Pulse/Test Generator Video Status Ref. Edit Preview Assign Preview SDI In Waveform SDI Out VTR:...
Page 99: Dvs-7200 System Interconnection Chart - Control
SONY DVS-7200 System Interconnection Chart — Control The simplified diagram below illustrates a typical DVS-7200 system. Control, GPI, and S-Bus connections are shown. RS-422 Serial Control DVR, DVW Series RS-422 BVE-9100 DVR, DVW Series RS-422 Monitor Display BKSR-3281 DVR, DVW Series...
Page 100: Dvs-7200 Control Panel Connections Chart
SONY DVS-7200 Control Panel Connections Chart The simplified diagram below illustrates a variety of DVS-7200 control panel connections, using RS-422 connectors on both the chassis and control panel. Note the use of loops to extend the system’s capabilities. RS-422 Remote 1-4...
Page 101: Dvs-7200 Video Paths With Router Chart
SONY DVS-7200 Video Paths with Router Chart The simplified diagram below shows the interconnection between a DVS-V6464B routing switcher and a variety of typical video sources, including the DVS-7200. DVS-7200 Processor Still Store Image Acquisition Routing Switcher Video Storage and Playback...
Page 102: Dvs-7200 Switcher - Router Interface Chart
SONY DVS-7200 Switcher - Router Interface Chart The simplified diagram below illustrates the S-Bus and RS-422 control interconnection between a DVS-V6464B routing switcher and the DVS-7200. Note: The DVS-7200 Control Panel can access DVS "B" series routers via the BKDS-7700 serial tally system.
Page 103: Dvs-7200 With Scitexdv (Abekas) Dveous A-5100
SONY DVS-7200 with ScitexDV (Abekas) Dveous A-5100 The simplified diagram below shows a typical interconnection between a DVS-7200 and a ScitexDV Dveous A-5100. Remote 1-4 Control Panel RS-422 BKDS-7015 Control Video/Key Key In Video In Aux 4 Out Aux 3 Out...
Page 104 SONY 96 • • Installation Guide DVS-7200 • Product Guide...
Page 105: Appendix A. Feature List
AUTO TRANS BLACK This Appendix provides a table of DVS-7200 features, along with brief descriptions of each. All features are cross-referenced in the index. Note that all features discussed in this section use Sony terminology. Appendix A. Feature List • • 97...
Page 106: Dvs-7200 Features
SONY DVS-7200 Features The following features are available with the DVS-7200 switcher. DVS-7200 Features Feature Description Compact Control Panel The DVS-7200’s compact and modular control panel offers streamlined operations, comfort, and flexibility in a two M/E configuration. Additional space savings can also be achieved through fully-integrated DME operation, eliminating the need for an additional control panel.
Page 107 Master E-File panel and the Shot Box option. Router Interface This option controls a Sony DVS-B Series routing switcher directly through the switcher’s EL display. You can control up to 128 sources, and store router information along with switcher setups and snapshots.
Page 108 Feature Description Preview Functions Rather than limit you to a single preview function, the DVS-7200 allows you to preview any key (over a constant background), the clean M/E or Program/Preset feed (without keys), the key matte signal, the process key, the key preview itself, and auto preview.
Page 109: Appendix B. Related Resources
Printed Media One set of Installation, Operation, and Maintenance (Part 1) Manuals are provided with each DVS-7200 system. If you wish to order additional manuals (or, if you wish to order manuals prior to the hardware shipment), the following list provides all required part numbers.
Page 110: Audio/Video Media
SONY • Refer to the DVS-7200 E1 Installation Guide for a discussion of all installation issues. P/N: 3-192-660-02 • Refer to the DVS-7200 E1 Part 1 Maintenance Guide for a discussion of maintenance issues. 3-192-659-01 P/N: • Refer to the DVS-7000/7200 Vol. 1 E1 Part 2 Maintenance Guide for a discussion of maintenance issues.
Page 111: Appendix C. Sales And Service
The following information is included in this Appendix: • Regional Sales Offices • Regional Service Centers • National Parts Centers • Emergency Response System • UPPORT • SOFTWARE PLUS Appendix C. Sales and Service • • 103 DVS-7200 • Product Guide...
Page 112: Regional Sales Offices
SONY Regional Sales Offices Sony Regional Sales Offices are located in the following areas: • Northeast Regional Sales Office 123 W. Tryon Ave. Teaneck, NJ 07666 Main Number: (201) 833-5300 Fax Number: (201) 833-5850 • Southeast Regional Sales Office 3175 A. Northwoods Parkway...
Page 113: Regional Service Centers
SONY Regional Service Centers Sony Regional Service Centers are located in the following areas: • Northeast Regional Service Center 123 W. Tryon Ave. Teaneck, NJ 07666 Main Number: (201) 833-5300 • Southeast Regional Service Center 3175 A. Northwoods Parkway Norcross, GA 30071 Main Number: (770) 263-8016 •...
Page 114: National Parts Centers
