AC Antennas KUM603 Series Installation Manual

3 section

Advertisement

AC Antennas has a
complete range of
mounting hardware
for the KUM series.
Mounts to be
ordered separately.
See datasheets for
all details.
N070F or N075F
Clamp Mount
Ø30-50mm
Tighten the M8
bolts with max 6Nm
of torque.
2 x N070F or
2 x N075F
per Antenna

Package content:

Top section
Middle section
Bottom section
N080F or N085F
Clamp Mount
Ø50-80mm
Tighten the M8
bolts with max 6Nm
of torque.
2 x N080F or
2 x N085F
per Antenna
M4 set screws
(2 pcs)
M6 set screws
(2 pcs)
M3 Machine
Screws
(4 pcs)
Box Lid
M10 nuts
(reused from
antenna)
PCB
(Coax cable
not included)
TX15 Tapping
Screw, with
washer
Box
(Only applicable for type -1 and -2)
N090F
Clamp Mount
Ø80-100mm
Tighten the M8
bolts with max 6Nm
of torque.
2 x N090F
per Antenna

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KUM603 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AC Antennas KUM603 Series

  • Page 1 TX15 Tapping Screw, with washer (Only applicable for type -1 and -2) Top section Middle section Bottom section AC Antennas has a N070F or N075F N080F or N085F N090F complete range of Clamp Mount Clamp Mount Clamp Mount mounting hardware Ø30-50mm...
  • Page 2 Installation Guide This is a guide only and does not form any contract or warranty DETAIL A SCALE 1 : 2 1: Assemble the top and middle antenna sections with 20-25 Nm recommended torque 2: Tighten the M4 set screws (2 pcs) with 1-2Nm recommended torque.
