Vents th-Tune (A17) User Manual

Automatic control system for air handling units
Hide thumbs Also See for th-Tune (A17):

Advertisement

Quick Links

Download this manual
USER'S MANUAL
pGD1(A17)
th-Tune (A18)
Automatic control system for air handling units

Advertisement

loading
Need help?

Need help?

Do you have a question about the th-Tune (A17) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vents th-Tune (A17)

Summary of Contents for Vents th-Tune (A17)

  • Page 1 USER’S MANUAL pGD1(A17) th-Tune (A18) Automatic control system for air handling units...

  • Page 2: Table Of Contents

    th-Tune (A17)/pGD1 (A18) CONTENTS Safety requirements ..................................3 Purpose ........................................ 4 Technical data ....................................4 Installation and set-up................................5 Control ......................................... 7 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the th-Tune (A17)/pGD1 (A18) unit and all its modifications.

  • Page 3: Safety Requirements

    SAFETY REQUIREMENTS • Please read the user’s manual carefully prior to installing and operating the unit. • All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit. •...

  • Page 4: Purpose

    th-Tune (A17)/pGD1 (A18) PURPOSE The control panel is designed for controlling industrial and domestic supply and exhaust ventilation units as well as other air handling units. It is rated for continuous operation. THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE TRAINING.

  • Page 5: Installation And Set-Up

    INSTALLATION AND SET-UP TH-TUNE (A17) CONTROL PANEL INSTALLATION To install the rear part of the control panel, use a suitable mounting box (minimum diameter 65 mm and minimum depth 31 mm). 1. Use a screwdriver to pull the front and the rear sides of the control 2.
  • Page 6 th-Tune (A17)/pGD1 (A18) PGD1 (A18) CONTROL PANEL INSTALLATION Connect the pGD1 control panel to the controller connector using the 6P6C (PLUG-6P6C-P-C2) phone plug. The maximum length of the phone cable is 50 m. To mount the control panel on a wall, route the phone cable to the selected location. 1.

  • Page 7: Control

    CONTROL UNIT CONTROL PANELS The unit is controlled via the th-Tune or pGD1 control panels. BUTTON FUNCTION Auto or manual speed control selection. Fan speed selection: setting required speed stage (off, low, medium, high). Scheduled operation on/off: short pressing. Activation is confirmed by a pictogram Access to the time/time range setting menu: press and hold for 3 seconds.
  • Page 8 th-Tune (A17)/pGD1 (A18) Connect the pGD1 control panel to the controller connector using the 6P6C (PLUG-6P6C-P-C2) phone plug. The maximum length of the phone cable is 50 m. Operation with the pGD1 control panel is identical with operation from the controller. CONTROLLER FUNCTIONS AND MENU The controller has the following control elements and indicators: Backlit LCD display:...
  • Page 9 UNIT START When the unit is connected to power mains the controller loads and goes to the main page. If no action is taken in any menu within 5 minutes, the system will reload to the main page. MAIN PAGE The main page opens after confirmation of the unit switching on.
  • Page 10 th-Tune (A17)/pGD1 (A18) SCHEDULER Schedule Select in the setup menu and press Schedule menu displays all the settings for the set day of the week. Mode: scheduled operation mode status. Off: scheduled operation is off. scheduled operation is on. If the scheduled operation mode is activated, the setpoint editing on the main page is disabled! Press to change the status of the scheduled operation mode.
  • Page 11 TIMER Timer Select in the setup menu and press Edit the parameter using the buttons . Then press to confirm and proceed to the next parameter. Press to return to the setup menu. Timer settings: Period: time range for operation of the unit with set parameters. Speed: fan speed when the timer is activated.
  • Page 12 th-Tune (A17)/pGD1 (A18) FILTER Filter Select in the setup menu and press . The parameters of this entry are not editable and are for reading only. Press to return to the setup menu. Filter parameters: Current time: current filter operating time. Set time: set filter replacement periodicity.
  • Page 13 ENGINEERING MENU THE SERVICE SETTINGS ARE PROGRAMMED AT THE FACTORY. THESE SETTINGS MAY BE CHANGED ONLY BY QUALIFIED SPECIALISTS UPON ENTERING THE SERVICE PASSWORD. CHANGING OTHER PARAMETERS DOES NOT REQUIRE A SERVICE PASSWORD. Engineering menu Select in the setup menu, press and enter the password to engineering menu.
  • Page 14 th-Tune (A17)/pGD1 (A18) For the units with integrated VOC sensor Threshold Edit the parameter using the buttons . Then press to confirm. Press to return to the setup menu. The display shows current sensor readings and the maximum set point. If the current sensor readings exceed the maximum set point, the unit will maintain the set air quality by means of controlling the fan speed.
  • Page 15 Auto Lock Security Auto Lock Security In the menu select the item and press for setting the display locking or to return to the menu. Edit the parameters using the buttons . Then press to confirm and proceed to the next parameter. Auto lock: activation/deactivation of the display locking.
  • Page 16 V159EN-01(Carel)
