Paradigm Soundtrack 2 Setup Manual page 2

WARNING! THE SET-UP AND SYNCING STEPS MUST BE DONE IN THE FOLLOWING ORDER. DO NOT PLUG IN SUBWOOFER UNTIL STEP 7.
Choose subwoofer orientation
Horizontal
When subwoofer is in horizontal
position feet must be attached
1
for heat dissipation.
#2 Phillips (not supplied)
Vertical
2
4
Power on, then initiate audio
Using the Remote or Top Panel Controls, turn Power
ON. Then repeatedly press the Source button until
you hear audio from your device (TV, iPhone, etc).
Top Panel Controls
Power Source Wireless Volume Volume
Sync Down Up
OR
Setting up the soundbar
1
Attaching soundbar feet
Lay your soundbar face down on a soft
surface. Insert feet as shown, press firmly
until you hear a 'click'.
Wireless subwoofer pairing
5 6
Wireless setting
DO NOT connect subwoofer ATTENTION: From the moment you
to wall outlet until step 7. press the soundbar's 'Sync' button
you have 30 seconds to connect the
subwoofer to the wall outlet.
Move switch to 'wireless' setting
on subwoofer.
Press the Sync button to initiate pairing with
subwoofer. The LED on the soundbar should
flash blue (
is established the LED switches to solid blue ( ).
Wireless Range
50'
or 15 Meters
OPTIONAL: For wall mounting instructions, refer to Owners Manual.
2
Power connection
Connect soundbar to wall outlet.
A
7
Syncing
Connect subwoofer to wall outlet.
) for 30 seconds. Once a connection
ATTENTION: If the soundbar's
LED flashes red and blue,
pairing has failed. Repeat
the Subwoofer Pairing process.
3
Connecting to source
NOTE: Choose analog
3.5-mm to mobile
OR digital connections audio device
(not included)
TV
B C
If desired, establish Bluetooth connection at this point (see rear for details)
8
Power connection Adjust subwoofer loudness
Your subwoofer's LEVEL knob is set to 12 o'clock to
suit average preferences. If desired, adjust up or
down to match sound level of your speakers.
–
BASS
D
Analog connection to
TV (use for good audio)
B
C
Digital connection to TV
(use for best audio)
+
BASS
