Philips HR 6325 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
Maximum air displacement : 29 l/sec
Maximum vacuum
Power consumption 230 V
Dustbag capacity
Paper dustbag type no.
5 - Filter system
Cordwinder cordlength
Colour HR 6325/B
Dimensions of cleaner
Net weight
Gross weight
This product meets the requirements regard-
ing interference suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care
4322 277 00461
01/01
Economy
: 160 cm H O
2
: 1000 W IEC/1150 W Max
: 2.3 litre
: HR 6995 Geneva
: Double layer paper dustbag
Motor protection fi lter
Double layer exhaust fi lter
: 5 meter
: Yellow
: 38.2 x 27.2 x 23.3 cm
: 4.8 kg
: 8.6 kg (include packaging)
Printed in the Netherlands

Vacuum cleaner

SERVICE INFORMATION
- Component confi guration on exploded view may differ in
case of specifi c versions. However, the actual components
are distinguished by means of code numbers.
- After a repair has been made, make sure that the
appliance functions correctly.
- The spare parts have been standardized as much as
possible.
- Cordwinder
The cordwinder unit item 27 is a unit without cord.
The cord item 26 is a standardized spare and must be
shortened till 5 meter.
The pre-tension on the cord is 4 revolutions after the cord
has been wound.
After the product has been repaired, it should
function properly and has to meet the safety
requirements as offi cially laid down at this
moment.
© Copyright reserved
HR 6325/B
Subject to modification