SONY National Parts Centers Sony National Parts Centers are located in the following cities: • San Jose, CA For Broadcast parts: (800) 538-7550 • Kansas City, MO For Professional Audio parts: (800) 331-6679, (800) 654-0962 (in MO) For Business/Industrial parts: (816) 891-7550, (816) 891-7435 (after-hours) 106 •...
Page 115: Emergency Response System
3. When prompted, leave your name, company, a telephone number where you can be reached, model number, and a brief description of the problem. A Sony product specialist will return your call within 60 minutes. Appendix C. Sales and Service • • 107...
Page 116: Supportnetsm
Discounts on selected new and optional software products. • Automatic enrollment in SOFTWARE service program. PLUS SOFTWARE PLUS Purchasers of Sony Production Systems products are automatically enrolled into the SOFTWARE program. This service includes the following: PLUS • Notification of software releases •...
Page 117: Glossary
Also called “Aux” buses, auxiliary buses are extra switching buses that allow video signals connected to the switcher to be routed to external equipment such as digital effects systems and VTRs. Some switchers such as the DVS-7200 have multiple Aux buses as an option.
Page 118 The video switch which selects the source required on a particular switcher bus. Depth Key A DVS-7200 option that permits keys in the third dimension, using the “Z” axis or depth axis in XYZ coordinate space. Depth information can be derived from a full- screen video source, a key source, the main mask, a subsidiary mask, or by using “Z-data”...
Page 119 M/Es will not affect the downstream key video. ™ E-File The Sony trademarked system for switcher effects memory. One E-File contains a “snapshot” of the switcher control panel, including all settings and crosspoint selections. Edit Data Page Also known as the Edit Screen, the BVE-9100’s main operating menu in which the...
Page 120 The lever on a switcher that manually controls the progress of an effect. The position of the level typically controls the amount of the A-Bus signal and the B- Bus signal that contributes to the mix, wipe, or key. On the DVS-7200, the Fader Arm also controls the DME timeline.
Page 121 Peripheral device Any device connected to the BVE-9100 via serial communications or GPI. Category includes VTRs, ATRs, Video Switchers, Audio Mixers, Color Correctors, DVEs, and DDRs. Glossary • • 113 DVS-7200 • Product Guide...
Page 122: Setup Menu
#1 is next used as a source in the second cut (producing master tape #2), the original source reel timecodes are one EDL generation back. If the process is repeated again, the original numbers get farther away, but they’re not lost. If you 114 • • Glossary DVS-7200 • Product Guide...
Page 123 SONY want to assemble the show using the original source reels, the trace program is used to “recover” the original source in and outpoints. Glossary • • 115 DVS-7200 • Product Guide...
Page 124 47 BKDS-7790 25 control panel rear view 47 BKDS-8060 21, 56 control panel specifications 48 connectors 58 control panel top view 46 external dimensions 57 BKDS-2031 10, 23 front view 56 Index • • 117 DVS-7200 • Product Guide...
Page 125 BKDS-7700 81 DVS-7000 102 rear components 67 Digital output module 18 rear components, BKDS-7700 80 Dimensions rear view 67 chassis 69 rear view, BKDS-7700 80 chassis, BKDS-7700 81 weight 69 chassis, external 69 118 • • Index DVS-7200 • Product Guide...
Page 126 Editor Interface 8, 98 DME control 10, 98 EDL 8 system 4 Effect Interconnection chart keyers 6, 98 control 91 loop 12, 99 control panel connections 92 memories 99 router interface 94 memory 7 Index • • 119 DVS-7200 • Product Guide...
Page 127 Making Complex Tasks Simple 4 BKDS-7700 Tally In/GPI Connector 85 Masks 11 BKDS-7700 Tally Out 1-9 Connector 87 Master E-File BKDS-7700 Terminal Connector 82 panel 7, 98 BKDS-7700 Through Out Connector 83 120 • • Index DVS-7200 • Product Guide...
Page 128 20 Source Name Display 24, 99 panel interface 21, 56 Spare Parts Kit 25 Request Forms 29 Specifications Response System 107 BKDS-2010 control panel 48 RGB 17 BKDS-7700 chassis 81 Index • • 121 DVS-7200 • Product Guide...
Page 129 72 Tally interface unit 25 Technical education 108 publications 108 Time and Materials 108 Timeline 4 DME 12 effects 9 learn 8 Timing adjustable 6 requirements 72 Tools basic 5 power 9 122 • • Index DVS-7200 • Product Guide...
Page 130 SONy DVS-7200 • Product Guide Part Number BC-00603 Revision B...

Sony DVS-7200 Product Manual

Introduction

Features and Benefits

Configuration Guide

Installation Guide

Appendix A. Feature List

Appendix B. Related Resources

Appendix C. Sales and Service

Glossary

Quick Links

Need help?

Questions and answers

Related Manuals for Sony DVS-7200

Summary of Contents for Sony DVS-7200

Table of Contents
