  • Page 1 USER MANUAL RADWIN 5000 SCB JET FOR SMALL CELL BACKHAUL Release 4.2...

  • Page 2: Table Of Contents

    1.2 Customer Support .......................1-2 Chapter 2: Introduction 2.1 Welcome to RADWIN 5000 SCB Jet! ...................2-1 2.2 Components of a RADWIN 5000 SCB Jet Link or Sector............2-3 Chapter 3: Site Survey 3.1 Planning the Sector or Link Sites ..................3-1 3.2 The Site Survey ........................3-1 3.3 Stage 1: Preliminary Survey....................3-2...
  • Page 3 12.3 Four Sector Display Views ....................12-3 12.4 Continuing with our Example Sector................12-10 12.5 Exploring the RADWIN Manager Main Window - HBS ..........12-11 12.6 Exploring the RADWIN Manager Main Window - HSU..........12-22 12.7 Logging on to a HSU ......................12-22 12.8 Setting RADWIN Manager Preferences.................12-26...
  • Page 4 19.3 HSS Implementation......................19-3 19.4 External Pulses Messages and Color Codes..............19-15 Chapter 20: Network Timing Synchronization 20.1 What is it for........................20-1 20.2 Synchronous Ethernet (Sync E) ..................20-1 20.3 IEEE 1588v2 Transparent Clock ..................20-4 RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 5 21.1 VLAN Tagging - Overview ....................21-1 21.2 Scope of this Chapter ......................21-1 21.3 Requirements ........................21-1 21.4 VLAN Tagging........................21-1 21.5 VLAN Configuration Using the RADWIN Manager ............21-6 Chapter 22: Quality of Service 22.1 Prerequisites ........................22-1 22.2 QoS - Overview........................22-1 22.3 Setting up QoS.........................22-2 Chapter 23: Operating Under the FCC Unrestricted Contention Based Protocol 23.1 Scope of this Chapter ......................23-1...
  • Page 6 Appendix C: Model Variants Appendix D: Laboratory Installation D.1 About SCB Jet Laboratory Units ..................D-1 D.1 Installing RADWIN 5000 SCB Jet in a Laboratory ..............D-2 D.2 PtP Configuration........................D-5 D.3 PtMP Configuration ......................D-8 D.4 Full Antenna Alignment for a Laboratory Installation............D-12 Part 8: Regulatory Notices Regulatory Compliance ............................

  • Page 7: List Of Tables

    ....21-10 ABLE URTHER ONFIGURATION OPTIONS AND RESULTS BY AG MODE 22-1 D VLAN ID ......22-1 ABLE EFAULT PRIORITIES AN D ALLOCATION BY IFFSERV 27-1 S ........27-6 ABLE PECTRUM NALYSIS ISPLAY UTTONS FUNCTIONALITY RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 8 A-1 T ......................A-1 ABLE ERMINOLOGY B-1 S RADWIN 5000 SCB J IC P .....B-1 ABLE AFETY ISTANCES FOR RODUCTS B-2 S RADWIN 5000 SCB J ETSI P .......B-1 ABLE AFETY ISTANCES FOR RODUCTS RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 9 Part 1: Installation Release 4.2...

  • Page 10: Chapter 1: About This User Manual

    1.1 Manual Structure This User Manual is divided into seven functionally distinct sections reflecting the activities required to set up a RADWIN 5000 SCB Jet sector. The division is shown in the following table: Table 1-1: User Manual - General layout...

  • Page 11: Customer Support

    Remind you of something that should be kept in mind 1.2 Customer Support Customer support for this product can be obtained by contacting support@radwin.com . For additional information, contact the RADWIN distributor nearest to you or one of RADWIN's offices worldwide. RADWIN 5000 SCB Jet User Manual...

  • Page 12: Chapter 2: Introduction

    GHz band. 2.1.1 The RADWIN 5000 SCB Jet Series The RADWIN 5000 SCB Jet Series is a complete portfolio of carrier-grade PtP and PtMP solutions geared for small cell non line-of-sight (NLOS) backhaul. These sub-6 GHz solutions operate in dense urban environments where there is no line-of- sight, high radio interference and severe multipath conditions.

  • Page 13: Product Highlights

    Align- ment and Commissioning) 2.1.3 Product Highlights The RADWIN 5000 SCB Jet product consists of a High Capacity Sector Base Station and one or more Subscriber units • Up to 350Mbps throughput in a single channel at 40 MHz CBW •...

