We hope you enjoy your Wireless Weather
Station from RadioShack. This weather
station features a clock with alarm function,
and minimum and maximum indoor/outdoor
6301469
TM
temperature display. It works with up to three
sensors (additional sensors not included). Please
Wireless Weather Station
read this user's guide before using your new
weather station.
Package Contents
User's Guide
• Weather Station
• Thermo Sensor
• User's Guide
Specifications
Indoor Temperature Range ... 32–122°F (0–50°C)
Outdoor Temperature Range ....................................
.................................................. -4 – 140°F (-20–60°C)
Sensor RF Frequency ..................................433 MHz
RF Operation Range ...............................98 ft (30 m)
Channel Number .........................................................3
Specifications are subject to change and improvement
without notice. Actual product may vary from the
images found in this document.
6301469_PM_EN_081115.indd 1-7
Important Installation and
Location Notes
• During initial installation, the sensor may
take up to an hour or more to acclimate to
current conditions.
• Place the weather station indoors away from
vents, heating or cooling elements, and
direct sunlight.
• Stand the sensor on
a flat surface indoors
or outdoors away
from direct sunlight
and moisture. Or use
a screw (not included)
to mount it on a wall.
Make sure the sensor is within 98 feet (30m)
of the weather station, without obstructions
between them. To avoid interference, place
the weather station and sensor away from
other electronic devices.
• If the sensor is placed outdoors, mount it
high enough off the ground where water,
snow, and rain cannot accumulate and also
2 3
Weather Station
high enough where it is out of reach for
children. The sensor should be mounted
onto a vertical flat surface. Avoid location
where rain and water falls directly onto the
sensor.
Install Batteries
1. Insert two AA batteries (not included) into
the weather station and thermo sensor
respectively, matching the polarity symbols
(+ and –) marked inside each battery
Thermo Sensor
compartment.
2. Press RESET on both units.
Battery Note:
• Dispose of old batteries promptly and
properly. Do not burn or bury them.
• Use only a fresh battery of the required size
and type.
• Use alkaline batteries for longer usage, or
use lithium batteries in temperatures below
-4°F (-20°C).
• If you do not plan to use your weather
station for more than a month, remove the
• Do not mix old and new batteries, or
batteries. Batteries can leak chemicals that
batteries of different types, capacities, or
can damage electronic parts.
chemistries.
4
Set Weather Station and Sensor
1. Place the weather station and sensor close
together indoors to communicate.
2. Slide the sensor's CH 1 2 3
switch to select a channel,
and press the weather
station's CH + button to
select the same channel. If
you are using more than one
sensor (up to three), select
a different channel for each
sensor.
3. Press the weather °C/°F
RESET
station's SENSOR Change between
CH 1 2 3 Celsius and Fahrenheit.
button to scan sensor
signal. Scanning may SENSOR
Scan sensor signal.
take some time.
Note: If the weather RESET
station does not connect Clear all indoor/outdoor
temperature data,
to the sensor, relocate
and clock and alarm
the sensor and/or the
settings.
weather station until
connection is established.
5 6
ALARM SET
SNOOZE / LIGHT
• Enter and
• Silence the alarm for
confirm alarm
5 minutes when the
settings.
alarm sounds.
• View the set
• Turn the backlight on.
alarm time.
• Activate the
alarm.
CH +
• Set the hour
and minute.
• Select a sensor.
MEM –
• Set the hour
and minute.
• View maximum
(MAX), minimum
(MIN) or current
indoor/outdoor
temperature.
DISPLAY SET
Enter and confirm
clock settings.
7
