METAL MAN
Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before
using product. Protect yourself and others by observing all safety information, warnings, and
cautions. Failure to comply with instructions could result in personal injury and/or damage to
product or property. Please retain instructions for future reference.

Description

The Metal Man Deluxe Folding Weld Table
provides a quick and easy work surface for welding
projects. Designed to quickly and easily fold up,
this weld table provides a flexible work surface and
is easy to store. The work surface measures 36
inches wide and 20 inches deep. In the middle of
the work surface is a heavy wire grate designed to
allow debris to fall through to the removable
collection tray below. The Deluxe Weld Table is
perfect for mobile welding applications,
maintenance departments or anywhere space is a
premium.

Specifications

Item
Packing Dimension (LXWXH) inch
Product Dimension (LXWXH) inch
Packing weight
Net weight

Assembly

1.1 Assemble the No.20 connecting tube to the No.1 top table
1.2 Assemble the No.16 short leg with the No.20 connecting tube
1.3 Assemble the No.13 long leg to the No.1 top table
1.4 Assemble the No.13 long leg to the No.16 short leg
Deluxe Folding Weld Table
Specification
36" x 10" x 43-1/2"
36" x 20" x 36"
46 lbs
43 lbs
1
FWTD