  • Page 14: Components Of A Radwin 5000 Scb Jet Link Or Sector

    Link or Sector 2.2.1 Major Components of a PtMP Sector A RADWIN 5000 SCB Jet Point-to-MultiPpoint sector consists of an HBS communicating with up to 4 HSUs located within the beam of its antenna. Figure 2-1: Sector Schematic: Main Components Both the HBS and the HSUs communicate respectively, with the service provider and users through PoE devices.

  • Page 15: Recent Events

    Introduction 2.2.2 Major Components of a PtP Link A RADWIN 5000 SCB Jet point-to-point link consists of a pair of outdoor radio transceivers units (ODUs) using a MIMO 2x2/3x3, OFDM smart beam-forming integrated antenna. The ODU itself is connected to a PoE device providing an Ethernet LAN connection to user equipment.

  • Page 16: Chapter 3: Site Survey

    RADWIN 5000 SCB Jet offers a wide operating frequency range. A free frequency channel must be determined within the operating range, for optimum performance.

  • Page 17: Stage 1: Preliminary Survey

    This type of reflection causes the received amplitude to be reduced. As a rule of thumb, the presence of a large body of water between sector sites may dou- ble the required antenna height. RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 18: Stage 2: Physical Survey

    6. If there are obstructions between the two sites, calculate the Fresnel Zone 7. If the sites chosen do not meet requirements, consider alternative sites. 8. You may require a RADWIN Site Survey Kit to complete the task. Contact Customer Support for further information.

  • Page 19: Stage 3: Rf Survey

    Self-interference from co-located RADWIN radios • Other co-located radio devices installed on the same site. To avoid or minimize interference, follow these recommendations: • For co-located RADWIN units, use Hub Site Synchronization to synchronize between them. RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 20: Additional Tools And Facilities

    Additional Tools and Facilities Site Survey • If one or more co-located units are not RADWIN units, ensure that there is a physical separation of at least three meters between a RADWIN unit and any other co-located radio on the site.

  • Page 21: Chapter 4: Hardware Installation

    Chapter 4: Hardware Installation 4.1 Overview This chapter describes the hardware installation of a RADWIN 5000 SCB Jet unit in accordance with the prior planning as set out in Site Survey. 4.2 Goals After you have completed the steps in this chapter, your HBS and all HSUs should be installed in its final location and have electrical connections.
  • Page 22 Cable glands (to be used with the HBS/HSU-PoE cable) 4.3.2 Power over Ethernet (PoE) Devices Indoor PoE RADWIN’s Gigabit Power over Ethernet (GbE PoE) device provides data and power to SCB Jet outdoor units. AC and DC models are available. Figure 4-2: GbE Indoor PoE device RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 23 The use of lightning protection is dependent on regulatory and end user requirements. The LPU is designed with surge limiting circuits to minimize the risk of damage due to lightning strikes. It is designed for use with RADWIN products. Figure 4-4: RADWIN Lightning Protector The lightning protector incorporates a high-power gas discharge tube and current transistor protection in a single protector unit.

  • Page 24: Preparations Before You Start

    Ensure that there is a LAN cable in place from the user’s switch to the PoE location 4.4.3 Tools and materials The following is a list of the equipment and materials required to install RADWIN 5000 SCB Jet hardware. •...

  • Page 25: Hardware Installation Procedure

    • Up to 100 m. for 100BaseT connection. • For a 1000BaseT connection (HBS only) use an ODU-PoE cable no longer than 75m. For 1000BaseT, use RADWIN supplied ODU-PoE cables, which guarantees 1Gb performance. RADWIN cannot guarantee 1Gb performance if you use third party cables.
  • Page 26 You will then have one “unit” that you can take to the location on the pole where you want to mount the ODU. (See Figure 4-15 RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 27 Figure 4-9: Rotate Clamp and tighten bolts Figure 4-10: Mounting Kit on pole Figure 4-11: Mounting an ODU on a horizontal pole To attach the RADWIN 5000 SCB Jet unit to a vertical pole, use the radio vertical adaptor as shown in Figure 4-6.
  • Page 28 Step 2: Mount the HBS/HSU Hardware Installation Figure 4-12: RADWIN 5000 SCB Jet on a vertical pole Figure 4-13: RADWIN 5000 SCB Jet on a horizontal pole RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 29 Figure 4-14: Mounting an ODU on a wall When mounting on a thin pole, position the pole clamp as shown in the following figures: Figure 4-15: Connect Pole Clamp to Radio Figure 4-16: Tighten bolts Holder RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 30: Grounding Lug

