Marantz SB-C2 User Manual

Box Contents
Contenido de la caja
Contenu de la boîte
Contenuti della confezione
Lieferumfang
Battery Installation
Instalación de la batería
Installation de la pile
Installazione della batteria
Batterieinstallation
1
Polar Pattern
Patrón polar
Diagramme polaire
Figura polare
Polardiagramm
1 kHz
Marantz is a trademark of D&M Holdings Inc., registered in the U.S. and other countries. All other product or
company names are trademarks or registered trademarks of their respective owners. Manual Version 1.0

User Guide

Guía del usuario
Guide d'utilisation
2
Guida per l'uso
Benutzerhandbuch
Technical Specifications
Especificaciones técnicas
Spécifications techniques
Specifiche tecniche
Technische Daten
Electret condenser microphone
Type
Cardioid
Polar Pattern
Frequency Response 50–18000 Hz
Sensitivity -69 dB (±3 dB; 0 dB = 1 V/Pa @ 1 kHz)
200 Ω (+30%; @ 1 kHz)
Impedance
Equivalent Noise < 26 dB
130 dB (THD α 1%, 1 kHz)
Maximum SPL
Signal-to-Noise Ratio > 68 dB
Power Requirement (1) AAA battery, not included
Dimensions 4.5" x 1.8" x 3.0"
(length x width x height) 115 x 45 x 75 mm
Weight 0.32 lbs.
0.15 kg
Frequency Response
Respuesta en frecuencia
Réponse en fréquence
Risposta di frequenza
Frequenzgang
marantzpro.com