    There is a grounding lug on the rear of the HBS/HSU as shown in Figure 4-19. Connect it to ground using 10 AWG wire. Grounding lug Figure 4-19: HBS: Grounding lug RADWIN 5000 SCB Jet User Manual Release 4.2 4-10...
  • Page 31 RADWIN recommends the use of additional surge arrestor devices to protect the equipment from nearby lightning strikes. In what follows, ODU may be any type of RADWIN outdoor radio unit and IDU may be any type of RADWIN IDU used with such products.
  • Page 32 The LPU has two cable glands on the bottom for CAT-5e cables, in addition to a grounding lug. There is an extra hole for a second screw when installed on a wall. On the side of the LPU RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 33 4. Connect the grounding lug to a grounding source. 5. Remove the cable glands. 6. Thread the CAT-5e cables through the cable glands, and connect the cables to the LPU as shown in Figure 4-25. RADWIN 5000 SCB Jet User Manual Release 4.2 4-13...
  • Page 34 8. Route one CAT-5e up to the ODU, and the other down to the IDU or PoE (via the lower LPU). An LPU installed on a pole is shown in Figure 4-27. 9. RADWIN recommends that you add extra waterproofing to the connections (see see "Step 6: Add Supplemental Waterproofing" on page 4-15.).
  • Page 35 7. Route one CAT-5e up to the ODU (via the upper LPU), and the other to the IDU or PoE. 8. RADWIN recommends that you add extra waterproofing to the connections (see see "Step 6: Add Supplemental Waterproofing" on page 4-15.).
  • Page 36 LAN-Out port may damage it. 4.5.9 Step 9: Power up the HBS/HSU from a Poe Device Connecting the HBS/HSU port labelled PoE to a powered up PoE is sufficient. RADWIN 5000 SCB Jet User Manual Release 4.2 4-16...

  • Page 37: Chapter 5: Radwin Manager Setup

    Setup 5.1 In this Chapter We show you how to install the RADWIN Manager software on your managing PC, and connect it to an operating HBS. In addition, we also show how to switch the base station (default, PtP) to PtMP mode.

  • Page 38: Installing The Radwin Manager Application

    Any modern Web browser to view additional material, use the Web Interface or get help from the RADWIN Web site. 5.2.2 Installing the Software Any PC running the RADWIN Manager application can be used to configure a RADWIN 5000 SCB Jet sector. ...
  • Page 39 Any other response from ping means that the HBS is not responding. Check your Ethernet connection and that both the PoE and HBS are switched on and then try again. If you do not succeed, seek assistance from RADWIN Customer Service. Pinging the HSUs should yield similar responses.

  • Page 40: Log On To The Hbs

    Log on to the HBS RADWIN Manager Setup 5.4 Log on to the HBS 1. Open the RADWIN Manager from the desktop icon, or click Start|Programs|RAD- WIN Manager|RADWIN Manager. The Log-on dialog box appears. You may log-on using a valid IPv4 or IPv6 address:...

  • Page 41: Log On To The Hbs Via A Server (Optional)

    SNMPv1 and SNMPv3 at log-on time. To set the SNMP version, use the Settings button in Figure 5-5. A log-on extension window opens: RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 42: Logging On

    Write Operator plus Read- Installer wireless Read-Write netman netman set-band Write The Network Manager should change the default passwords as soon as possible, particularly if SNMPv3 is to be used. RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 43: Log-On Errors And Cautions

    If the IP address chosen is invalid or the sector is unreachable, the following error message will be displayed: Figure 5-9: Unreachable device message 5.6.3 Incorrect Password If you type an incorrect password in the Login window, the following message will be displayed: RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 44: Successful Log-On

    Community Strings. 5.7 Successful Log-on If you logged successfully, you will see one of the two following windows, depending if you are working in point-to-point mode, or point-to-multipoint mode: RADWIN 5000 SCB Jet User Manual Release 4.2...
  • Page 45 Point to Point RADWIN Manager Setup 5.7.1 Point to Point Figure 5-11: PtP Link display RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 46: Choosing The Operating Mode - Ptp Or Ptmp

    Link Configuration. In the RADWIN Manager, you will be able to switch the HBS between single and multiple HSU mode. Multiple HSU mode is Point-to-MultiPoint (PtMP). Single HSU mode is specifically PtP as distinct from a PtMP sector with one HSU.

  • Page 47: Configuration Tabs

    1. Log on to the HBS. Here is the initial situation: Make sure the HSU is NOT registered when switching from PtP to PtMP. 2. Click the Link Configuration tab. The Link Configuration dialog box will appear: RADWIN 5000 SCB Jet User Manual Release 4.2 5-11...
  • Page 48 Automatic Channel Selection enabled. 5. Click the Switch to Multiple HSU mode: 6. Click OK to continue: After a about minute, the main window goes into PtMP mode: RADWIN 5000 SCB Jet User Manual Release 4.2 5-12...

  • Page 49: Deregister Rt-B(Hsu)

    1. Deregister all the HSUs in the sector (see Deregister RT-B(HSU)). 2. Suspend all but the one required HSU for approximately 5 minutes (see Suspend a Deregistered RT-B(HSU)) 3. From the HBS Configuration window, open the Air Interface tab: RADWIN 5000 SCB Jet User Manual Release 4.2 5-13...

  • Page 50: Setting Preferences

    4. Click the Advanced button, followed by the Switch to Single HSU mode button. 5.9 Setting Preferences 5.9.1 Scope of Preferences The Preferences tab at the top of the RADWIN Manager relates to the managing computer. • If you are working in PtP mode, the preferences will be relevant for both the RT-A(HBS) and the RT-B(HSU).
  • Page 51 Preferences: Monitor RADWIN Manager Setup 5.9.2 Preferences: Monitor Figure 5-13: Monitor Preferences - HBS Figure 5-14: Monitor Preferences - HSU or HBS PtP Mode RADWIN 5000 SCB Jet User Manual Release 4.2 5-15...
  • Page 52 Generate KMZ: Relevant for Mobility sectors only. • Click Apply to apply your changes without closing the Preferences dialog box. • Click OK to apply your changes, and close the Preferences dialog box. RADWIN 5000 SCB Jet User Manual Release 4.2 5-16...
  • Page 53 SNMPv3. In this, case trap messages are keyed to the user name and password and not visible to anyone else. The preferences entered here relate to trap messages sent to the specified user if specified, or to all trap messages, otherwise. RADWIN 5000 SCB Jet User Manual Release 4.2 5-17...
  • Page 54 Change Password: You may change your log-on password here from the default value. Restore Alerts:Many alert messages in the RADWIN Manager have an option of the form “Do not show this message again”. These alert messages can be reverted to their default state (shown) by clicking this button.
  • Page 55 If the RSS Extended View button is unchecked, the center part of Figure 5-11 looks like this: For a PtMP sector, the HSU cards will look like this: RADWIN 5000 SCB Jet User Manual Release 4.2 5-19...
  • Page 56 For example (for a PtP connection), with this box checked the center part of Figure 5-11 looks like this: If this box is unchecked, the center part of Figure 5-11 looks like this: RADWIN 5000 SCB Jet User Manual Release 4.2 5-20...
  • Page 57 RADWIN Manager Setup For a PtMP connection, with this box checked the HSU display looks like this: For a PtMP connection, with this box unchecked the HSU display looks like this: RADWIN 5000 SCB Jet User Manual Release 4.2 5-21...
  • Page 58 If you want a background image for the map view, choose Background Image then click the explorer button to select the location of the image file. RADWIN 5000 SCB Jet User Manual Release 4.2 5-22...

  • Page 59: Chapter 6: Alignment And Commissioning

    6.3 Required Software • WINTouch application, installed on the Laptop PC • RADWIN Manager application, installed on the Laptop PC 6.4 Preparations Before You Start • Connect your Laptop PC directly to the HSU (either via the CAT-5e cables or via an...
  • Page 60 • You may have to ping the HSU to verify a connection (instructions for this are the same as that for an HBS - see Verify Connectivity to an HBS on page 5-2) RADWIN 5000 SCB Jet User Manual Release 4.2...

  • Page 61: Registering An Hsu For Service

    Alignment Procedure Alignment and Commissioning • You may have to open the RADWIN Manager to verify that the HSU is not registered. For instructions on how to verify this, see Registering an HSU for service on page 2. Run the WINTouch executable file. The following screen will appear: 3.
